Summary of Contents for Elk ELK-M1XRFTWM
- Page 1 ELK-M1XRFTWM Two-Way Wireless Transceiver/ Expander for Elk Two-Way Wireless Sensors. Refer to page 8 for a listing of sensor part numbers. INSTALLATION MANUAL PO Box 100 3266 US Hwy 70 West Hildebran, NC 28637 828-397-4200 828-397-4415 Fax L665 Rev. A 9/22/2016...
-
Page 2: Table Of Contents
Operating Voltage: 12 Volts D.C. • Current Draw: 25mA Receiving, 85mA Transmitting NOTE: ELK PRODUCTS IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. - Page 3 See the listing of available sensors later in the manual. This list is constantly growing and may not be current in this manual due to its printing date. Please contact your local Elk distributor for the latest products and information.
-
Page 4: Installation And Setup
Terminating Jumper Data Bus RS-485 Address Switches Data Bus Connections ELK-M1XRFTWM Two-Way Transceiver LEGEND Address 2 Address 3 Address 4 Address 5 NOTE: ONLY addresses 2, 3, 4, or 5 are permitted to be used with the M1XRFTWM. Installation must be in accordance with: - Chapter 2 of the National Fire Alarm Code, ANSI/NFPA 72 and the National Electrical Code,ANSI/NFPA 70. -
Page 5: Diagnostic Led Indicators
1. Mounting - Use two (2) #6 x 1/2" screws (not provided) on each side of the housing for mounting. The Transceiver connects to the Keypad data bus and may be remotely located up to several thousand feet away from the control. NEVER mount inside a metal enclosure or on metalized surface! Space at least 4 to 6 feet from electrical devices that generates noise, including the M1 Control. -
Page 6: Data Bus Enrollment
Tables 1-1 and 1-2 As shown above zones 17 to 32 are associated with data bus address 2, which is where the primary Elk-M1XRFTWM must be setup and enrolled. Avoid setting up and enrolling hardwired expanders at any of the data bus addresses where a wireless zone might someday be needed. -
Page 7: Operation
Every signal sent by an Elk two-way sensor receives a positive acknowledgment from the transceiver. One-way systems have the reputation of being "fire and pray". Elk two-way sensors only send one signal at a time. One-way sensors have no choice but to blindly send multiple signals in hopes that at least one will reach the receiver. -
Page 8: Elk 6000 Series Wireless Sensors
Elk 6000 Series Wireless Sensors Enrollment and programming of wireless devices may be done from Keypad Installer Programming or from ElkRP Enrollment from Keypad Installer Programming utilizes Menu 14 and the LRN (Learn) method. The enroll method varies between sensors. Please follow the specific enroll method suggested below and read the additional programming recommendations. -
Page 9: Quick Step' Enrollment Of Elk 6000 Series Sensors
6. To end Rapid-Enroll once all wireless zones (sensors) have been enrolled, press the ELK key one time. 7. Loop # - Refer to the "Elk 6000 Series Wireless Sensors" chart for more information on the loop setting of each sensor. For single internal reed sensors the Loop # setting will be 2. -
Page 10: M1 Keypad Programming For Wireless
M1 Keypad Programming for Wireless From the keypad enter the Installer Level Programming mode. Press ELK, 9 > (enter installer code). Navigate to the Wireless Setup - Menu 14 and press the RIGHT arrow key to select. There are four (4) wireless setup submenus: 1-Receiver (Transceiver) Options, 2-Xmitter 14-Wireless Options, 3-Xmitter Enroll, and 4-Keyfob Event Definitions. Use the UP or DOWN arrow keys to... - Page 11 Press the RIGHT arrow to move the cursor over to Loop =. Enter 1, 2, or 3 according to the sensor instructions. Refer to the "Elk 6000 Series Wireless Sensors" for more information.
-
Page 12: Appendix A - Data Bus Selection Table
Appendix A - Data Bus Selection Table This table should help visualize how the Wireless Zones and Hardwired Zones share the data bus address assignments. Please note that No Wireless Zones Are Allowed Above Zone 160. This table shows the starting wireless Zone # and data bus address along with the additional data bus addresses and Zone #’s necessary to obtain the total and best mix of wireless and hardwired zones. -
Page 13: Appendix B - Examples Of Zone Configurations
Appendix B - Examples of Zone Configurations Example A Example B Example C All 208 Zones as Hardwired 144 Wireless Zones 112 Wireless Zones plus plus 16 Hardwired Zones 48 Hardwired Zones Zones Bus Addr Inputs on Zones Bus Addr Inputs on Zones Bus Addr... -
Page 14: Appendix C - Installing Multiple Redundant Transceivers
Each addItional unit will require its own data bus address and must be enrolled into the control. IMPORTANT: There should NEVER be more than 4 total ELK-M1XRFTWM Transceivers connected to the M1 Control. Special attention must be made to minimize excessive coverage overlap. -
Page 15: Appendix D - Agency Statements
Limited Warranty The ELK-M1XRFTWM Wireless Transceiver is warranted to be free from defects and workmanship for a period of 2 years from date of manufacture. Batteries used with wireless devices are not warranted. Elk makes no warranty, express or implied, including that of mechantability or fitness for any particular purpose with regard to batteries used with wireless devices. Refer to Elk’s website for... - Page 16 Page 16 M1XRFTWM Installation Manual...
