- Page 1 Bkav USER GUIDE SMART LIGHTING DEVICE Model: SH - D3 Bkav SmartHome technology company limited...
- Page 2 . s m a r t h o m e . b k a v . c o m Mfr Code: 893604393UGD3 Copyright © 2014 Bkav SmartHome Co., Ltd. All rights reserved. UGD3/V1.0/1014...
- Page 3 USER GUIDE SMART LIGHTING DEVICE Model: SH - D3...
- Page 4 User Guide SH - D3 Thank you for choosing smart lighting device SH - D3 of Bkav SmartHome. For selecting Bkav SmartHome’s products, you will get the best warranty service and installation support from our technicians. This document gives useful information during installation and usage time. You should read and keep the manual carefully in case of need.
- Page 5 SH - D3 Copyright © 2014 Bkav SmartHome Co., Ltd. All rights reserved. The smart lighting device SH - D3 is the product of Bkav SmartHome and has been registered regarding design, utility solutions and quality certification. All violations such as copies of design and product idea are subject to the current...
- Page 6 User Guide SH - D3 Safety instruction Do not use voltage which is different from the one stated in the device’s specifications. Disconnect the device’s power prior to any installation, disassembly or repair. Do not leave the device in high-temperature environment. Do not disassemble the device if not necessary.
-
Page 7: Table Of Contents
Contents SH - D3 Introduction 1. General introduction 2. Product package 3. Sensor area 4. Specifications Features 1. Auto lighting 2. Forcible lighting 3. Use remote control SH - RM6 4. Light sensor 5. Preferred light level settings 6. Indicator light Settings 1. -
Page 8: Introduction
Introduction SH - D3 Introduction 1. General introduction The smart lighting device uses pyroelectric infrared radial sensor technology. When users are in the sensor area, the light will automatically turn on. The device is integrated with light sensor and has ability to flexibly adjust the pending time to turn off the light when users leave the sensor area. -
Page 9: Product Package
2. Product package by Bkav User guide (book) USER GUIDE SMART LIGHT DEVICE Model: SH - D3 Bkav SmartHome technology company limited SH - D3 and remote control SH - RM6 Set of hook, screws, anchors and molly bolts for plaster ceiling... -
Page 10: Sensor Area
Introduction SH - D3 3. Sensor area Above the ceiling Below the ceiling Within the above distances, it is the best operation condition for the device. In case the device fails to detect users, please contact Notice Customer Contact Center. -
Page 11: Specifications
Introduction SH - D3 4. Specifications Voltage 100-240V 50/60Hz Load power Incandescent lamp - maximum 1000W Fluorescent lamp - maximum 350W Sensing range Maximum 5 m Applicable sensor area Maximum 20 m² Light sensing mode Adjustable day - night mode Operating temperature 60ºC max Dimensions (L x H) -
Page 12: Features
Features SH - D3 Features Components Sensor Turn on/off light sensor Adjust the pending time to turn off the light when Select switch type there is no motion Test mode Adjust the pending time to (for technicians only) turn off the light by switch... -
Page 13: Auto Lighting
Features SH - D3 1. Auto lighting The smart lighting device automatically turns on when detecting people in sensor area. When users leave the sensor area, the device will turn off after a preset time. The preset time for turning off can be set from 10 seconds to 60 minutes by switch S201 (refer to page 16 &... -
Page 14: Use Remote Control Sh - Rm6
Features SH - D3 Turn on the light: When the light is off, using a switch to turn on the light, the device will turn on and automatically turn off the light when users get out of the sensor area after the automatic turn-off time (refer to time settings in page 16 &... -
Page 15: Light Sensor
Features SH - D3 4. Light sensor Light sensor helps the device’s operation to be smarter and more power-saving. When using light sensing mode, the device automatically turns on only when environment light condition is darker than the preset one. Enable or disable this mode with switch S203 as shown in the figures. -
Page 16: Preferred Light Level Settings
Features SH - D3 5. Adjust light level For the preferred light level setting, please take the following steps: Wait for the environment light to reach the preferred level to begin the setting. Switch on and off 5 times consecutively for 3 seconds (or hold the button for more than 10 seconds) so that the device records the new reference light level. - Page 17 Features SH - D3 If the indicator light flashes every 0.5 second and off for 2 seconds in each cycle, the device is scheduled to turn off after 15 minutes. If the indicator light flashes twice every 0.5 second and off for 2 seconds in each cycle, the device is scheduled to turn off after 30 minutes.
