AVT Bigeye G
Technical Manual
AVT Cooled CCD Cameras
V2.1.0
2013-July-08
Allied Vision Technologies GmbH
Taschenweg 2a
D-07646 Stadtroda / Germany

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVT Bigeye G and is the answer not in the manual?

Questions and answers

Summary of Contents for Allied AVT Bigeye G

  • Page 1 AVT Bigeye G Technical Manual AVT Cooled CCD Cameras V2.1.0 2013-July-08 Allied Vision Technologies GmbH Taschenweg 2a D-07646 Stadtroda / Germany...
  • Page 2: Legal Notice

    Legal notice Trademarks Unless stated otherwise, all trademarks appearing in this document of Allied Vision Technologies are brands protected by law. Warranty The information provided by Allied Vision Technologies is supplied without any guarantees or warranty whatsoever, be it specific or implicit. Also excluded are all implicit warranties concern- ing the negotiability, the suitability for specific applications or the non-breaking of laws and pat- ents.
  • Page 3: Table Of Contents

    Contents Contacting Allied Vision Technologies ........... 5 Introduction ......................7 Document history......................7 Manual overview ......................7 Conventions used in this manual ..................9 Styles ........................9 Symbols ........................9 More information ......................10 Before operation......................10 Safety warnings ......................11 Bigeye G GigE cameras ..................12...
  • Page 4 Index ...........................54 Bigeye G Technical Manual V2.1.0...
  • Page 5: Contacting Allied Vision Technologies

    38 Washington Street Newburyport, MA 01950, USA Toll Free number +1 877-USA-1394 Tel: +1 978-225-2030 Fax: +1 978-225-2029 e-mail: info@alliedvisiontec.com Allied Vision Technologies Asia Pte. Ltd. 82 Playfair Road #07-02 D’Lithium Singapore 368001 Tel: +65 6634-9027 Fax: +65 6634-9029 e-mail: info@alliedvisiontec.com...
  • Page 6 Contacting Allied Vision Technologies Bigeye G Technical Manual V2.1.0...
  • Page 7: Introduction

    Manual overview This manual overview outlines the contents of each chapter of this manual. • Chapter Contacting Allied Vision Technologies on page 5 lists AVT contact data (phone numbers and URLs) for both: – Technical information / ordering – Commercial information...
  • Page 8 Introduction • Chapter Introduction on page 7 (this chapter) gives you the document history, a manual overview (short description of each chapter) and conventions used in this manual (styles and symbols). Furthermore, you learn how to get more information on AVT GigE Installation Manual, available AVT software (incl.
  • Page 9: Conventions Used In This Manual

    Introduction Conventions used in this manual To give this manual an easily understood layout and to emphasize important information, the following typographical styles and symbols are used: Styles Style Function Example Bold Programs, inputs or highlighting bold important things Code listings, camera output etc. Output Courier Command Courier bold...
  • Page 10: More Information

    Introduction More information For more information on hardware and software read the following: • AVT GigE installation manual describes the hardware installation proce- dures for the AVT GigE cameras (Manta/Bigeye G). Additionally you get safety instructions and information about camera interfaces (GigE port, I/O connector, inputs and outputs).
  • Page 11: Safety Warnings

    Introduction Safety warnings Caution Electrostatic discharge The camera contains sensitive electronic components that can  be destroyed by electrostatic discharge. Use sufficient grounding to minimize the risk of damage. Bigeye G Technical Manual V2.1.0...
  • Page 12: Bigeye G Gige Cameras

    All AVT Bigeye G cameras are GigE Vision compliant cameras with a Gigabit Ethernet interface. AVT Bigeye G cameras work with standard Gigabit Ethernet hardware and cables. AVT Bigeye G cameras support cable lengths up to 100 m, using conventional Cat5e or better network cables.
  • Page 13 (currently only Bigeye G-132 and Bigeye G-629) For further information on the highlights of Bigeye G types, the Bigeye G family and the whole range of AVT GigE cameras read  the data sheets and brochures on the website of Allied Vision Technologies: http://www.alliedvisiontec.com/emea/products/ cameras.html...
  • Page 14: Conformity

