Biospace InBody 720 User Manual

The precision body composition analyzer
Hide thumbs
Table of Contents

Advertisement

Quick Links

User s Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InBody 720 and is the answer not in the manual?

Questions and answers

Summary of Contents for Biospace InBody 720

  • Page 1 User s Manual...
  • Page 2 This user s manual and product pertinent to this manual may have misprints or technical flaws, which can be modified without prior notice to the readers. Biospace is not liable for any damage caused by a failure to meet the requirements in this user s manual.
  • Page 3 5. Email or phone us if you experience any inconvenience when using the equipment. Forward any clinical inquiries at: E-mail : biospace@biospace.co.kr TEL : 82-2-501-3939 6. Read signs of warning, precautions and notes carefully. The followings are the visual representations of these signs.
  • Page 4 If service is required, contact Biospace or the supplying agency. 8. Individuals with any kind of contagious disease or any kind of injury to the palm or sole must not use or come in contact with this product.
  • Page 5 - Consult the manufacturer or field service technician for help. 2. This product has been designed, manufactured, and inspected under the full quality assurance system of Biospace. Biospace fulfills European MDD ( Medical Device Directive ), and InBody720 has acquired the CE conformity marking.
  • Page 6 INDICATION & SAFETY SYMBOLS A. Indication Manufacturing Year 2005 9pin serial port, (RS232C, Male) Ethernet port (10/100Base-T) USB port (Version 1.1) IEEE 1284 (25pin Parallel), Female (PCL 3, or above; printer) B. Safety signs Dangerous high voltage Danger / Warning /Caution / Note(refer to the safety information) Fuse specification Equipotential terminal BF type equipment...

  • Page 7: Introducing Inbody720 The Body Composition Analyzer

    InBody720 that were not found in the previous body composition analyzers will usher you into a new chapter of body composition. Biospace strives to be your partner for health. We are committed to developing high-quality products through transparent management and continuous research and development.

  • Page 8: Table Of Contents

    CONTENTS HOW TO USE THIS MANUAL SAFTY INFORMATION INDICATION & SAFTY SYMBOLS INTRODUCING InBody720 - THE BODY COMPOSITION ANALYZER Chapter 1 Installation and Maintenance 1. Contents in a Carton 2. Exterior and Functions 3. Installation Instructions 1-10 4. Transportation 1-12 5.

  • Page 9: Chapter 1 Installation And Maintenance

    Chapter 1 Installation and Maintenance 1. Contents in a Carton 2. Exterior and Functions 3. Installation Instructions 4. Transportation 5. Repacking 6. Maintenance...

  • Page 10: Contents In A Carton

    1. Contents in a Carton This product consists of the following units. Make sure your products include all the units. A. Product units InBody720 equipment Hinge cover + pentagonal wrench (6mm) 1 each Fuse holder (1 unit) + fuse (F2.5AL250V; 2 units) + spare fuse 4 units Cables (AC 250V 10A 1.8m) The user s manual CD + Easy Installation Manual 1 each Main Body Cover 1 unit(option)
  • Page 11 Hinge pad 2 units Accessory bag 1 unit To reduce the physical impact on the equipment, use the wrapping material provided by the Biospace during shipment or transit. For information on how to relocate the equipment, refer to the Chapter1, Section 4.

