Chapter 2
Setting-up
Supplying Power to the Alnor Model AXD620/A
The Alnor AXD620/A
batteries.

Installing the Batteries

Insert four AA batteries as indicated by the diagram located on the
inside of the battery compartment. The Alnor AXD620/A
PVM620 is designed to operate with either alkaline or NiMH
rechargeable batteries, although it will not recharge NiMH batteries.
Battery life will be shorter if NiMH batteries are used. Carbon-zinc
batteries are not recommended because of the danger of battery acid
leakage.

Using the Optional AC Adapter

When using the AC adapter, the batteries (if installed) will be bypassed.
Be sure to provide the correct voltage and frequency, which is marked
on the back of the AC adapter. The AC adapter will not recharge the
batteries.

Connecting to a Computer

Use the Computer Interface USB Cable to connect the instrument to a
computer. Connect the end labeled "COMPUTER" to the computer USB
port and the other end to the data port of the Alnor AXD620/A
PVM620.
For information on how to download stored data see Chapter 3
Downloading Software.
Caution: This symbol is used to indicate that the data port
of the Alnor AXD620/A
connection to a public telecommunications network.
Connect the USB data port only to another USB port.
PVM620 is powered with four size AA
