Summary of Contents for Xtron TD706
- Page 1 Car Multimedia System USER MANUAL Model Number: TD706/ TD706G (GPS optional) PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
-
Page 2: Warning
================================ XTRONS Car DVD Player=============================== Acknowledgement Thanks for purchasing our car DVD player! In order to use this system properly, please read this manual before using it. Keep this manual for the future reference Warning Keep the disc entry clean. You should clean it immediately if there is dust. Disc with dust must be cleaned by clean soft cloth before putting into the machine, otherwise, the dust will be taken into the machine together with the disc from the entry, which may influence the drive of the machine, and cause the entrance... -
Page 3: Table Of Contents
================================ XTRONS Car DVD Player=============================== Content Acknowledgement............................I Warning ................................I Instructions for Installation ..........................I Content ................................II Detaching/Attaching the Monitor Panel......................1 Detaching ............................1 Attaching ............................1 Connecting Guide............................2 Monitor Panel Buttons ..........................3 Basic Operation..............................4 Power on/off...........................4 Previous/Next ..........................4 TFT Screen Angle Adjustable ......................4 Volume Control ..........................4 Mute ...............................4 Mode Switch ..........................4... - Page 4 ================================ XTRONS Car DVD Player=============================== Return to Main Menu ........................13 General Setup ..........................13 DVD/ SD/ MMC/ USB Mode ........................13 Enter/Eject............................14 Play/Pause ............................14 Stop...............................14 Direction Keys..........................14 Menu ............................15 Operation on Selecting the Catalog Functions ................15 Track Setup...........................15 Exit from the Menu ........................16 Volume control/Mute........................16 Repeat............................16 Fast forward/Fast backward ......................16...
- Page 5 ================================ XTRONS Car DVD Player=============================== ² Skin ............................26 ² System ..........................27 GPS Navigation..........................27 AUX Mode..............................27 TFT Screen Angle Adjusting ......................28 Exit the Menu ..........................28 Volume/Mute control........................28 TA On/Off.............................28 Return to the Main Menu ......................28 General setup menu:........................28 Back Sight Video Input Mode ........................29 iPod Mode [Optional]...........................30 Main Menu Setup .........................30 iPod Video Settings ........................30...
-
Page 6: Detaching/Attaching The Monitor Panel
================================ XTRONS Car DVD Player=============================== Detaching/Attaching the Monitor Panel Detaching 1. While the unit is turned on, press OPEN on the monitor panel to slide the panel downward. 2. Press the release button at the bottom of the panel (see picture above). Note: The panel closes automatically when no operation is done for about a minute. -
Page 7: Connecting Guide
================================ XTRONS Car DVD Player=============================== Connecting Guide iPod Input Video Input 1 TV- Antenna Video Output 2 AUX-L Input Sub-woofer AUX-R Input Rear Video AUX Video Radio Antenna Joint PDF 文件使用 "pdfFactory Pro" 试用版本创建 隖 www.fineprint.com.cn... -
Page 8: Monitor Panel Buttons
================================ XTRONS Car DVD Player=============================== Monitor Panel Buttons 1. Power Switch/Mode Switch 2. TFT Screen Slide Up/Down 3. GPS, Loud On/Off 4. Reset 5. Previous 6. Next 7. Microphone Window 8. Remote Receiver Window 9. Volume - 10. Volume + 11. -
Page 9: Basic Operation