  • Page 12: Exterior And Functions

    2. Exterior and Functions This section introduces the name of parts and their functions. Before installation, check for cracks on the case of equipment. A. Control Part B. Upper Part C. Lower Part D. Rear Part Control Part Rear Part Upper Part Lower Part...
  • Page 13 A. Control part LCD monitor (640 X 480 TFT Color LCD) The monitor displays the status of progress, message or test results. Keypad (20 buttons) The keypad is divisible into input buttons and function buttons.The buttons are used to input data required for body composition analysis, set up the operating environment or to print out test results.
  • Page 14 C. Lower part Front Sole Electrode The patient stands on the foot electrode to come into contact with electricity during testing. Rear Sole Electrode The patient put their heels on this foot electrode to come into contact with electricity during testing. Base Frame (Loadcell) The loadcell is connected to the base frame where the patient stands on.
  • Page 15 (1) Back Cover <Warning sticker> Biospace is not responsible for damages done on the product or injury caused by the user s unauthorized opening of the back cover. Biospace is not responding to any request for repair or upgrade, when damage is done on the warning sticker or there is any indication that the back cover was previously opened.
  • Page 16 Com 1 port is used to connect to the personal computer that runs the Lookin Body. Com 2 port is used for an additional peripheral. Com 3 port is used to hook up the automatic blood pressure monitor provided by the Biospace. LAN Port (10/100 Base-T) Through LAN cable, the equipment can communicate with the external systems including computers.
  • Page 17 (3) Power & Safety Unit Power Socket Plug the 3-pin plug to the power socket to supply the power to the equipment. Fuse Socket The fuse holders (two fuses) are embedded in the equipment. Equipotential Terminal The equipotential terminal can be connected to the external equipotential line to prevent danger caused by the difference in the potentials between the other devices.

  • Page 18: Installation Instructions

    3. Installation Instructions A. Workplace Reguirements (1) Location: Indoor only. Any outdoor area where the equipment is to be located should meet all the environmental requirements. (2) Operating environment: 10 ~40 (50 ~ 104 ), 30%~80% RH (3) Power supply: 100 - 240V~, 50/60Hz B.
  • Page 19 <Un - Leveled State > <Leveled State> (10) Attach the box wrench back to the underneath the hinge cover and put the hinge cover back over the connection area between the upper and lower part. (11) Plug the fuse holder containing the fuse into the fuse socket and then plug in the power to the power socket.

  • Page 20: Transportation

    C. Transporting after installation It is not recommended to move the equipment installed by Biospace or the authorized distributors of Biospace. If it is inevitable to move the equipment, repackage the equipment with the box and wrapping material the equipment came in, to keep the equipment from being damaged during transportation.

  • Page 21: Repacking

    5. Repacking Prior to un-assembling and repackaging the equipment, turn the power off and pull the plug off the outlet. Take appropriate precautions not to damage foot and hand electrode during repackaging. (1) The writings on the box should be on top, when it is ready to be opened. Open up the box from the top.

  • Page 22: Chapter 2 Management & Results Description

    Chapter 2 Management & Results Description 1. Cautions Before Measurement 2. Exterior and Function of Keypad 3. Power Connection & Getting Started 4. Initial Screen and Input 5. Personal Profile 6. Proper Posture 7. How to Operate the Equipment 8. Results...

  • Page 23: Cautions Before Measurement

    1. Cautions Before Measurement To observe changes of the human body through body composition analysis, it is crucial to perform the analysis each time under the same conditions, temperature, posture, etc. Bear in mind, the following factors affect the result of body composition analysis, and as a result, affect the reproducibility of analysis.

  • Page 24: Exterior And Function Of Keypad

    2. Exterior and Function of Keypad The keypad as illustrated below is divided into two sections by their functions. A. Input Button (15 buttons) Number buttons (0~9) / Alphabet buttons (A ~ Z) The input buttons are used to enter numeric and character data such as the patient s age, height and I.D.

  • Page 25: Power Connection & Getting Started

    3. Power Connection and Getting Started (1) Plug the power cable to the outlet. (2) Once power is turned on the equipment, the LCD monitor displays a sequence of characters, indicating the sequential process of loading up the operating system to the system. This is equivalent to the process through which PC loads up windows to the memory and gets the operating systems ready for the user.
  • Page 26 (4) When the system boots up, the initial screen comes up, allowing the user to enter data into the system.

