User Manual

Dishwashers

AUPL-DW9X, AUPL-DW9W

AUPL-DW12X

AUPL-DW14X, AUPL-DW14W, AUPL-DW14I

IMPORTANT

Please ensure that you read through this manual prior to installation and use. This user

manual contains important information to ensure optimal performance and keep you safe.

Please retain your proof of purchase, as this will be needed in the event that you require a

warranty service. Remember to retain this user manual for future reference.

| platinumappliances.com.au

Table of Contents

Need help?

Do you have a question about the AUPL-DW9X and is the answer not in the manual?

Questions and answers

Dennis Brown

April 9, 2025

where find water draning pump platinum dishwasher water not draining

1 comments:

Mr. Anderson

April 10, 2025

The document does not provide information about where to find a water draining pump for the Platinum AUPL-DW9X dishwasher. For parts like the draining pump, you may need to contact the authorized service agent or the customer care listed in the manual.

This answer is automatically generated

Summary of Contents for Platinum AUPL-DW9X

Page 1 User Manual Dishwashers AUPL-DW9X, AUPL-DW9W AUPL-DW12X AUPL-DW14X, AUPL-DW14W, AUPL-DW14I IMPORTANT Please ensure that you read through this manual prior to installation and use. This user manual contains important information to ensure optimal performance and keep you safe. Please retain your proof of purchase, as this will be needed in the event that you require a warranty service.
Page 2: Table Of Contents
Contents Contents Warning & Safety Instructions Product Specifications Product Overview Operating Instructions 9-21 Maintenance 22-24 Installation 25-28 Trouble Shooting 29-30 Notes Contact Details Page 2 Dishwasher User Manual...
Page 3: Warning & Safety Instructions
Warning & Safety Instructions IMPORTANT // To ensure best performance, avoid risk of damage or accidents. Please read the operating instructions prior to first time use. Correct Application • Do not use commercial or industrial detergents as they may cause damage •...
Page 4: Warning & Safety Instructions
Warning & Safety Instructions Safety with children overheating and fire risk if the dishwasher were to be pushed against a plug. • Young Children should not use this • The Dishwasher must not be installed appliance . underneath a cooktop or next to an oven. •...
Page 5: Product Specifications
Voltage / Frequency 220-240V~ / 50Hz Power 1850W Water Pressure 0.04-1.00MPa Capacity 14 Place Settings Hot Water Connection Max 60ºC Model: AUPL-DW9X, AUPL-DW9W Dimensions W450 x D600 x H845mm Voltage / Frequency 220-240V~ / 50Hz Power 1850W Water Pressure 0.04-1.00MPa Capacity...
Page 6: Product Overview
Product Overview Control Panel Model: AUPL-DW12X START/STOP 3 sec 1. Power Button: To turn the power supply 4. Start/Pause Button: To start or pause the on/off. washing cycle. 2. Delay Start Button: To set the delay start 5. Rinse Aid Refill Indicator: The light comes for 3 different periods: 3, 6 or 9 hours.
Page 7: Control Panel
Product Overview Control Panel Model: AUPL-DW14X, AUPL-DW14W, AUPL-DW9X, AUPL-DW9W 1. Power switch: 1. Power Button: To turn 8. Rinse Aid Refill Indicator: The light comes the power supply on/off. on when the rinse aid dispenser needs to be refilled. 2. Delay Start Button: To set the delay start, 9.
Page 8 Product Overview Control Panel Model: AUPL-DW14I Intensive R inse Heav y R apid S oak Normal 10 11 1. Program Indicator Lights: The 7. Power Button: To turn the power supply corresponding light will turn on indicating on/off. the chosen washing program. 8.
Page 9: Operating Instructions
Operating Instructions ATTENTION // Before using your dishwasher for the first time, please read through these instructions as they contain important information on how to operate your appliance correctly. 1. Loading the dishwasher baskets NOTE // Do not overload your dishwasher. There is only space for 9, 12 or 14 standard place When loading items to be washed: settings, depending on the dishwasher model as...
Page 10 Operating Instructions NOTE // The height of the upper basket can be adjusted. There are 2 types of height adjustment systems: Sliding Brackets: This system allows the upper basket to be positioned in two different heights by simply lifting it and slowly sliding it down into the new height position every time a height adjustment is required.
Page 11: Lower Basket
Operating Instructions 1.2. Lower Basket AUPL-DW12X The lower basket is designed to hold larger items, which are most difficult to clean, such as pots, pans, lids, serving dishes and bowls. It is preferable to place serving dishes and lids on the side of the baskets in order to avoid blocking the rotation of the top spray arm.
Page 12 Operating Instructions 1.3. Cutlery Tray / Basket 5 5 5 5 5 5 5 5 5 5 The cutlery tray or basket, depending on the dishwasher model, is designed for, as its name suggests, forks, knives and spoons. The 3 4 3 3 4 3 4 images below provide suggestions of how to 1 1 1 1...
Page 13: Filling The Rinse Aid Dispenser
Operating Instructions NOTE // The following items are commonly not The rinse aid dispenser is located inside the suitable for dishwashers: door next to the detergent dispenser. • Cutlery with wooden or mother-of-pearl To fill the dispenser, open the cap and pour handles.
Page 14 Operating Instructions 2.1. When to refill the rinse aid dispenser You can check the level of rinse aid in the dispenser by the colour of the optical level indicator “D” located next to the cap. When the rinse aid container is full, the whole indicator will be dark.
Page 15: Filling The Detergent Dispenser