================================ XTRONS Car DVD Player=============================== Basic Operation Power on/off Press (1) [SRC] in the standby mode to turn on the DVD player; Hold this button to turn off the player. Previous/Next When searching for radio channels, press (5) [Previous] or (6) [Next] can select the channels backward or forward respectively. -
Page 10: Reset
================================ XTRONS Car DVD Player=============================== DVD/SD /USB or iPod mode cannot be accessed when you press (1) [SRC]. The switching sequence is as follows: Audio/Video Input Radio GPS (Optional) Bluetooth Reset You can press (4) [RES] to reset the settings when the machine does not work normally. -
Page 11: Tft Screen Angle Adjusting
================================ XTRONS Car DVD Player=============================== TFT Screen Angle Adjusting You can press (12) and (13) in the main menu to control the screen to slide up and down. Each click allows you to slide up or down an angle. There are five angles;... -
Page 12: Tft Screen Angle Adjusting
================================ XTRONS Car DVD Player=============================== 1. TFT screen up-sliding key 2. TFT screen down-sliding key 3. Return to Main Menu 4. Current Status 5. Time 6. Exit the Setup Menu 7. Picture Setup 8. EQ Setup 9. Sound Balance 10. Skin Setup 11. -
Page 13: ² Eq Setup
================================ XTRONS Car DVD Player=============================== ² EQ Setup Press EQ to enter the EQ setup. Press [FLAT/ROCK/POP/JAZZ/CLASS] respectively to select the corresponding sound effect. ² Sound Balance Setup Press BALANCE to enter the balance setup. Press [BASS/TREBLE/BALANCE/FADER] and the corresponding bar shows up. -
Page 14: ² Skin Setup
================================ XTRONS Car DVD Player=============================== ² Skin Setup You can press to choose the corresponding style, color and skin. Press repeatedly to choose the preferred styles. Press repeatedly to choose four different background colors. ² Language and Rear-View Video Setup You can press [English] and [Chinese] to set English or Chinese as the... -
Page 15: ² Clock Setup
================================ XTRONS Car DVD Player=============================== ² Clock Setup You can press ] to turn on/off the beep. Press [TIME SETUP] to set the time format (12 hours and 24 hours available). Press [Hour] and [Minute] to adjust the time and minutes by touching PDF 文件使用... -
Page 16: Radio Mode
================================ XTRONS Car DVD Player=============================== Radio Mode 1. Automatic Scan 2. Scan Browse 3. Remote/Local Search Switch 4. MONO/STEREO Switch 5. TA (RDS) (Optional) 6. AF (RDS) (Optional) 7. PTY (RDS) (Optional) 8. Volume + 9. Volume - 10. TFT screen up-sliding key 11. -
Page 17: Rds (Optional)
================================ XTRONS Car DVD Player=============================== Press [STER] to choose the stereo or mono radio mode. RDS (Optional) ] do not work if there is no RDS or RDS is off. A. Press [TA] to search RDS radio automatically. B. Press [PTY] to choose your favorite program.The player will search the programs automatically in 2 seconds. -
Page 18: Tft Screen Angle Adjusting
================================ XTRONS Car DVD Player=============================== TFT Screen Angle Adjusting Press ] and ] in the setup menu to to slide the screen up and down to a proper view angle. Favorite Radio Channels You can press one of [Number key] for 3 seconds to save the channel as the preset channel. -
Page 19: Enter/Eject
================================ XTRONS Car DVD Player=============================== 1. Enter/Eject 2. Play/Pause 3. Stop 4. Direction Key 5. Main Menu 6. Catalog Functions 7. Audio 8. Return 9. Volume + 10. Volume - 11. Repeat 12. Fast Forward 13. Fast Backward 14. Next 15. -
Page 20: Menu
================================ XTRONS Car DVD Player=============================== Left/right/up/down direction key The confirming button You can press to select the programs and roll the picture when playing the MP3/MP4/SD/USB. The direction key icon disappears if there is no action on it in 5 seconds. Note: The direction key only works when it is in MP3, MP4 and DVD menu. -
Page 21: Exit From The Menu