    Conformity Conformity Allied Vision Technologies declares under its sole responsibility that all stan- dard cameras of the AVT Bigeye G family that this declaration relates to, are in conformity with the following standards or other normative documents: • CE, following the provisions of 2004/108/EG directive •...
  • Page 15: Specifications

    Specifications Specifications Bigeye G-132B Cool / Bigeye G-132B NIR Cool Note The warranty becomes void in case of unauthorized tampering or any modifications not approved by the manufacturer.  Caution Surge To avoid damage caused by surge, connect the camera to an ...
  • Page 16 Specifications Feature Specification Sensor SONY ICX285AL with EXview HAD CCD microlenses Max. resolution (HxV) 1280 x 1024 pixels Sensor type CCD progressive Sensor size Type 2/3 Sensor diagonal 11 mm Effective chip size 8.26 mm x 6.6 mm Cell size 6.45 μm x 6.45 μm Lens mount C-Mount: 17.526 mm (in air);...
  • Page 17 Specifications Feature Specification Exposure time 80077 μs … 4294.97 s in 1 μs increments Binning 2x1, 2x2 Gain 0, +6 dB Gamma 0.45, 0.5, 0.7 available (Note: decreasing ROI does not increase frame rate) Trigger modes Continuous mode (image acquisition with maximum frame rate) IOD mode (Image on Demand: triggered image acquisition) External trigger event Rising edge, falling edge, any edge, level high, level low...
  • Page 18 Specifications Feature Specification Mass (without lens) <1270 g Dimensions (L x W x H) 100.8 mm x 90 mm x 99 mm; incl. connectors, without tripod and lens Regulations CE, RoHS (2011/65/EU) Optional NIR variant Bigeye G-132B NIR Cool Software packages AVT VIMBA SDK AVT PvAPI SDK AcquireControl software (V4.0.0 or greater)
  • Page 19: Bigeye G-283B Cool

    Specifications Bigeye G-283B Cool Note The warranty becomes void in case of unauthorized tampering or any modifications not approved by the manufacturer.  Caution Surge To avoid damage caused by surge, connect the camera to an  AC/DC power supply. Use a certified industrial power supply that complies with common industrial standards.
  • Page 20 Specifications Feature Specification Sensor SONY ICX674ALG with EXview HAD CCD II microlenses Max. resolution (HxV) 1928 x 1452 pixels Sensor type CCD progressive Sensor size Type 2/3 Sensor diagonal 10.972 mm Effective chip size 10.7 mm x 9.2 mm Cell size 4.54 μm x 4.54 μm Lens mount C-Mount: 17.526 mm (in air);...
  • Page 21 Specifications Feature Specification Exposure time 9083 μs … 4294.97 s in 1 μs increments Binning 2x1, 2x2 Gain 0, +6 dB Gamma 0.45, 0.5, 0.7 available (Note: decreasing ROI does not increase frame rate) Video-type auto iris available Trigger modes Continuous mode (image acquisition with maximum frame rate) IOD mode (Image on Demand: triggered image acquisition) External trigger event...
  • Page 22 Specifications Feature Specification Mass (without lens) < 1250 g Dimensions (L x W x H) 100.8 mm x 90 mm x 99 mm; incl. connectors, without tripod and lens Regulations CE, RoHS (2011/65/EU) Software packages AVT VIMBA SDK AVT PvAPI SDK AcquireControl software (V4.0.0 or greater) Table 4: Specification Bigeye G-283B Cool Bigeye G Technical Manual V2.1.0...
  • Page 23: Bigeye G-629B Cool / Bigeye G-629B Nir Cool

