  • Page 1 AirPoint 2011-BYMG ™ User Guide...

  • Page 2: Table Of Contents

    6.1.1 Apple AirPlay wireless mirroring in P2P connection ............13 6.1.2 WiFi Direct – Miracast wireless mirroring in P2P connection ........... 16 6.1.2.1 Android Wireless Display (Android 4.2 or higher ) ......17 Doc. Ver.AAP-2011-BYMG-802-001 Arrive AirPoint™ - 2011 - BYMG - User Guide...
  • Page 3 7.2 Audio ............... 34 7.3 Video ............... 35 7.4 System ..............35 7.5 Assign web console password ......36 7.6 Change the SSID Name ........38 7.7 Add Signage ............41 Copyright © 2017 Arrive Systems, Inc. All rights reserved.
  • Page 4 IP addresses or phone numbers in illustrative content is unintentional and coincidental. ARRIVE disclaims ownership of the brand or use or association of the name “Visionergy” and/ or “Verity” as a real business or business entity and does not recommend the use of this name by others for a similar purpose of creating examples to avoid confusion. The domain visionergy.com is set to reflect to arrivesys.com.

  • Page 5: Fcc Compliance Statement

    Arrive Systems, Inc.. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by Arrive Systems, Inc., or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgment elsewhere in the body of this document, Arrive Systems, Inc.

  • Page 6: Introduction

    WiFi capable presentation device. It is part of Arrive’s MediaPoint™ product line, and marks the industry’s first generation of universally integrated devices – supporting the most commonly used wireless video connectivity platforms in a single device.

  • Page 7: Arrive Aap-2011-Bymg Panel Description

    • 802.11n/g Wireless enabled video source device (i.e. Smartphone, computer) • HDMI cable • Available USB port as power source 1.3 Arrive AAP-2011-BYMG Panel description Figure 1: Parts of the AAP-2011-BYMG Copyright © 2017 Arrive Systems, Inc. All rights reserved.

  • Page 8: Arrive Aap-2011-Bymg Specifications

    Operating Temperature 5 to 30°C (23 to 86°F) Storage Temperature 5°C to 35°C (23°F to 95°F) Humidity 10%~55% RH Dimensions 5.118” W x3.150” H x 0.866” D (8x13x2.2cm) Weight 0.09lbs (40 gms) Arrive AirPoint™ - 2011 - BYMG - User Guide...

  • Page 9: System Requirements

    6ft HDMI cable to be able to connect to the display. 3. Ensure the Arrive AirPoint device is situated near an available USB power port . Note: : The unit’s maximum distance for wireless coverage is limited within an unobstructed 12-15 feet circumference.

  • Page 10: Hardware Installation

    3. Connect the Mini-USB end of the USB cable to the AirPoint and the other end to a USB port to provide power. This can be directly from a main electrical outlet using the USB adapter plug, or from the USB port of a laptop/PC, or from an Arrive MediaPoint or HuddlePoint USB charging port.

  • Page 11: User Experience

    4. If present, enter the PIN number here if you are connecting via Intel WIDI. 5. The Arrive AirPoint runs an internal webserver. This is the IP address of that webserver and should be used only by the System Administrator to setup the Arrive AirPoint.

  • Page 12: Setting Up A Connection

    Local Host: xxx.xxx.xxx.xx Figure 6: SSID on top left of the screen A wireless ad-hoc Peer-to-Peer (P2P) WiFi connection to Arrive AirPoint devices, is a standalone, one way, device-bound wireless network connection. Arrive AirPoint™ - 2011 - BYMG - User Guide...

  • Page 13: Apple Airplay Wireless Mirroring In P2P Connection

    AirPlay Mirroring enables users of certain AirPlay compatible devices to display whatever is on their device’ screen on AirPlay compatible Arrive AirPoint. This allows users to show presentations, websites, videos, or other content from their device on to a big screen display that the Arrive AirPoint device is attached to.
  • Page 14 Figure 7: Activate WiFi from settings 1. The Arrive-AP SSID (in this example, the SSID is Arrive-AP 278) should appear on the list as an active access point. This is the same SSID that is indicated on the display splash-screen.
  • Page 15 Figure 9: Tap on AirPlay mirroring on the utilities screen 3. The Arrive AP (shown as SSID on the AirPoint splash screen) wireless mirroring from the Apple device to the display using AirPoint is now enabled. Everything on the Apple device now displays on the screen wirelessly.

