Acer Extensa 5235 Series Quick Manual page 5

# Icon Item
4 HDD
Num Lock
Caps Lock
5 Power button
Wireless LAN
communication
button/indicator
Bluetooth
communication
button/indicator
6 Keyboard
7 Touchpad
8
Power
Battery
9 Click buttons
(left and right)
10 Palmrest
11 Microphone
1. The front panel indicators are visible even when the computer cover is closed
up.
Description
Indicates when the hard disk drive is
active.
Lights up when Num Lock is activated.
Lights up when Caps Lock is activated.
Turns the computer on and off.
Enables/disables the wireless LAN
function. Indicates the status of wireless
LAN communication.
Enables/disables the Bluetooth function.
Indicates the status of Bluetooth
communication. (only for certain models)
For entering data into your computer.
Touch-sensitive pointing device which
functions like a computer mouse.
Indicates the computer's power status.
1
Indicates the computer's battery status.
1
1. Charging: The light shows amber when
the battery is charging.
2. Fully charged: The light shows blue
when in AC mode.
The left and right buttons function like
the left and right mouse buttons.
Comfortable support area for your hands
when you use the computer.
Internal microphone for sound recording.
5