-
Page 18: Settings
Installation SH - D3 Installation 1. Device’s default settings Mode Default value Actual settings Light sensor Forcible turn-off 10 hours Forcible turn-off Automatic turn-off 10 hours after 10 minutes Automatic turn-off 10 minutes S203 S202 S201 Switch type Ordinary switch 2. -
Page 19: Time Settings
Installation SH - D3 3. Time settings S203 S202 S201 S203 S202 S201 Forcible light turn-off Automatic light turn-off Forcible light turn-off Automatic light turn-off for 30 minutes after 10 seconds for 45 minutes after 60 seconds S203 S202 S201 S203 S202 S201... - Page 20 Installation SH - D3 S203 S202 S201 S203 S202 S201 Forcible light turn-off Automatic light turn-off Forcible light turn-off Automatic light turn-off for 6 hours after 10 minutes for 2 hours after 5 minutes S203 S202 S201 S203 S202 S201 Forcible light turn-off Automatic light turn-off Forcible light turn-off...
- Page 21 Installation SH - D3 (*) Difference between normal switch and push button switch Normal switch: is the type of switch mounted on electric panel to turn on and off the light. Its status does not change after interactions of switching. Push button switch: is the type of button commonly used with doorbell.
-
Page 22: Installation
Installation SH - D3 Installation The back of device by Bkav Smart Lighting Device Made in Vietnam Model: SH - D3 Neutral 100-240VAC Input Light device Input Line 100-240V Switch Switch 50/60Hz Light device Line 100-240V 50/60Hz Neutral Switch... -
Page 23: Wiring Diagram
Installation SH - D3 1. Wiring diagram Switch wiring diagram Neutral 100-240V Line 50/60Hz Switch Sensor 90mm The light can be replaced by other indicator devices based on users’ demand (bell, fan, alarm device, etc.). Notice... -
Page 24: Installation Steps
Installation SH - D3 2.Installation steps Step 1: Drill 2 screw holes to mount the hook on the ceiling. (Notice: avoid underground wire upon drilling as in Figure 1). Step 2: Connect the power line, light wire and switch wire to corresponding power connector, light, switch of the device (Figure 2). - Page 25 Installation SH - D3 Step 3: Mount the device on the hook to fix it to the ceiling (Figure 3&4). All wires mentioned in Step 2 should be connected properly to avoid damage to the device. During installation, the sensor surface should be kept from being Warning scratched, which may affect the sensor’s sensitivity.
-
Page 26: Problems During Usage
Problems during usage SH - D3 Problems during usage The following cases are not caused by device’s error Lights turn off when there is no motion in the room. Lights do not turn on when there is enough light in the room. - Page 27 Problems during usage SH - D3 The following cases are not caused by device’s error Lights turn on due to the impact of air conditioner heat sources (cooker, micro-wave, stove, etc.). Lights turn on due to moving objects.
- Page 28 Problems during usage SH - D3 The following cases are not caused by device’s error Lights turn on due to nearby powerful transmit- ting equipment. Lights turn on due to a nearby steam fan.
- Page 29 Problems during usage SH - D3 Problem Solution The device does not Use a switch to turn on and off the light, operate, the indicator if the device does not operate please light does not flash check the power connection. If you when there is a user cannot solve the problem, please contact in sensor area.
- Page 30 Problems during usage SH - D3 Problem Solution The device operates The device is currently in environment only when it is dark. light mode. To disable this mode, refer to light sensing mode settings (page 12).
-
Page 31: Contact
Contact SH - D3 If there is any problem related to the product, please contact Customer Contact Center: Customer Contact Center: (+1) 202 386 6779 Email: GlobalProject@bkav.com... - Page 32 T h e n e w h o m e s t a n d a r d !