    Specifications Bigeye G-629B Cool / Bigeye G-629B NIR Cool Note The warranty becomes void in case of unauthorized tampering or any modifications not approved by the manufacturer.  Caution Surge To avoid damage caused by surge, connect the camera to an ...
  • Page 24 Specifications Feature Specification Sensor Truesense KAF6303E Max. resolution (HxV) 3072 x 2048 pixels Sensor type Full-frame CCD Sensor size Type 35 mm Sensor diagonal 33.229 mm Effective chip size 27.65 mm x 18.43 mm Cell size 9.00 μm x 9.00 μm Lens mount F-Mount: 46.5 mm (in air) maximum protrusion: 26 mm...
  • Page 25 Specifications Feature Specification Exposure time 50688 μs … 4294.97 s in 1 μs increments Binning 2x1, 2x2 Gain 0, +6 dB Gamma 0.45, 0.5, 0.7 available (Note: decreasing ROI does not increase frame rate) Video-type auto iris available Trigger modes IOD mode (Image on Demand: triggered image acquisition) Note A continuous mode is not supported due to the...
  • Page 26 Specifications Feature Specification Mass (without lens) <1390 g Dimensions (L x W x H) 131.55 mm x 90 mm x 109 mm; incl. connectors, without tripod and lens Regulations CE, RoHS (2011/65/EU) Optional NIR variant Bigeye G-629B NIR Cool Software packages AVT VIMBA SDK AVT PvAPI SDK AcquireControl software (V4.0.0 or greater)
  • Page 27: Bigeye G-1100B Cool

    Specifications Bigeye G-1100B Cool Note The warranty becomes void in case of unauthorized tampering or any modifications not approved by the manufacturer.  Caution Surge To avoid damage caused by surge, connect the camera to an  AC/DC power supply. Use a certified industrial power supply that complies with common industrial standards.
  • Page 28 Specifications Feature Specification Sensor Truesense KAI11002 Max. resolution (HxV) 4024 x 2680 pixels Sensor type CCD progressive Sensor size Type 35 mm Sensor diagonal 43.5 mm Effective chip size 36.22 mm x 24.12 mm Cell size 9.00 μm x 9.00 μm Lens mount F-Mount: 46.5 mm (in air) maximum protrusion: 30 mm...
  • Page 29 Specifications Feature Specification Exposure time 1394 μs … 4294.97 s in 1 μs increments Binning 1x2, 2x1, 2x2 Gain 0, +6 dB Gamma 0.45, 0.5, 0.7 available (Note: decreasing ROI does not increase frame rate) Video-type auto iris available Trigger modes Continuous mode (image acquisition with maximum frame rate) IOD mode (Image on Demand: triggered image acquisition) External trigger event...
  • Page 30 Specifications Feature Specification Mass (without lens) < 1320 g Dimensions (L x W x H) 132.8 mm x 90 mm x 99 mm; incl. connectors, without tripod and lens Regulations CE, RoHS (2011/65/EU) Optional NIR variant Software packages AVT VIMBA SDK AVT PvAPI SDK AcquireControl software (V4.0.0 or greater) Table 6: Specification Bigeye G-1100B Cool...
  • Page 31: Spectral Sensitivity

    Specifications Spectral sensitivity Note All measurements were done without protection glass / without a filter.  The margin of error of the QE values is 10%. This is due to: • Manufacturing tolerance of the sensor • Uncertainties in the measuring equipment itself (Ulbricht-Kugel/Ulbricht sphere, optometer, etc.) Figure 1: Spectral sensitivity of Bigeye G-132B Cool Bigeye G Technical Manual V2.1.0...
  • Page 32 Specifications Figure 2: Spectral sensitivity of Bigeye G-283B Cool Bigeye G Technical Manual V2.1.0...
  • Page 33 Specifications Figure 3: Spectral sensitivity of Bigeye G-629B Cool Bigeye G Technical Manual V2.1.0...
  • Page 34 Specifications Figure 4: Spectral sensitivity of Bigeye G-1100B Cool Bigeye G Technical Manual V2.1.0...
  • Page 35: Filters And Lenses