================================ XTRONS Car DVD Player=============================== Note: This function can give you a satisfied sound effect when you are playing the bi-lingual movie or karaoke. You can choose the Chinese dubbing or English dubbing. Exit from the Menu Press [Return] or does not touch the screen, the menu will disappear automatically. -
Page 22: Return To The Main Menu
================================ XTRONS Car DVD Player=============================== Return to the Main Menu Press ] to return to the main menu. General Setup Menu Press ] to show the general setup menu. For details, please refer to page 7. Note: Operations on USB, SD and MMC card are the same as that in DVD mode. -
Page 23: Tv Mode
================================ XTRONS Car DVD Player=============================== TV Mode 1. TV system 2. Automatic scan 3. Skip 4. Manual fine tuning 5. Return 6. Volume + 7. Volume - 8. Channel return 9. Previous channel 10.Next channel 11. Previous scan by manual fine tuning 12. -
Page 24: Tv System Setup
================================ XTRONS Car DVD Player=============================== Click this area when you are not operating the TV menu and general setup to slide the TFT screen upward. B. Menu control area. Click this area to show the TV control menu. C. TFT screen down-sliding control area. Click this area when you are not operating the TV menu and general setup to slide the TFT screen downward. -
Page 25: Recent Radio Program Switch
================================ XTRONS Car DVD Player=============================== It is mute when you click the area between and the Volume number becomes . Press it again to cancel the mute. Recent Radio Program Switch Press to return to the previous channel. Pressing this button repeatedly allows you to switch between the two recent radio channels. - Page 26 ================================ XTRONS Car DVD Player=============================== 1. Play/Pause 2. Stop 3. Next 4. Previous 5. Call/receiving button 6. Hands-free/Hang-off 7.Bluetooth/Mobile phone switching key 8. Matching button 9. Back-spacing 10. Dialed number 11. Received Calls 12. Missed Calls 13. Number key 14. Return to Main Menu 15.
-
Page 27: Bluetooth Matching Connection
================================ XTRONS Car DVD Player=============================== setup menu, to slide the TFT screen downward. Bluetooth Matching Connection The Bluetooth function is automatically activated when you turn on the mobile phone. If there is no mobile phone to match the Bluetooth, the color of is white, in which it shows “SORRY NO LINK”. -
Page 28: Music Play Of Mobile Phone
================================ XTRONS Car DVD Player=============================== choose a number and press ] to make a call. You can press ] to check up to 10 recent incoming calls. You can press ] to check up to 10 missed calls. You can also choose a number and press ] to make a call. -
Page 29: Operations In Gps Mode
================================ XTRONS Car DVD Player=============================== GPS or other mode by pressing "SEL" on the remote control. You can set the device to the GPS, DVD, or other modes according to your preference. GPS2: Simple GPS Navigation Only GPS works, other functions, such as radio/DVD player, do not work. You can switch between GPS and the main menu of the device by pressing "SEL"... -
Page 30: ² Gps Setup
================================ XTRONS Car DVD Player=============================== ² GPS Setup Press ] in the GPS main menu to enter the setup menu; press ] to page up or down. Press Navigation setup, usual setup, GPS monitor, Touch screen, Screen, Time, Skin, and System to enter the corresponding interface. -
Page 31: ² Usual Setup
================================ XTRONS Car DVD Player=============================== ² Usual setup Press “Usual setup” to enter the setup interface. You can set the volume, key sound, and language here. ² GPS Monitor Press “GPS monitor” to enter the GPS monitor interface. You can see the information about the GPS satellite status. -
Page 32: ² System