  • Page 16: Wifi Direct - Miracast Wireless Mirroring In P2P Connection

    Setting up a connection Figure 11: Arrive AirPoint recognized as an Airplay device Note: In this mode, the Apple device will have no Internet access. If you have a 4GLTE or 3G GSM data enabled phone or device, the Internet connection is possible via the data plan.

  • Page 17: Android Wireless Display (Android 4.2 Or Higher )

    For other Android devices, check with your device specifications for this feature. 2. The Arrive AP will be listed on the Screen Mirroring page. Tap on the AP to connect. Figure 13: Screen mirroring connection Copyright © 2017 Arrive Systems, Inc. All rights reserved.

  • Page 18: Intel Widi Application

    3. Once connected, users will be able to mirror device content on the screen. Figure 14: Disconnect device from Arrive AP The connection is 1-on-1 : One device to one Arrive AirPoint Receiver at a time. The connected device has to disconnect before another device can connect.

  • Page 19: Windows 8.1/10 Wireless Display

    Miracast. To actually project to a Miracast device, tap or click the “Add a wireless display” option. Select the ARRIVE-AP*** from the list of devices. Selecting your receiver begins the secure pairing of your Windows 8.1/10 device to the Miracast receiver. After pairing is finished, you’ll be able to project your full Windows 8.1/10 experience wirelessly onto...
  • Page 20 Figure 18: Windows 10 - Select AirPoint with SSID from the list 4. 4. If MAC address is required, select the MAC address on the default Arrive AP splash screen. If a WPS PIN is required, enter the WIDI PIN provided on the Arrive AP splash screen.

  • Page 21: Advanced Wifi Enabled Connection

    Miracast is enabled on your device. Advanced WiFi enabled connection Figure 21: WiFi connected Mode In an advance WiFi mode, the Arrive AirPoint device will connect to the network through an access point. Copyright © 2017 Arrive Systems, Inc. All rights reserved.

  • Page 22: Connecting The Arrive Airpoint Device To A Wifi Network

    PCs etc). Select the AirPoint device (which must have the same SSID provided on the splash screen) on your laptop. By default, the SSID for the device is “Arrive-APXXX” with no security code.
  • Page 23 Below are the directions to connect the Arrive AP using the Setup: 1. From the Setup page, the WiFi Connection shows “On” and shows the Arrive-AP under the Device Name (SSID), in this example “Arrive-AP 774”which should match the Arrive AP SSID shown on-screen.
  • Page 24 5. The device will then connect to the network. Figure 26: Device connecting to network 6. The Arrive AirPoint device is now connected to the network. 7. Once connected, the AirPoint device shows a splash screen that it is now connected to the network.
  • Page 25 The second way to access Setup on the Airfun utility is by clicking on the Remote control icon and accessing Setup within the remote control UI. Below are the directions to connect the Arrive AP using the Setup under the virtual remote control UI: Figure 28: Remote interface 1.
  • Page 26 Virtual AP only – Devices connected to the AirPoint device network can only access the AirPoint device . Save Change: Remember to save all changes made on the initial setup in order to apply said changes. Arrive AirPoint™ - 2011 - BYMG - User Guide...

  • Page 27: Advanced Setup Menu Using Airfun Utility

    Return button to go to the previous page or standby screen. 7.1 Network Click on Network to access settings for WiFi Connection and Virtual AP Setup. Figure 30: Setup page Figure 31: Network options Copyright © 2017 Arrive Systems, Inc. All rights reserved.

  • Page 28: Wifi Connection

    Wireless APs (see below). Choose the AP you wish to connect to (in this example, we are connecting to “Network 1-Guest”. This will bridge the Arrive AirPoint device to the network via your WiFi network. Please ensure that the wireless AP has Internet Access available, and you have a password to connect to the same.
  • Page 29 The input history on the right side of the keyboard shows previously entered characters. Figure 33: Virtual Keyboard Figure 34: Arrive AP Device connecting to the network 4. Once WiFi network password is accepted, the Arrive-AP device will connect to the network. Copyright © 2017 Arrive Systems, Inc. All rights reserved.

