Summary of Contents for Prokit’s TE-3210B
- Page 1 TE-3210B DC To AC Power Inverter 1000W 50Hz Modify Sine Wave TE-3210B: DC12V to AC220V~240V AC OUTPUT OUTLET User’s Manual Edition 2016 ©2016 Copy Right by Prokit’s Industries Co., Ltd...
-
Page 2: Instruction Manual
Instruction Manual Please read user manual before use. USEFUL APPLICATIONS RUN NOTEBOOK COMPUTERS, RADIOS, TVS, VCRS, LAMPS, FANS, FAX, DRILL ..ETC. SPECIFICATION Input voltage range : DC 10~15V (12V) Input full load current : 100A (12V) Standby input current : <0.6A (12V) Output voltage (AC) : 220V~240V Output waveform : modify sinewave... - Page 3 *The fuse is located inside the DC plug. Please replace fuse with a new equivalent value fuse. 4) Overload caused AC output reduce *Reduce the wattage of loading to lower than 1000 watts. 5) Thermal caused AC output reduce *Under heavy loads for extended periods of time. The AC inverter will reduce output to prevent damage to excess heat.
- Page 4 WARNING SIGNAL Condition Warning signal cycle Shutdown signal cycle Low battery alarm: BI BI BI (pause) BEE BEE BEE (pause) Over heating alarm: BI BI (pause) BEE BEE (pause) Over load alarm: BI BI BI BI BI BI Continuous tone Note: BI is a short beep, and BEE is a longer beep.
- Page 5 ※ AS UPS IF YOU WANT TO USE THIS UNIT AS U.P.S. FUNCTION , TURN ON THE SWITCH OF THE INVERTER AT FIXED POSITON FIRSTLY. WHEN THE BLACK OUT OCCURS IN THE MEANTIME, THE INVERTER WILL DIVERT AUTOMATICALLY FROM HOME ELECTRICITY INTO THE BATTERY SUPPLY POWER...
- Page 6 ※ CHARGER CONNECT AC INPUT POWER CORD TO HOME MAIN SOCKET THEN USE RED BATTERY CORD TO CONNECT (+) OF DC BATTERY TO (+) SINDING POST.AND USE BLACK BATTERY CORD TO CONNECT (-) BATTERY TO (-) SINDING POST. HOME MAIN SOCKET OUTLET BATTERY POWER SWITCH...
- Page 7 BATTERY LED DARK/LIGHT INDICATIVE CHART. BATTERY BATTERY BATTERY BATTERY LIGHT LIGHT LIGHT BLINKS 4.5A 3.5A 2.5A 1.5A 0.5A (24V) 12.5V 13.5V 14.5V (24V) (25V) (26V) (27V) (28V) (29V) 0.2(12V) 0.4(24V) :CHARGER CURRENT INDICATING SIGN NORMAL LIGHTED LED : POWER SWITCH “ ON ” , INVERTER STANDBY NORMAL UNLIGHTED LED : POWER SWITCH “...
- Page 8 IF THE TOTAL WATTS OF ELECTRICAL APPLIANCES EXCEEDS THE OUTPUT CAPACITY OF INVERTER. OR AFTER OPERATING FOR A PERIOD OF TIME. IF THE TEMPERATURE OF THE INVERTER REACHES 60℃, THE INVERTER SHALL BE REDUCED AC OUTPUT BY THE PROTECTION CIRCUIT. 60 C CAUTION * ALWAYS PLACE THE INVERTER IN...
