- Page 1 USER GUIDE...
-
Page 2: Table Of Contents
Pairing of your WisePad with the Device (Mobile/Tablet) Transaction on your WisePad using a Magnetic Stripe Card or Chip Card To void a transaction on your WisePad Last Transaction Status History Day Summary Batch History Change Password Device Info... -
Page 3: Pairing Of Your Wisepad With The Device
Pairing of your WisePad with the Device (Mobile/Tablet) -
Page 4: Mobile/Tablet
Prepare your WisePad to pair with your Device (Mobile/Tablet). Ensure that the WisePad is fully charged via the microUSB slot (1a) on the left. Switch on your WisePad using the Power button (1b), it takes approximately 3-4 seconds. The display will show STANDBY. -
Page 5: (Mobile/Tablet)
Ensure that BlueTooth is switched on on your Device (Mobile/Tablet) Press the Bluetooth button (1a) on your WisePad for 4-5 seconds. This will put your WisePad in Bluetooth pairing mode. The blue light (1b) on your WisePad will start blinking. - Page 6 DEVICE To pair with passkey, ensure the passkey on the Device (Mobile/Tablet) is the same as that on your WisePad. Then press Pair .
- Page 7 The WisePad will display: PASSKEY 123456 DECLINE ACCEPT Press on your WisePad and press Accept on the application. The Bluetooth pairing is complete.
-
Page 8: Transaction On Your Wisepad Using A
Transaction on your WisePad using a Magnetic Stripe Card or Chip Card... - Page 9 98200XXXXX DEVICE On the Device (Mobile/Tablet) open the Mswipe Application. Login using your Username and Password.
- Page 10 Your WisePad will show STANDBY on the screen when switched on but not in use.
- Page 11 DEVICE In the Mswipe Application on the Device (Mobile/Tablet), open the Card Sale option. When you select Card Sale , your WisePad will detect the command and show WISEPAD READY on the screen.
- Page 12 DEVICE Enter the Amount and Mobile Number in the Card Sale option, then press Next . Con rm the total Card Sale amount by pressing OK .
- Page 13 DEVICE Follow the instructions on screen, press Start .
- Page 14 SWIPE /INSERT When you press Start on the Device (Mobile/Tablet), your WisePad will show SWIPE / INSERT...
- Page 15 For Magnetic Stripe Card INPUT PIN Swipe the card in the slot on the top of your WisePad, with the Magnetic Stripe facing towards you. The Magnetic Stripe should be at the bottom. After swiping the card it may prompt you to enter the PIN for the same.
- Page 16 AMIT KUMAR DEVICE After putting in the PIN, the Device (Mobile/Tablet) will show the card details. Con rm the details and press Submit .
- Page 17 123456 DEVICE Card Sale APPROVED will pop up, press Ok to proceed.
- Page 18 On the Device (Mobile/Tablet) it will bring you to the digital signature screen. After signing on the screen, press Submit and the signature gets uploaded to the server and the transaction is complete.
- Page 19 For Chip Card ICC INSERTED Insert the Chip Card into the slot on the lower side of your WisePad, with the chip side of the card facing upwards and the chip being inserted into your WisePad. Your WisePad will show ICC INSERTED.
- Page 20 The WisePad will display the amount: 40.40 DECLINE ACCEPT Press on your WisePad to proceed. It may prompt you to enter the PIN for the same.
- Page 21 AMIT KUMAR DEVICE After putting in the PIN, the Device (Mobile/Tablet) will show the card details. Con rm the details and press Submit .
- Page 22 123456 DEVICE Card Sale APPROVED will pop up, press Ok to proceed.
- Page 23 AMIT KUMAR PLEASE REMOVE CARD DEVICE The Device (Mobile/Tablet) will prompt you to remove the Chip Card. Press Ok to proceed.
- Page 24 DEVICE On the Device (Mobile/Tablet) it will bring you to the digital signature screen. After signing on the screen, press Submit and the signature gets uploaded to the server and the transaction is complete.
-
Page 25: To Void A Transaction On Your Wisepad
To void a transaction on your WisePad... - Page 26 DEVICE Select Void Transaction option in the Mswipe Application.
- Page 27 DEVICE Enter the Amount and Last 4 digits of the card then press Submit . Con rm the details and follow the instructions to void the transaction.
-
Page 28: Last Transaction Status
Last transaction status... - Page 29 DEVICE Select Last Transaction Status option in the Mswipe Application.
- Page 30 DEVICE On the Device (Mobile/Tablet), the display will show the last transaction details.
-
Page 31: History
History... - Page 32 DEVICE Select the History option in the Mswipe Application.
- Page 33 DEVICE On the Device (Mobile/Tablet), press Refresh .
- Page 34 DEVICE The Device (Mobile/Tablet) will show the last 30 days history.
-
Page 35: Day Summary
Day Summary... - Page 36 DEVICE Select the Day Summary option in the Mswipe Application.
- Page 37 DEVICE Press Set date to select the summary of a particular day. Then press Submit .
-
Page 38: Batch History
Batch History... - Page 39 DEVICE Select Batch History option in the Mswipe Application.
- Page 40 DEVICE Press Refresh to view the batch history.
-
Page 41: Change Password
Change Password... - Page 42 DEVICE Select Change Password option in the Mswipe Application.
- Page 43 DEVICE On the Device (Mobile/Tablet), enter the current password, then the new password. Re-enter the new password and press Submit .
-
Page 44: Device Info
Device Info... - Page 45 DEVICE Select Device Info option in the Mswipe Application.
- Page 46 Connect to WisePad, and press Device-Info to view information about the device. DEVICE On the Device (Mobile/Tablet), press Connect to proceed.
- Page 47 Connect to WisePad, and press Device-Info to view information about the device. DEVICE Press Device Info to view your WisePad information and battery level.
- Page 48 Customer Care: 1800-1022699 Email: helpdesk@mswipetech.com Mswipe Technologies Pvt. Ltd. Astral Center, 9th Floor, N.M. Joshi Marg, Byculla, Mumbai 11...