    Filters and lenses Filters and lenses Filters • Monochrome cameras are equipped with a protection glass (without IR cut filter): Transmission > 99 % between 450 nm and 700 nm. Anti-reflective coating on both sides. • NIR cameras: Bigeye G-132B NIR Cool and Bigeye G-629B NIR Cool cameras are equipped with a protection glass: Transmission >...
  • Page 36 Filters and lenses Focal length f / mm Object at distance = 500 mm Object at distance = 1000 mm for Bigeye G-132 Width x Height / mm Width x Height / mm 157 x 125 322 x 257 110 x 88 228 x 182 74 x 59 157 x 125...
  • Page 37 Filters and lenses Focal length f / mm Object at distance = 500 mm Object at distance = 1000 mm for Bigeye G-629 Width x Height / mm Width x Height / mm 111 x 74 249 x 166 75 x 50 177 x 118 49 x 33 126 x 84...
  • Page 38: Camera Interfaces

    Camera interfaces Camera interfaces This chapter gives you information on Gigabit Ethernet port, inputs and outputs and trigger features. Note For a detailed description of the camera interfaces (GigE, I/O connector, status LEDs), and operating instruc-  tions see the Manta/Bigeye G Hardware Installation Guide (How to install a GigE camera: Manta and Bigeye G), Chapter Camera interfaces.
  • Page 39: Camera I/O Connector Pin Assignment

    Camera interfaces Camera I/O connector pin assignment Note The I/O port of a Bigeye G camera is different to the one provided with a Bigeye P camera.  Bigeye G cameras have a 20-pin Mini D Ribbon (MDR) shielded I/O connector with screw-locks. Figure 5: 20-pin Mini D Ribbon (MDR) shielded I/O connector Pin Signal Direction Level...
  • Page 40: Control Signals

    Camera interfaces Pin Signal Direction Level Description 15 Camera Out 2 Open emitter, Camera Output 2 max. 20 mA (GP Out 2) 16 Camera In 2 Max. 24.0 V Camera Input 2 (GP In 2) 17 Camera In 4 3.3 V TTL Camera Input 4 (GP In 18 --- Reserved...
  • Page 41: Input/Output Pin Control

    Camera interfaces Input/output pin control All input and output signals running over the camera I/O connector are con- trolled by the I/O strobe commands. See AVT GigE GenICam Feature Descrip- tion and AVT GigE Vision Cameras. Outputs Note For a general description of the outputs and warnings see the AVT GigE Installation Manual.
  • Page 42: Trigger Timing Diagram

    Camera interfaces Output mode selectable via software Polarity selectable via software AcquisitionTriggerReady FrameTriggerReady Read from software FrameTrigger Exposing FrameReadout Opto- Output signal Acquiring SyncIn1 Coupler SyncIn2 SyncIn3 SyncIn4 Strobe1 Figure 7: Output block diagram Trigger timing diagram The following diagram explains the trigger concept in general. Figure 8: Trigger timing diagram Bigeye G Technical Manual V2.1.0...
  • Page 43: Notes On Triggering

    Camera interfaces Notes on triggering Trigger definitions Term Definition User trigger Trigger signal applied by the user (hardware trigger, software trigger). Logic trigger Trigger signal seen by the camera internal logic (not visible to the user). Propagation delay between the user trigger and the logic trigger.
  • Page 44 Camera interfaces • The start of exposure must always correspond with the interline time if Readout is true. • Exposure start delay equals the Readout time minus the registered expo- sure time. Triggering during the idle state For applications requiring the shortest possible trigger latency and the smallest possible trigger jitter the user trigger signal should be applied when Imaging is false and Idle is true.
  • Page 45: Description Of The Data Path

    Description of the data path Description of the data path Block diagrams of the cameras The following diagrams illustrate the data flow and the bit resolution of image data after being read from the CCD sensor chip in the camera. The individual blocks are described in more detail in the following manual: AVT GigE Camera Controls.
  • Page 46: Available Bigeye G Camera Controls