  • Page 27: Initial Screen And Input

    4. Initial Screen and Input The Initial screen in the InBody720 provides a variety of the functions for the convenience of the patient and the user. The configuration of Initial screen is categorized into four groups by function. A. Personal Information Window This area is where the personal information of the patient including I.D.

  • Page 28: Personal Profile

    5. Personal Profile Age, height, weight and gender are the key personal information required to analyze the body composition. To reduce the probabilities of an error and to obtain reliable results, follow the instructions presented below. A. I.D. (permissible range of input : 20 characters) Use the numeric buttons to enter data.
  • Page 29 You can correct the data, when the input data is incorrect. Error occurs with key operation prior to the entry of data. Press the backspace key ( ) to delete the entry and enter data again. Error occurs with the text field data entries before the current text field. Use the direction button ( ) to move to the text field where an error occurs and press the backspace key ( ) to delete the existing data and re-enter data.

  • Page 30: Proper Posture

    6. Proper Posture Observing the following methodology is essential to achieving reliable results and accuracy. Palms, fingers and soles should be in contact with electrode during the testing. Keep the following instructions in mind during testing. A. How to hold hand eletrodes (1) Four fingers should be touching the surface of the electrode as shown below.
  • Page 31 Excessive moisture may cause an erosion of electrode, which in turn may result in breakdown of the equipment. The electrolyte tissues provided by the Biospace are specifically manufactured for InBody and thus is completely different from the generic wet tissues in the market. It is strongly recommended to use the electrolyte tissues specifically designed for InBody720.

  • Page 32: How To Operate The Equipment

    7. How to Operate the Eguipment This procedure begins with the Initial screen, which is the initial environment settings of the InBody720, when it is factory-released. The InBody720 goes back to the Initial screen, as the patient steps down from the stand. (1) See if the InBody720 is in test-ready status.
  • Page 33 (5) Enter the patient s personal information including I.D. height, and gender using the keypad buttons. After finishing the data entry, press the Enter button and see the information windows prompting the patient to get ready for a test. (6) Follow the test instructions displayed on the information windows. InBody720 checks your posture on the equipment continuously.
  • Page 34 (7) During the, the analysis result windows on the LCD monitor will display the results of body composition analysis in the order of the test procedure. Analysis results window (8) When the analysis is completed, the InBody720 informs that the test is completed through the information windows.

  • Page 35: Results

    8. Results A. Analysis result window During the test, information on body composition analysis is displayed on Analysis result window on the LCD monitor. As long as the patient is on the stand, the monitor retains the data of the body composition analysis. Once the patient steps down, the InBody720 goes back to the initial screen and sets itself back to test-ready status.
  • Page 36 Chapter 5 Consumables. As for the installation of a printer, consult the user s manual provided by the printer manufacturer. (2) Result sheet Form The results sheet is shown below. It is one of the consumable products provided by Biospace.
  • Page 37 (2) User Information The name of the hospital or clinic and the doctor in charge are displayed here. Please contact Biospace Co., Ltd. or sales division if you need to enter or correct User Information (3) Body Composition Analysis(9 items)
  • Page 38 Weight (kg) Generally, BMI 18.5~25 is used for determining normal range of weight. But in InBody 720, normal range for Weight is standard weight 15% of standard value, and the range is very similar to the one based on BMI (18.5~25). Standard weight is determined according to BMI 22 for males, BMI 21 for asian females, BMI 21.5 for western females, and growth chart for the age under 18.
  • Page 39 (5) Obesity Diagnosis Obesity Diagnosis offers indexes for the diagnosis of the extent of obesity. BMI (Body Mass Index, kg/m BMI is determined by using only weight and height and diagnoses superficial obesity. The standard values are 22kg/m for male and 21.5kg/m for western female and 21kg/m for Asian female.
  • Page 40 Waist-Hip Ratio Waist-Hip Ratio (WHR) is obtained from dividing your waist size by your hip size and it is used for looking at the proportion of fat stored on your body around your waist and hip. The normal range of WHR is 0.80~0.90 for male and 0.75~0.85 for female.
  • Page 41 (7) EDEMA EDEMA means an excessive accumulation of serous fluid in tissue spaces, which results in swelling. This graph shows the ratio of ECW to TBW and ECF to TBF. The normal range of this score is 0.36 ~ 0.40 and 0.31 ~ 0.35 respectly, which is maintained in a healthy person.
  • Page 42 (10) Weight Control(4 items) InBody720 calculates a Target Weight. This is not merely showing an ideal weight. Instead, the calculation of the target weight is based on the complete evaluation of the body composition diagnosis. Apart from the fact that the conventional standard weight is a height specific, and population-based statistical information, Target Weight is personalized information based on InBody720 measurement.
  • Page 43 (13) Additional Data(6 items) This section shows you commonly used data, related to body composition. Obesity degree(%) Obesity Degree, measured in percentage, is a convenient way of assessing the subject s degree of obesity but body composition is not considered. Obesity degree is calculated using only a subject s weight.