================================ XTRONS Car DVD Player=============================== ² System Press "System" to enter the system setup interface. GPS Navigation Set the TFT screen to the lowest angle in the menu mode and insert the authorized map card into the GPS map card slot as shown in picture below: GPS Card Slot After the navigation setup, click the navigation icon in the interface of GPS console to enter the GPS navigation mode. -
Page 33: Tft Screen Angle Adjusting
================================ XTRONS Car DVD Player=============================== 1. TFT screen up-sliding key 2．TFT screen down-sliding key 3．Return 4．Volume- 5．Volume + 6．TA on/off 7．Return to main menu 8．Status and time 9. General setup Press the icon in the main menu to enter the AUX operation mode: TFT Screen Angle Adjusting Click ] and... -
Page 34: Back Sight Video Input Mode
================================ XTRONS Car DVD Player=============================== the general setup in page 7. Back Sight Video Input Mode Press in the main menu to enter the backup video operation mode. Note: The following menu interface is shown when you click the clock setup in the general setup menu. -
Page 35: Ipod Mode [Optional]
================================ XTRONS Car DVD Player=============================== iPod Mode [Optional] 1. Video 2．Menu 3．Search backward 4．Search forward 5．Enter 6．Hang-up 7. Volume + 8. Volume - 9. TFT screen up-sliding key 10. TFT screen down-sliding key 11. Next 12. Play/Pause 13. Previous 14. Return to main menu 15. -
Page 36: Remote Control
================================ XTRONS Car DVD Player=============================== Remote Control 1. Power Supply 11. GPS screen switching 21. Angle selection 12.Repeat/Automatically 2. Play/Pause 22.Title/Language settings save the channel 13.Random play/Local & 3. Enter/Eject 23. Main menu setup remote control 4. Direction keys 14. Number keys 24.Title/Catalog settings 5.Band/System switching button 15. -
Page 37: Remote Control Operations
XTRONS Car DVD Player ※※※※※※※※※※※※※※※※※※※※※※※ Remote Control Operations Power switch ※※※※※※※※※※※※※※※※※※※※※※※ ★ Replace the battery Press to turn on/off the power ★ supply. The remote control only works If the operating distance shortens or the when you have pressed the [POW] on remote control does not work, please DVD for the first time or after you change a new Lithium battery. - Page 38 XTRONS Car DVD Player ※※※※※※※※※※※※※※※※※※※※※※※ Remote control operations Programming / ST ★ ※※※※※※※※※※※※※※※※※※※※※※※ You can set the play sequence of the song Band/System switching ★ by this function in the state of VCD or Press [BAND/SYS] to change the radio Press [ST/PROG] in the state of band when you are searching the radio...
- Page 39 XTRONS Car DVD Player Remote control operations ※※※※※※※※※※※※※※※※※※※※※※※ ※※※※※※※※※※※※※※※※※※※※※※※ Number key Set the disc playing time ★ ★ Press number key 1-6 when you are When you are playing the disc, press searching the channel to choose the 6 radio [GOTO] to set the disc to play from the channels saved in each band.
-
Page 40: Title Menu
XTRONS Car DVD Player Remote control operations screen will enlarge in the following rules: 2-fold, 3-fold, 4-fold, 1/2-fold, 1/3-fold, ※※※※※※※※※※※※※※※※※※※※※※※ Stop playing ★ 1/4-fold, and 0-fold. Press ] for the first time to pre-stop Note: ZOOM key does not work in CD/MP3 mode. playing when you are playing the DVD, and ※※※※※※※※※※※※※※※※※※※※※※※... -
Page 41: Installation
XTRONS Car DVD Player Installation Installation Choose the proper fittings according to the car Note: 1. please keep the small parts away from the children. 2. Use the attached screws. 3. The installation of attached parts may vary from the cars. Make sure to be installed by the professional. -
Page 42: Specifications
XTRONS Car DVD Player Specifications General Power supply 14.4VDC 4 Ω Load Max. power output 45W*4 Tone control +/-8db (Bass:100Hz, Treble:10KHz) Dimensions About 192*178*100mm (D*W*H) Installation dimension About 169*182*103mm (D*W*H) Weight About 2.65 Kg DVD chip Applicable disc MPEG4. DVD,SUPER VCD, MP3, CD, CD-R, CD-RW, PICTURE-CD Video system AUTO, NTSC, PAL... -
Page 43: Troubleshooting
XTRONS Car DVD Player Troubleshooting Problems Reasons and settlement ¬ Check whether the fuse of power supply is broken. Change No power for another one with a proper capacity if necessary. ¬ Press Reset key LCD display mess-up and the key does not work ¬...
