User Manual of Wireless Full Touch Color Screen Alarm System X6
Ⅰ. FOREWORD
Thank you for buying our 7 inch true color full touch screen alarm host.
performance home guard of high-tech product, it can provide more wonderful life interest to you!
In order to use this alarm system properly and efficiently, please read the following information before
use.
Ⅱ. SYSTEM CONFIGURATION
This alarm is composed of alarm host and matching accessories.
Note: alarm model is different, have different matching accessories category, please consult
supplier for details
Alarm host
Accessories optional
GSM 7 inch
wireless remote controller, wireless door sensor series, wireless wide angle PIR
true color full
sensor series, wireless indoor siren series, wireless smoke detector, wireless keypad,
touch screen
wireless gas detector, wireless doorbell button, wireless repeater, wireless emergency
alarm host
button, etc.
Ⅲ. SYSTEM INTRODUCTION
FEATURES
1, 7 "color screen, graphic display, friendly man-machine interface.
2, Multi-languages optional (simplified Chinese, traditional Chinese, English, German, French,
Russian...etc.)
3, 3/4 band GSM alarm information transmission, the realization of the telephone voice alarm,
protection zones/SMS alarm;
4, 30 wireless defence areas, extensible 8 wired defence areas and wired siren . preset up five
groups of alarm telephone, each group can be arbitrary set to phone call or SMS alarm, automatic
cycle dial;
5, Intelligent logic analysis technology, while alarm, display the corresponding protection zones ,
installation location, name of probe ,etc...
6, Alarm priority, random recording, voice alarm, SMS alarm, on-site monitoring, power off
information preservation, AC/DC power supply optional;
this product is a kind of high
Advertisement
Summary of Contents for Michael X6
- Page 1 User Manual of Wireless Full Touch Color Screen Alarm System X6 Ⅰ. FOREWORD Thank you for buying our 7 inch true color full touch screen alarm host. this product is a kind of high performance home guard of high-tech product, it can provide more wonderful life interest to you! In order to use this alarm system properly and efficiently, please read the following information before use.
-
Page 2: Technical Parameters
7, Text messaging, remote controller, host keypad, remote control keypad (optional), long distance telephone five ways control arm/disarm ; 8, Doors & windows condition monitoring automatically, can be extended to realize the wireless doorbell "ding dong" function; 9, Host low-voltage alarm; 10, "One-click"... -
Page 3: Standby Interface
DRAFT ● STANDBY INTERFACE INTRODUCTION ABOUT STANDBY SCREEN IN STATUS BAR 1. “GSM signal level” icon: max 5 level; 2. “SIM card status” icon: SIM card icon will be displayed if the SIM card is installed; On the contrary, the SIM card icon won’t be displayed if the SIM card isn’t installed;... - Page 4 7. “Sensor in low voltage” icon: this icon will come if the sensor which has low voltage emitting function, sends the low voltage signal to the alarm host when it is in low voltage; this icon will disappear if you click and finish browsing this records;...
- Page 5 B. ABOUT PROGRAM SETTING NOTE: *The buttons without any click within 40 seconds after operation, the host automatically quit programming and into the screen protection sleep state; *All operations shall be effective under the state into the “programming menu” *Input the wrong password three times, the host automatically restore the initial state 上面这段红字是加多的内容...
- Page 6 Alarm call/SMS setting, 5 groups; Group 1 for CID protocol CMS, group Phone Numbers 2~5 for personal use; Arm delay and alarm delay setting, host will beep one DI every second in Delay Time delay duration; Alarm time setting, individually set the alarm time for 24H defense line, Alarm Time defense line,2 defense line;...
- Page 7 Defense 34 ~ 35 —— wired Wired wide angle sensor, etc. Line 24H Defense Wired emergency button, wired gas 36 ~ 38 —— wired Line sensor, wired smoke sensor, etc. NOTE: Each wireless zone can accept 4 groups (group 0, group 1, group 2, group 3), one wireless sensor takes one group;...
- Page 8 define the default of door/window status is closed; and select Door Chime YES/NO, default is YES. *In smart zone, the default door status is Close. If you set the default status of door as Open, a “Window Icon” will appear on the Status Bar on the top of screen. It means in this mode you can’t arm system unless you select “Arm by Force”...