  • Page 44: Chapter 3 Setup Establishment

    Chapter 3 Setup Establishment 1. Setup Menu 2. Quick Setup 3. DATABASE 4. Modification Example...

  • Page 45: Setup Menu

    1. Setup Menu Press the InBody720 Setup key to bring up the following windows. A. How to modify settings (1) Use the direction buttons ( ) to move and select one option of Environment, Region, Printer, Result Sheet, Result Option, Others and Interface. (2) Use the direction button ( ) at a particular setting to move to the sub- categories.
  • Page 46 B. Setup (1) Environment It shows the environmental status of the InBody720. No items can be changed by users. Environment Summary Language : displays the current language. Result Sheet : displays the number of result sheet automatically printed after measurement. BMI Basis : displays a selected standard range of BMI.
  • Page 47 (4) Result Sheet Mode Select the type of result sheet. Printed : to use printed result sheet provided by Biospace. Built-in : to use plain A4 paper. All formats of the result sheet will be printed out. Number of Result Sheet Printing You can decide the numbers of result sheet automatically printed after measurement.
  • Page 48 (7) Interface Manual DNS, Netmask, Gateway, IP, Host IP : Connect in the same way as connect general PC to the network. DHCP DHCP (Dymanic Host Configuration Protocol) offers IP address and dynamic configuration of related data. When you use the network which uses DHCP server, get instructions from a system administrator.

  • Page 49: Quick Setup

    2. Quick setup User can modify the user environment easily. The changeable items are weight adjustment, results sheet selection, race selection. (1) How to modify the quick setup Press the EXIT / MODE button in the startup window. Select the item to change. - Use the Left, Right direction button ( ) to select the item.

  • Page 50: Database

    3. DATABASE Press the DATABASE key on the Keypad to bring up the archive windows as shown below. The cursor is located in the I.D. search field. Type key words or a set of characters in the text field and press the enter key to search the archive data. To search through the entire archive, press the direction button( ).

  • Page 51: Modification Example

    Select Printed using the direction buttons ( After you press EXIT/MODE button 3 times, the screen asking whether you want to save modified setting will pop up. Press Enter button to quit setup. Use the printed result sheet provided by Biospace only.

