Summary of Contents for Platinum 3OND
- Page 1 U S E R M A N U A L technologies...
- Page 3 Thank you for becoming a Wise owner of our Platinum e-BIKES 3OND. In this manual you will find information about how to use and maintain your 3OND, as well as information about our one year limited warranty. We stand behind our products 100% to give you peace of mind.
- Page 4 Congratulations on your new Platinum e-BIKES purchase. We do not just anticipate the joy COMPONENTS that the 3OND will bring you, we expect it! The 3OND, read “B-O-N-D”, stands for everything that Platinum e-BIKES is all about. It is the bond between you and your e-bike, between you...
-
Page 5: Specifications
SPECIFICATIONS Instruction Manual FRAME ALUMINUM ALLOY 6061 by: Wise Innovation Technologies BAFANG MID-DRIVE BRUSHLESS, 350W MOTTOR BATTERY 36V 14AH SAMSUNG CELLS POWER ASSIST COMES WITH: 5 LEVELS PEDAL, 5 LEVELS THUMB THROTTLE; CUSTOMIZABLE UP TO 9 LEVELS TRANSMISSION SHIMANO NEXUS INTERNAL GEARED HUB, 7-SPEED PEDALS WELLGO LU-C25 ALUMINUM BAFANG DPC14 COLOR LCD... - Page 6 COMPONENTS Instruction Manual COLOR DISPLAY / USB PORT by: Wise Innovation Technologies HANDLEBAR BRAKE LEVER FOLDING HANDLEBAR STEM SADDLE SEAT POST FRAME BATTERY HOUSING KEY INSERSION POINT MID-DRIVE MOTOR FRONT SHOCK TIRE PEDAL INTERNAL GEARED HUB REAR BRAKE CHAIN FRONT BRAKE CHAIN GUARD KICKSTAND NOT PICTURED:...
- Page 7 Wise Innovation Technologies Check to make sure that all of the following components are contained within the TIRE PRESSURE box of your new 3OND. Remove the valve cap by turning it counter-clockwise. Using a tire gauge, check that both tire pressures are Platinum e-BIKES 3OND folding bicycle √...
- Page 8 FOLDING AND UNFOLDING FOLD IN THREE (3) EASY STEPS 1. Lift the rear wheel off the ground. Use a foot to sweep the kickstand downward. Instruction Manual 2. Release safety and lever, and swing the front of the bike towards the back. by: Wise Innovation Technologies 3.
- Page 9 up and down BICYCLE POWER ON/OFF Insert key under frame just below folding mechanism. Turn key clockwise one click. [07]...
- Page 10 BATTERY MAINTENANCE components. If you are mechanically inclined and would like to Though the lithium-polymer battery that comes with the 3OND is built do some maintenance yourself, the following will help you on to resist overheating, exposing the battery to extreme heat can not only...
- Page 11 It will stay green, otherwise. Once the battery is fully charged, the light will turn green. Unplug the charger and be on your way to more adventures on your 3OND! [09] © 2016 Wise Innovation Technologies, Inc.
- Page 12 TIRE CHANGING Instruction Manual FRONT WHEEL REMOVAL by: Wise Innovation Technologies The front tire has a quick release system. Flip the quick release lever 180 °. Pull twist lever counter-clockwise USEFUL TOOLS while holding onto the lock nut on the opposite side of the Allen Key Set √...
- Page 13 On a fully charged battery, the range is anywhere What happens if I lose my key? What is the range of my 3OND? between 20 to 60 miles depending on how the In the SHOP on the Wise Tech website, click “Order battery is maintained, the terrain, the rider's weight, Replacement Keys.”...
- Page 14 BE NO OTHER WARRANTIES EXPRESSED OR IMPLIED INCLUDING ANY IMPLIED WARRANTY OF model number of the product available. To better ensure that your Platinum e-BIKES product is MERCHANTABILITY OR FITNESS OR ANY OTHER OBLIGATION ON THE PART OF THE COMPANY WITH covered under warranty and to help us better assist you, please register your product at RESPECT TO PRODUCTS COVERED BY THIS WARRANTY.
- Page 16 technologies...