- Page 9 user code and Upload Status or not. *User code is selectable from 0001~9999; *If you choose YES to Upload Status, status info of alarm system will be sent to CMS; if NO to Upload Status, status info of alarm system won’t be sent to CMS; E.
- Page 10 By clicking the Emergency button on the screen of alarm host, the alarm system will alarm right now, and make calls/send SMS to entered phone number holders. 5. What can you do when you get an alarm call? You will hear the recorded voice immediately after receiving alarm call, the recorded voice will be played for 30 seconds repeatedly, and then you can make the following operations: ...
- Page 11 smart function for this zone; NOTE: A. This smart zone function needs smart door/window sensor, like wireless smart sensor、wireless smart control door/window sensor… B. If you want to arm alarm system, which has smart zone, by SMS or phone call, it is an ordinary operation like common arm operation, one time will work;...
- Page 12 Arm Delay One Di every second in Delay Alarm Delay One Di every second in Delay One Di Disarm Two Di Two Di every 30 seconds <Cut Wire Alarm setting should Landline is off be enabled > AC is OFF / AC is ON One Di Sensor is in low voltage status One Di...
- Page 13 Ⅳ. ABOUT PERIPHERAL SENSORS *This chapter includes two parts: introduction of wireless sensors, and how to learn/delete wireless sensors into/from alarm system. Wireless Remote Controller Features To control the alarm host to arm home/arm away/disarm the alarm system. Press emergency button to send emergency alarm for urgent help ...
- Page 14 the wireless remote controller will stay> + ENT Button + Click Group Code to enter X <Group Code is the code of target group, where the wireless remote controller will stay> + ENT Button + Click Activate Sensor in item You want to + ENT Button to confirm.
- Page 15 How to learn\delete wireless intelligent door sensor into\from alarm system How to learn wireless intelligent door sensor into alarm system: In standby screen, press Menu Button Enter program code xxxx + ENT Button Program Sensor + Click Zone Code and enter YY <Zone Code is the code of target zone, where the wireless intelligent door sensor will stay>...
- Page 16 Specifications Power supply: disposable battery/rechargeable lithium battery 3.7v800mAH Emitting distance: ≥100m (in open area) Service life of disposable battery ≤1 year, of lithium battery ≤3 years Detecting distance: 110°, 10m*10m Wireless frequency: 433MHz or 868MHz Static current: 50uA working current: 15mA ...
- Page 17 How to delete wireless wide angle PIR sensor from alarm system: In standby screen, press Menu Button + Enter program code xxxx + ENT Button Program Sensor + Click Zone Code and enter YY <Zone Code is the code of target zone, where the wireless wide angle PIR sensor stays>+ ENT Button + Click Group to enter X <Group Code is the code of target group, where the wireless wide angle PIR sensor stays>...
- Page 18 C. Press Emergency Alarm Button on the host screen more times to trigger the alarm host and make host send signal. D. If LED light on indoor siren flashes 5 times then goes off, it means learning operation is successful; Otherwise, you need repeat the progress; How to delete wireless indoor siren from alarm system: Connect the indoor siren with the power, Keep pressing the “Learning button ”on side of siren for 5 seconds and release;...
-
Page 19: Problems And Solutions
it, to make gas sensor send wireless signal to alarm system; 3. Zone code is optional from 02~10 1. Operation is same to learning operation of wireless wide angle PIR sensor; Operation same deleting 2. In trigger-learning stage, trigger Wireless smoke operation of wireless wide angle PIR smoke sensor by pressing button on... - Page 20 3. Input symbol “*” to stop alarm phone call finally from the host, the host won’t call your phone number anymore; 4. Hang off the alarm call, the host will dial next group No. 1. Adjust SIM card installation properly 1.
-
Page 21: Daily Maintenance And Care
sensor flashes pay attention to the battery type frequently in green door sensor’s Replace the battery with a new one, please indicator flashes Battery is dying pay attention to the battery type frequently. The distance of the Replace the battery with a new one, please remote controller gets Battery is dying pay attention to the battery type...