  • Page 52: Chapter 4 Problems And Solutions

    Chapter 4 Problems and Solutions 1. Error Messages 2. Trouble Shooting 3. Frequently Asked Questions ( FAQs ) 4. Customer Service Information...
  • Page 53 1. Error Messages The InBody720 displays the following error messages to warn the user of the problems it runs up against during operations and to guide the users to take steps. The following is the most common error messages and the steps to handle the corresponding errors.
  • Page 54 2. Trouble Shooting This section lays out the order of steps you have to take for each particular problem, on the assumption that you have some basic knowledge on how to operate the InBody720. If you still have the problem after taking the following steps, contact our customer service representatives listed in the warranty certificate appended to the end of this user s manual.
  • Page 55 The measurements don t seem right. (When the measurements seem too high or too low) Cause 1 The patient loses contact with the electrodes or fails to maintain the recommended posture during the testing. Step 1 Refer to the Chapter 2, section 6.Proper posture to correct the patient s posture and maintain the recommended posture until after the testing is finished.
  • Page 56 Can an amputee or people who cannot stretch their hands or feet to the electrode be tested? It is impossible to test people who cannot contact the electrode. Biospace has a lineup of products that conduct body composition analysis on the patients in bed, without having to get patients out of bed during the tests.
  • Page 57 Can the jewelry or other metallic wear affect the testing? The ideal test methodology is where the patient doesn t wear anything metallic. As the weight of clothes and other wear affects the results of body composition analysis, it is strongly recommended to take off any heavy clothing or metallic wear.
  • Page 58 4. Contomer Serivice Information Corporate agents of InBody720 and addresses are listed below. Contact us for assistance or more information about InBody720. Biospace Co., Ltd. 10th Floor, Poonglim Bldg., 823 Yeoksam 1-dong, Gangnam-gu, Seoul 135-784 KOREA Tel : 82-2-501-3939 Fax:82-2-501-3978 Homepage : http://www.biospace.co.kr...

  • Page 59: Chapter 5 Consumables

    Chapter 5 Consumables 1. Consumables 2. Basic Equipment 3. Options...
  • Page 60 The following diagram and specifications describe the properly functioning electrolyte tissue. If you find any abnormality or defects with the tissue, stop using it and contact the Biospace head office or one of the distributors to get it replaced with the normal tissues.

  • Page 61: Basic Equipment

    Deskjet 920C/5550/3820 Only the printers that have one of the chipsets listed in the above table or support PCL3 or higher are compatible with the InBody720. Use the printers recommended by the Biospace. B. Printer desk The printer desk makes for the optimal printing environment, with drawers where you can put results sheets, convenience and the minimized vibration during printing.

  • Page 62: Options

    3. Options Biospace provides optional devices to make the operation of InBody720 more efficient and convenient. For more information, contact the head office or authorized distributors of Biospace. A. Lookin Body Lookin Body is a database management software, which stores the measurement results generated by InBody720.

  • Page 63: Appendix

    Appendix 1. More About InBody720 2. Classifications 3. Specification 4. Worldwide Patents LIMITED WARRANTIES...
  • Page 64 1. More About InBody720 A. Principles of Bioelectrical Impedance Analysis (BIA) Bioelectrical Impedance Analysis (BIA) is based on the fact that organs and tissues of human body work as semi-conductor or a non-conductor electronically. In general, 50~60% of human body is comprised of water, which functions as a conductor.
  • Page 65 The body composition analyzer InBody720 is precision clinical diagnostic tool featuring the world-leading technology of Biospace. The advanced technology used in the InBody720 is recognized both in Korea and abroad, as Biospace obtained CE for exports to Europe and signed a technology royalty agreement with Yamato of Japan.
  • Page 66 C. Outputs Intracellular Water ( ) Extracellular Water ( ) Total Body Water ( ) Protein Mass (kg) Mineral Mass (estimated value, kg) Body Fat Mass (kg) Soft Lean Mass (kg) Fat Free Mass (kg) Weight (kg) Skeletal Muscle Mass (kg) Percent Body Fat (%) WHR (Waist-Hip Ratio) Lean Balance(kg)
  • Page 67 External Interface RS-232C 3EA, USB Host 2EA, Ethernet(10/100 Base-T) 1EA, IEEE1284 (25pin parallel) 1EA Compatible Printer Laser/Inkjet Printer (with PCL 3 or above, the printers recommended by Biospace) Dimensions 20.4(W) 34.3(L) 47.2(H) : inch (520(W) 870(L) 1200(H) : mm) Machine Weight 99lbs.(45kg)
  • Page 68 4. Worldwide Patens A. International patents 1998. 02 Apparatus and method for analyzing body composition based on bioelectrical impedance analysis Registration number: U.S. 5,720,296 (The United States of America) 2000. 08 Apparatus and method for analyzing body composition using a new electrode system based on bioelectrical impedance analysis Registration number: C.N.

