- Page 1 D-Moticam BTW8 Microscope Tablet / Camera Use and Care Manual SWIFT OPTICAL Enduring Quality and Technical Excellence...
- Page 2 Moticam BTW8 Introduction Introduction Thank you for purchasing the D-Moticam BTW8 Tablet/Camera system. The BTW provides an effective method of attaching a camera system to any c-mount trinocular microscope using a 0.5x c-mount adapter. The image from the microscope can be viewed on the provided tablet or via WiFi to any WiFi enabled device.
- Page 3 BTW Diagram Connecting Tablet to Camera...
- Page 4 TABLET ACCESSORIES HDMI Cable This cable will enable you to connect to an HDMI ready device, to view your tablet on a larger format. The displayed image will replicate the displayed image of the tablet. Power Adapter This 5V DC power adapter is for charging your tablet’s battery.
- Page 5 Sample Trinocular Assembly TABLET OPERATION Volume adjustment - decrease Volume adjustment - increase Hold for a few seconds to turn unit on Micro USB Port for charging tablet and connecting to bracket camera Provides sound via earphone/speaker Connects to HD ready device via HDMI cable Micro SD Card Slot for storing images on Micro SD Card (4GB included)
- Page 6 Camera Switches and Ports – Limited Production This feature is limited to a small production batch, not a standard feature of this camera. Placing the switch in the WiFi mode, turns the camera into a WiFi only camera. Connection to camera can only be made via WiFi connection.
- Page 7 TABLET SOFTWARE This android tablet comes equipped will all the necessary software needed to start using your equipment out of the box. Since it is an android tablet, you will be able to connect to your office/school Wi-Fi network to access the internet and download additional applications.
- Page 8 MOTICHUB CONNECTION GUIDE Connecting to the hub with Motic Images Plus 2.0 on PC: After you have connected to your network/hotspot, open Motic Images 2.0 software and click the capture button. After you’ve opened the Motic Live Imaging Module, the drop down box under “Video Device” should say Moticam X. Then you will need to click “Open”...
- Page 9 MOTIC IMAGES SOFTWARE Full Help Menu The full software manual for Motic Images is accessible within the software’s main page. To begin, open the Motic Images Software. At the top of main screen find the menu tab labeled Help: ...
- Page 10 Motic Live Imaging Module Full Help Menu The full Live Imaging Module manual is accessible within the live Imaging main page. To begin, open the Motic Images Software. At the top of main screen find the menu tab labeled File and click on Capture: ...
- Page 11 SWIFT OPTICAL INSTRUMENTS, INC. Please see our website, www.swiftoptical.com, for complete warranty details and exclusions. Swift Optical Instruments, Inc.● (877) 967-9438 ● www.swiftoptical.com...
