OPERATING INSTRUCTIONS

for the labelcutter and labelfinisher

Secabo LC30

Congratulations on the purchase of your Secabo labelcutter!

Please carefully read the operating manual to easily integrate your unit into your production

environment.

Any type of reproduction of this operating manual requires the written permission of Secabo

GmbH. Changes and errors in the technical data and the product characteristics are reserved.

The Secabo GmbH is not liable for any direct or indirect damages occurring as a result of the use

of this product.

Version 1.0 (01.03.2017)

Table of Contents

Need help?

Do you have a question about the LC30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Secabo LC30

Page 1 Any type of reproduction of this operating manual requires the written permission of Secabo GmbH. Changes and errors in the technical data and the product characteristics are reserved. The Secabo GmbH is not liable for any direct or indirect damages occurring as a result of the use of this product.
Page 2: Safety Measures
● Always place the unit on a stable base to prevent it from falling down. ● Do not operate the unit during thunderstorms; it can be damaged or destroyed by lightning. Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
Page 3: Items Included
Power cable USB connection cable Blade holder Pen holder Drag knife 30°, 45°, 60° Clamping element Fence element Acrylic glass plate Rubber feet Certificate of DrawCut license Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
Page 4 Strip edge for excess foil g) Dancer roller for winding finished labels h) Control panel cutting unit Cutting unit Dancer roller for winding k) Electricity connection and switch Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
Page 5: Control Panel
DrawCut will be installed. The activation can also be performed via another computer. In order to control your LC30 via your computer, install the software as described in the following: ● Disable the Windows Firewall as well as your anti-virus software for the duration of the installation.
Page 6 Initial operation of machine ● Unpack the LC30 labelcutter and place it on a stable surface. Avoid lifting the unit by its shafts and axes. Instead, only lift it by its base plate at the bottom. ● Mount the supplied rubber feet by lifting the unit on one side and, one by one, screwing the feet into the holes provided for this purpose from the bottom.
Page 7: Installing And Adjusting The Blade
● Connect the LC30 to a 230 V socket via the supplied power cable. ● Now connect the LC30 to the computer on which you previously installed DrawCut LabelStudio using a USB cable. ● Now switch on the device. Installing and adjusting the blade ●...
Page 8 Calibration of the LC30 via DrawCut LabelStudio Laser offset calibration The laser's offset must be calibrated prior to the first use of the Secabo LC30. ● Open the spooler in Drawcut Labelstudio ● Click on "Auto Calibrate Laser Offset" in the spooler's header...
Page 9 ● {ut1}Now place a white sheet of paper into the LC30, equip the cutter head with the included pen holder and position the origin approximately in the center of the inserted page! Next, confirm the software request by clicking Yes! ●...
Page 10 ● Upon successfully completing the calibration, the software will return the measured laser offset! Confirm the value by clicking OK! This value will also be stored in the cutter settings! Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
Page 11 Secabo drag knives. ● The most important basic settings are now saved and you can begin finishing your print job previously created with Drawcut LabelStudio. Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
Page 12 ● Make sure that the clamping lever of the cutting device is open when the loading the foil, i.e. so that the medium in the cutting head won't be guided. Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
Page 13: Cutting Test
● After inserting the foil as described above, operate the dancer roller for the winding for finished labels by hand and run 1-2m of material through the LC30 by doing so to allow the medium to straighten itself.
Page 14: Settings And Operation
Now confirm the zero point by pressing the crosshair, which will cause the device to automatically switch to online mode. Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
Page 15 ➜refer to Manual Drawcut Label Studio Starting a cutting job from DrawCut Label Studio First, insert the already printed medium in the Secabo LC30 as described above. Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
Page 16 ● Use the laser button inside the LC30's control panel to manually switch on the laser, position it directly on a mark on the wall side of the LC30 and set the source here. ● Open the Spooler in LabelStudio ●...
Page 17 ● Now simply enter the job ID into the dialog box that opened. One place you can find this is between the crop marks on the printout you created. ● Click on Cut Labels. The cutting process will start automatically! Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
Page 18 ● For thicker materials, use knives specially suited for it (e.g. flock knife for flock). ● Frayed edges after cutting the foil indicate a blunt drag knife. Replace worn blades immediately! Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
Page 19: Technical Data
+5°C - +35°C / 30% - 70% relative humidity Weight without packaging 75kg Weight with packaging 110kg Dimensions (W x H x D) 103cm x 50cm x 67cm Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
Page 20: Statement Of Conformity
98/37/EC Directive on machinery (from 2009-12-29: 2006/42/EC) Standard: EN 60204-1:2006 Technical documents at: Secabo GmbH, Hochstatt 6-8, 85283 Wolnzach, Germany Dipl. Ing. Fabian Franke Dipl. Ing.(FH) Bernhard Schmidt Secabo GmbH | Hochstatt 6-8 | 85283 Wolnzach | Germany | mail@secabo.com | www.secabo.com...