Operating Instructions 2.2. Adjusting the amount of rinse dirt. Most of the available dishwasher aid released in every wash detergents will fulfil this purpose. The washing programs of your dishwasher The rinse aid dispenser has six settings. were specially designed to work in conjunction Always start with the dispenser set on “4”.
Page 16: Detergent Dispenser
Operating Instructions NOTE // Some “3 in 1” tablets don’t have If detergents without phosphate are used in cases where hard water is supplied, white enough rinse aid in their composition which spots often appear on dishes and glasses. can affect the drying results. If this is the In this case, please increase the amount of case, it is suggested to use a liquid rinse aid detergent to achieve better results.
Page 17 Operating Instructions 1. If the lid is closed: press the release 1. Main washing cycle detergent dispenser. button. The lid will spring open. MIN suggests approximately 20g of detergent. 2. Pre-washing cycle detergent dispenser. It holds approximately 5g of detergent. If the dishes are heavily soiled, place an additional detergent dose in the pre-wash detergent chamber.
Page 18 Operating Instructions 4. Starting the washing program Washing Cycle Tables Models: AUPL-DW14X, AUPL-DW14W, AUPL-DW14I, AUPL-DW9X, AUPL-DW9W Program Cycle Selection Information Description of Detergent Pre/ Runnig Energy Water Cycle Main Time (kWh) For the heaviest soiled loads, Pre-wash(40ºC) 5/27.5g 1.35 20.0 such as pots, pans, casserole Main wash(55ºC)
Page 19 Operating Instructions Washing Cycle Tables Models: AUPL-DW12X Program Cycle Selection Information Description of Detergent Pre/ Runnig Energy Water Cycle Main Time (kWh) For the heaviest soiled loads, Pre-wash(40ºC) 5/25g 1.20 15.5 such as pots, pans, casserole Main wash(55ºC) dishes and dishes that have Rinse 1 been sitting with dried food on Rinse 2...
Page 20 Operating Instructions 5. Have you forgotten a dish to be NOTE // If the detergent has been released already, the detergent dispenser must be placed in the dishwasher? refilled before starting a new program. A forgotten dish can be added if the detergent NOTE // If all the lights begin to glimmer, that cup isn’t opened yet.
Page 21 Operating Instructions 8. Removing strong spots and 5. Open the door slightly, wait until the spray arms stop. stains from glassware 6. Once the arms have stoped, fully open 1. Do not load the dishwasher with any the door and pour 2 cups of white vinegar metallic utensils.
Page 22: Maintenance
Maintenance WARNING // Before cleaning or servicing your 3. Micro filter - This filter holds soil and food dishwasher, always remove the plug from the residue in the sump area and prevents power point. it from being redeposited on the dishes during a washing cycle.
Page 23: Cleaning The Dishwasher
Maintenance 3. Wash the arms in warm soapy water and use a soft brush to clean the jets. Rinse thoroughly. 4. Repeat the steps in reverse to reinstall the spray arms in position. 2. All 3 parts of the filter can now be removed and washed under running water.
Page 24 Maintenance 4. Cleaning the door seals 2. Remove the power plug from the power supply. Food debris can get trapped in the door 3. Turn off the water supply and leave seals and it can be the cause of bad odours the door of the appliance ajar.
Page 25: Installation
Models: AUPL-DW12X, AUPL-DW14X, AUPL- with the wall. This appliance can also be DW14W, AUPL-DW9X, AUPL-DW9W recessed under a bench top. 3. Position the dishwasher on a level and sturdy floor. If the floor is uneven, the front feet of the appliance can be adjusted until it reaches a horizontal position.
Page 26: Cabinet Dimensions
Installation 2.1. Specific requirements for 2.1.2. Skirting Board & Door Panel Integrated Dishwasher model – NOTE // The required height of the skirting AUPL-DW14I board is based on 2 aspects: aesthetics and smooth opening and closing of the door. Please refer to suggested values in the chart below.
Page 27: Door Spring
Dimensions of the door panel the tension of the spring and turning the screw anti-clockwise decreases the tension of the spring. the hole with 10mm depth 2- 2 3. Connecting the water and electrical supplies The dishwasher should not stand on top of 2.1.3.
Page 28: Installation
Installation 3.2. Connecting the water outlet 3.4. Electrical connection Insert the hose into a drainage hose with NOTE // During installation, the power supply diameter greater than 40mm or into a sink, in must not be excessively or dangerously bent or both cases, make sure that the outlet pipe is flattened.
Page 29: Trouble Shooting
Water leakage Water leakage occurs LED3 LED5 flashing Heating element Abnormal heating * Models: AUPL-DW14X, AUPL-DW14W, AUPL-DW14I, AUPL-DW9X, AUPL-DW9W **Model: AUPL-DW12X - Refer to page 6 for detailed view of LED indicators. PROBLEM POSSIBLE CAUSES WHAT TO DO Fuse blown, or the Replace fuse or reset circuit breaker.
Page 30 PROBLEM POSSIBLE CAUSES WHAT TO DO Noise Some audible sounds are Sound from detergent cup opening. normal Utensils are not secure in To ensure everything is secured in the dishwasher. the baskets or something small has dropped into the basket Motor hums Dishwasher has not been used regularly.
Page 31: Notes
Notes Dishwasher User Manual Page 31...
Page 32: Contact Details
NSW 1755 1300 985 815 customercare@platinumappliances.com.au platinumappliances.com.au Platinum is committed to ongoing research and development. Every effort has been made to ensure all information in this usermanual is correct at time of going to print. Dimensions should be used as reference only and actual dimensions should be taken form the phyical product only.
