PLASMA TV
SERVICE MANUAL
CHASSIS : PD12C
MODEL : 50PZ950S
MODEL :
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL67083603(1103-REV00)
50PZ950G
North/Latin America
Europe/Africa
Asia/Oceania
50PZ950S-ZA
50PZ950G-ZA
Internal Use Only
http://aic.lgservice.com
http://eic.lgservice.com
http://biz.lgservice.com
Printed in Korea
