LED parcan lighting effect
M
A
N
U
A
7 channel DMX controllable LED colour mixable spotlights
Sound-to-Light operation via built-in mic / Variable mic sensitivity
RGB configurations and colour mixing / Soft fade colour mixing
DMX control mode, each with 7 channels / Colour can be also set manually
Dip switches for menu control / 151 x 5mm ultra bright LEDs
Low power consumption / Tough metal chassis / Adjustable hanging bracket
Mains fused IEC / Dimensions: 205 x 225 x 210mm (WxHxD) / Weight: 1kg
For the latest instruction manual updates and information on the entire Kam range visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com
If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
Due to continuous product development, specifications and appearance are subject to change.
PAR56 V2
L
V
E
R
16-01-12
LED parcan lighting effect
Modern replacement of a PAR56 light
No bulbs to replace, lightweight and portable
Sound-to-light mode for non-DMX use
Preset programs / DMX in and out
Standard LEDs beam angle 25 degrees
© Copyright Lamba plc 2010. E&OE.
S
I
O
N
3
.
0
Advertisement
Summary of Contents for KAM PAR56 V2
- Page 1 For the latest instruction manual updates and information on the entire Kam range visit: www.kam.co.uk Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
- Page 2 Thank you for purchasing this KAM product, we are sure that it will serve you for many years to come. To optimise the performance of this product, please read these operating instructions carefully to familiarise yourself with the basic operations of this unit. After you have read the instructions, please retain them for future reference.
- Page 3 Rear panel 1. DMX in 2. DMX out 3. DMX address dip switches 4. Mic sensitivity 5. Power mains 6. Sound / auto switch (see dipswitch settings) Using the preset functions without a DMX controller Using stand alone settings via dipswitches Auto / sound mode Set dipswitch 8 to the on position, then using the sound / auto switch (6) toggle between auto or sound mode Master / slave...
- Page 4 Setting DMX address To activate the DMX mode Dipswitch 10 must be in the on position Use dipswitch 1-9 to set address requires Each unit uses 7 DMX channels If all units are to be controlled exactly the same set all units with the same DMX address If individual control of each unit is required, set all units with its own DMX address Remember all DMX addresses must be at least 7 channels apart and no DMX channels should cross For example, unit 1 set to address 1 unit 2 set to address 8 unit 3 set to 15 and so on.
- Page 5 000-255 Strobe (0%~100%) 000-127 No Function 128-159 Fade mode, control the speed with channel 5 160-223 Auto mode, control the speed with channel 5 224-255 Sound mode 001-255 Dimmer 0-100% Specifications Power supply 90-250 V AC, 50 Hz ~ 60 Hz ~ Power consumption 25 W Current...
