Kensington - 1 Drawer 2 Door Robe

Assembly Instructions -

Dimensions

Width - 85.9cm

Depth - 49.5cm

Height - 198.8cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, please visit www.argos-support.co.uk

or email: Help@ClickSpares.co.uk (quoting your original order number)

Alternatively, call the Spares Helpline on: 0370 112 1928.

For any other queries please contact the Customer Helpline on: 0345 640 2020

Please keep for future reference

424/1360

404/4275

MADE IN

BRITAIN

Issue 1 - 18/06/15

Need help?

Do you have a question about the 424/1360 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kensington 424/1360

Page 1 Kensington - 1 Drawer 2 Door Robe Assembly Instructions - 424/1360 Please keep for future reference 404/4275 Dimensions Width - 85.9cm Depth - 49.5cm MADE IN Height - 198.8cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit www.argos-support.co.uk...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 54kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 Please check you have all the panels listed below (DF2409) (85.9 x 49.5cm)
Page 4 Components - Fittings If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
Page 5 Assembly Instructions Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels. Step 2 Prepare the drawer sides Insert a small locking into the hole shown on the left drawer side and the right drawer side...
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
Page 7 Assembly Instructions Step 8 Prepare the left side Place a runner the left side shown. Slide back the Finished top of runner and use the front edge 2nd hole from the front to fit the 1st screw Fit 3 hinge plates onto the left side , making...
Page 8 Assembly Instructions Step 9 Prepare the right side Place a runner the right side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Finished Fit 3 hinge plates onto front edge the right side , making...
Page 9 Assembly Instructions Step 10 Prepare the shelf Insert 4 large locking nuts into the shelf Tap 4 wooden dowels into the shelf Finished front edge Step 11 Fit the shelf to the right side Push the shelf onto the right side Use a screwdriver to tighten the 2 large Finished...
Page 10 Assembly Instructions Step 13 Fit the 4 rails Note: The holes Push the 4 rails onto for this rail must be on this side the right side Use a screwdriver to tighten the large locking fitted to each of the 4 rails Note: Fit the rails at the back last and support them until the left side has...
Page 11 Assembly Instructions Step 15 Prepare the top Screw 4 metal dowels into the top Step 16 Warning: The Polystyrene unit is heavy. block Fit the top Lift with care. Note: To make it easier to fit the top and plinths, Polystyrene place polystyrene blocks block...
Page 12 Assembly Instructions Step 18 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
Page 13 Assembly Instructions Step 20 Finished Prepare a side plinth top edge Insert a large locking into 1 of the side plinths Tap a wooden dowel into the side plinth Step 21 Prepare the other side plinth Finished top edge Insert a large locking into the side plinth Tap a wooden dowel into the side plinth...
Page 14 Assembly Instructions Step 24 Fit the plinths Position the 3 plinths around the outside of the assembly, ensuring that the bottom edge of the plinths are flush with the bottom edge of the sides, as shown. Secure the 2 side plinths through the left end...
Page 15 Assembly Instructions Step 26 Fit the hanging rail and shelf studs Push the hanging rail into the rail holders fitted to the side panels. Push the 2 shelf studs down into the holes in the shelf to act as door buffers. Step 27 Prepare the 2 doors Push fit 3 hinges...
Page 16 Assembly Instructions Step 28 Fit doors and handles Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
Page 17 Assembly Instructions Step 29 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
Page 18 Assembly Instructions Step 30 Screw Fit the overbalance Washer protector Wall fixing Strap (not supplied) Strap To prevent possible Washer overbalancing we recommend that this unit Screw is secured to a suitable (not supplied) wall by fitting of the overbalance protector kit to the unit, or an alternative fixing method of your choice.
Page 20 ALR3175...