  • Page 69: Limited Warranties

    2. The one year factory warranty begins on the day of purchase. 3. During the one - year warranty period, Biospace remedies any original defect in material or workmanship. 4. The following defects or malfunctions will not be covered under the one year warranty : Any defect caused by user s fault.
  • Page 70 RS-232C 3EA, USB Host (Transferring database to external device) 2EA, Ethernet(10 /100 Base-T) 1EA Printer Interface IEEE1284 (25pin parallel, with PCL 3 or above), USB Compatible Printer Laser / Inkjet Printer (the printers recommended by Biospace) Dimensions 20.5(W) 34.3(L) 47.2(H) : inch 520(W) 870(L) 1200(H) : mm Machine Weight 99lbs.(45 )
  • Page 72 InBody-the product of great technology Experience its speciality...
  • Page 73 InBody is chosen by experts Biospace has been striving to improve human health; it has explored new InBody has been praised by the world s medical professionals realms of body composition analysis, leading the health care market with with its power to analyze and its clinical reliability. Biospace...
  • Page 74 Nutrition clinic/Geriatric clinic InBody is used to analyze nutritional and health conditions for patients with wasting disease, geriatric disease, chronic disease and children in growth period. In particular, using broadband multi-frequencies, it provides a precise Product diagnosis on patients nutritional status. www.biospace.co.kr...
  • Page 75 Various Results based on measurements Examinee and institution Edema You can advertise your center effectively. It displays The graph shows the ratio of ECW to TBW and ECF to TBF. personal information of examinee entered and hospital or Edema score of healthy person is maintained in normal range. clinic name, doctor name and the address.
  • Page 76 www.biospace.co.kr...
  • Page 77 Weight Range 10 to 250 kg (max 39.5 stone) Body Composition Analysis InBody 720 gives a quantitative value for the various body compartments which equals the weight of each compartment, when added together they equal the person’s weight. The values can also be compared with the ‘normal’ values.
  • Page 78 Mineral InBody analyzes two groups of minerals: osseous mineral and non-osseous minerals. Osseous mineral is bone mineral whereas non-osseous minerals are those found in all other parts of the body. Osseous mineral accounts for about 80% of the body’s total minerals. Mineral mass is closely related to soft lean mass.
  • Page 79 HOW TO APPLY THIS RESULT TO YOUR CLIENTS Draw a line joining the end of each bar graph line. Different body types, based on a balanced body composition In the case of this body type, the body composition graphs form a slightly curved ‘D’.
  • Page 80 Athletes are usually included in the overweight muscle type. As such, such people can easily be included in the obese category when BMI alone is used. This person does not need to undertake weight control measures. Obesity Diagnosis InBody720’s obesity diagnosis uses BMI (Body Mass Index) and PBF (Percent Body Fat) to determine obesity levels. BMI (Body Mass Index, ㎏/㎡) The formula is BMI= Weight (kg)/Height ).
  • Page 81 Lean Balance InBody720 measures the soft lean mass of the body segments. There are two bar graphs for each body part in the Lean Balance graph. The two graphs have different meanings. The number at the end of the upper bar graph is the amount in Kg of soft lean mass in each area. If the upper bar graph reaches 100%, it means that the person has ideal soft lean mass for his or her ideal weight.
  • Page 82 Fitness Score Every body starts off at 80; you then lose points for too much fat or too little muscle, and gain points for more muscle. Used as a motivational scoring tool. As body composition changes with exercise, the fitness score should increase. Lacking muscle or overweight.