  • Page 30: Virtual Ap Setup

    Figure 35: Virtual AP Setup 2. Once inside the Virtual AP setup, set the parameters as needed for Wireless Security/ Password/Region and Save Changes to apply. Figure 36: Virtual AP parameters Arrive AirPoint™ - 2011 - BYMG - User Guide...
  • Page 31 WPA Key would require the setting up of a password for the Arrive-AP. When WPA Key is selected, for instance, it will show under Network/Wireless Security page. Open System is the default for an Arrive AP when the Network Setup is first accessed. Copyright © 2017 Arrive Systems, Inc. All rights reserved.
  • Page 32 Figure 38: Select WPA Key Figure 39: WPA Key as selected parameter in Wireless Security Note: Please consult the Arrive AirPoint Network Deployment Guide for more about P2P and Network connections. Arrive AirPoint™ - 2011 - BYMG - User Guide...
  • Page 33 6 up to 63 characters in length. The virtual keyboard (see Figure 32) will automatically open so administrators can type and set the password. Figure 41: Region setting Copyright © 2017 Arrive Systems, Inc. All rights reserved.

  • Page 34: Audio

    Surround sound setting and Lip Sync setting from this page. Figure 43: Audio settings Adjust advanced audio settings such as Night mode, HDMI Audio output format, SPDIF output format, Surround sound setting and Lip Sync setting from this page. Arrive AirPoint™ - 2011 - BYMG - User Guide...

  • Page 35: Video

    Adjust Aspect Ratio, TV System, Video Output, and other video settings from the video setup page. Figure 44: Video settings 7.4 System Set the OSD Language,reset to Factory Default, check the firmware Version, and perform a firmware upgrade from the system setup page. Figure 45: System settings Note: For OTA and USB upgrade, please refer to the AirPoint OTA upgrade guide. Copyright © 2017 Arrive Systems, Inc. All rights reserved.

  • Page 36: Assign Web Console Password

    Advanced Setup Menu using Airfun utility 7.5 Assign web console password 1. Go to device Setting - WIFI - Choose Arrive SSID **** Figure 46: Device settings-WiFi 2. Go to splash page from browser for the Airpoint Local host ARRIVE-AP***...
  • Page 37 1. Open the settings page by clicking on the settings/gear icon). Figure 48: Setting button 2. From Settings page, choose Modify Password . 3. Type a new password and press OK. Figure 49: Change password Copyright © 2017 Arrive Systems, Inc. All rights reserved.

  • Page 38: Change The Ssid Name

    5. To test, open local host from another browser (or close and reopen current browser). Login with the new password. Figure 51: Login with modified password 7.6 Change the SSID Name 1. Go to device Setting - WIFI - Choose Arrive SSID **** Figure 52: Available WiFi connections Arrive AirPoint™ - 2011 - BYMG - User Guide...
  • Page 39 Local Host: xxx.xxx.xxx.xx Figure 53: AirPoint Local host 3. From the browser, type local host to open Airfun. Open the settings page by clicking on the settings/gear icon). Figure 54: Setting button Copyright © 2017 Arrive Systems, Inc. All rights reserved.
  • Page 40 Figure 55: Device Name SSID 5. The new SSID will show, press OK to confirm modification. Figure 56: Modified SSID 6. To check, go to device setting (ex. smartphone), select WIFI to view list of connections, including the newly added SSID. Arrive AirPoint™ - 2011 - BYMG - User Guide...

  • Page 41: Add Signage

    Figure 58: Connect USB 2. Press the frequency toggle switch for approximately 60 seconds. The image should display on screen when the device is not used/or is idle. Figure 59: Toggle switch button -END- Copyright © 2017 Arrive Systems, Inc. All rights reserved.

  • Page 42: Additional Resources

    Arrive CarePoint Support Services Thank You for choosing us to serve you. Your suggestions for Arrive AirPoint™ are welcome. To make a technical support request, please contact ARRIVE Technical Support at our support page: http://arrivesys.com/support/#contact The peripheral product warranty related to AirPoint enabled devices can be found at http://www.arrivesys.com/warranty.
  • Page 43 This page left intentionally blank. Copyright © 2017 Arrive Systems, Inc. All rights reserved.
