Summary of Contents for Centurion G-SWITCH-22

  • Page 1 G-SWITCH-22 GSM Module G-SWITCH-22 GSM Module G-SWITCH-22 GSM Module nstallation nstallation nstallation uide uide uide MONITORING MONITORING MONITORING AND CONTROL AND CONTROL AND CONTROL...
  • Page 2: Important Safety Instructions

    SIM card will have little or no value should it ever get stolen. Record the IMEI of your G-SWITCH-22 in the blocks provided in Section 6. In the event that the G-SWITCH-22 is stolen, you can use the IMEI number to blacklist the G-SWITCH-22.
  • Page 3 Inputs: Two (reacts to rising edge, falling edge, or both) Should the supply voltage fall to below 10.6V, the G-SWITCH-22 will SMS the Admin Number (first number in the system) that there is a problem with the power supply 6. G-SWITCH-22 GSM Module Identification 12V-24V DC + 12V-24V DC –...
  • Page 4: Wiring Diagrams

    8B. Mount Unit Cover Circuit board 8.2. Remove the cover and unclip the circuit board from the retaining clips. Rawl plug Mounting position Fastener 8.3. Mark position of the unit against the mounting surface. 8.4. Using a 5mm masonry bit, drill a hole into mounting surface. 8.5.
  • Page 5 N/01 COM1 N/02 COM2 G-SWITCH-22 9.5. Output 1 is connected to Trg and will open gate fully. 9.6. Output 2 is connected to Ped and will open the gate to pedestrian opening. 9.7. Input 1 will send an SMS to subscribed numbers when the Beam Alarm is triggered (gate Safety Beams must be activated and 9C.
  • Page 6 PIN-protected. After the initial setup, please insert the SIM into your mobile phone, activate the PIN code protection and then re-insert the PIN-protected SIM card back into the G-SWITCH-22. SIM card housing 10.2. Raise the SIM card housing.
  • Page 7 11. GSM Network Signal Detection When powered up, the G-SWITCH-22 signal strength indicator LEDs will light up indicating the GSM network signal strength. The GSM signal strength can be determined based on the combination of the three LEDs that illuminate:...
  • Page 8 Sharecall 0860-CENTURION (0860 236 887) Head Office: +27 11 699 2400 Sharecall Technical Support 0861 003 123 or +27 11 699 2481 from 07h00 to 18h00 (GMT+2) (Sharecall numbers applicable when dialed from within South Africa only) 0.07.A.0227_01042014 www.CentSys.com...