    Description of the data path Available Bigeye G camera controls The following camera controls are available. The controls are displayed the way they are seen on the GigE Sample Viewer. Hierarchy level 1 Hierarchy level 2 Hierarchy level 3 Hierarchy level 4 Info CameraName DeviceFirmwareVersion...
  • Page 47 Description of the data path Hierarchy level 1 Hierarchy level 2 Hierarchy level 3 Hierarchy level 4 Acquisition Trigger AcqEnd AcqEndTriggerEvent AcqEndTriggerMode AcqRec AcqRecTriggerEvent AcqRecTriggerMode AcqStart AcqStartTriggerEvent AcqStartTriggerMode FrameRate FrameStart FrameStartTriggerDelay FrameStartTriggerEvent FrameStartTriggerMode FrameStartTriggerOverlap FrameStartTriggerSoftware AcquisitionAbort AcquisitionFrameCount AcquisitionMode AcquisitionStart AcquisitionStop RecorderPreEventCount ImageFormat Height...
  • Page 48 Description of the data path Hierarchy level 1 Hierarchy level 2 Hierarchy level 3 Hierarchy level 4 Controls DSPSubregionBottom DSPSubregionLeft DSPSubregionRight DSPSubregionTop Gamma Exposure ExposureMode ExposureValue Gain GainValue IODMode Iris IrisAutoTarget Note This feature is implemented in the  IrisMode firmware, but is not applicable due to IrisVideoLevel...
  • Page 49 Description of the data path Hierarchy level 1 Hierarchy level 2 Hierarchy level 3 Hierarchy level 4 EventControls EventID EventAcquisitionStart EventAcquisitionEnd EventFrameTrigger EventExposureEnd EventAcquisitionRecordTrigger EventSyncIn1Rise EventSyncIn1Fall EventSyncIn2Rise EventSyncIn2Fall EventSyncIn3Rise EventSyncIn3Fall EventSyncIn4Rise EventSyncIn4Fall EventOverflow EventError EventNotification EventSelector EventsEnable1 ConfigFile ConfigFileIndex ConfigFileLoad ConfigFilePowerUp ConfigFileSave Table 14: Available Bigeye G camera controls...
  • Page 50 Description of the data path Hierarchy level 1 Hierarchy level 2 Hierarchy level 3 Hierarchy level 4 GigE BandwidthCtrlMode ChunkModeActive NonImagePayloadSize PayloadSize StreamFrameRateConstrain Ethernet DeviceEthAddress HostEthAddress DeviceIPAddress HostIPAddress GvcpRetries Gvsp GvspLookbackWindow GvspResendPercent GvspRetries GvspSocketBuffersCount GvspTimeout HeartbeatInterval HeartbeatTimeout Multicast MulticastEnable MulticastIPAddress PacketSize StreamBytesPerSecond StreamHold...
  • Page 51 Description of the data path Hierarchy level 1 Hierarchy level 2 Hierarchy level 3 Hierarchy level 4 StatusLed1 StatusLedInvert StatusLedMode StatusLedGpoLevels Strobe Strobe1ControlledDuration Strobe1Delay Strobe1Duration Strobe1Mode SyncIn1 SyncInGlitchFilter SyncIn2 SyncInGlitchFilter SyncIn3 SyncInGlitchFilter SyncIn4 SyncInGlitchFilter SyncInLevels SyncOut1 SyncOut1Invert SyncOut1Mode SyncOut2 SyncOut2Invert SyncOut2Mode SyncOut3 SyncOut3Invert...
  • Page 52 Description of the data path Hierarchy level 1 Hierarchy level 2 Hierarchy level 3 Hierarchy level 4 Stats CCDTemperatureOK StatDriverType StatFilterVersion StatFrameRate StatFramesCompleted StatFramesDropped StatPacketsErroneous StatPacketsMissed StatPacketsReceived StatPacketsRequested StatPacketsResent Table 14: Available Bigeye G camera controls Bigeye G Technical Manual V2.1.0...
  • Page 53: Frame Memory

    Description of the data path Frame memory An image is normally captured and transmitted in consecutive steps. The image is taken, read out from the sensor, digitized and sent over the Gigabit Ethernet network. Bigeye G cameras are equipped with 32 MByte of RAM. The table below shows how many frames can be stored by each model.
