  • Page 1 Matrix-510 Linux ARM9 Industry Box Computer User Guide Version 1.0 Copyright © Artila Electronics Co., Ltd. All Rights Reserved.

  • Page 3: Table Of Contents

    3.11 Network Settings ......................... 6 3.12 Wireless LAN Configuration ....................6 3.13 File System ......................... 7 3.14 Devices List ......................... 8 3.15 Utility Software ........................8 Artila Utility Software ....................9 update ..........................9 setuart ..........................9 lcdctl ............................ 9 gpioctl ..........................10...
  • Page 4 Tone ..........................10 mp3play ..........................11 How to Make More Utility Software ................... 11 Mounting External Storage Memory ................. 11 4.10 Welcome Message ......................11 4.11 Web Page Directory ......................12 4.12 Adjust the System Time ....................12 4.13 SSH Console ........................12 4.14 Install GNU Toolchain .......................

  • Page 5: Introduction

    Matrix-510 User Guide 1. Introduction Matrix-510 is an ARM9-based Linux ready industrial computer. The key features are as follow:  ARM920T ARM Thumb Processor with 200MIPS at 180MHz, Memory Management Unit  16-KByte Data Cache and 16-KByte Instruction Cache ...

  • Page 6: Layout

    Matrix-510 User Guide 2. Layout Reset Button 12.5 167.5 ‧2‧...

  • Page 7: Pin Assignment And Definition

    The Power LED will show solid green if power is properly applied. 3.3 Ready LED The Ready LED will show solid green if Matrix-510 complete system boot up. If Ready LED is off during system boot up, please check if power input is correct. Turn off the power and restart Matrix-510 again.

  • Page 8: Serial Console Port

    Matrix-510 User Guide Pin No. RS-232 RS-422 RS-485 TXD+ DATA+ TXD- DATA- RXD+ RXD- 3.8 Serial Console Port Serial console port share the connector with Serial port 3 but the pin definition as shown as follow: Pin No. RS-232 The serial console port is disabled as factory default setting. To enable the serial console, you need to use the serial console cable and connect it to port 3.

  • Page 9: Digital I/O Port (Db25 Female)

    Matrix-510 User Guide 3.9 Digital I/O Port (DB25 Female) Pin No. RS-232 Pin No. Function DIO0 DIO13 DIO1 DIO14 DIO2 DIO15 DIO3 DIO16 DIO4 DIO17 DIO5 DIO18 DIO6 DIO19 DIO7 DIO20 DIO8 DIO9 DIO10 VCC3 DIO11 VCC5 DIO12  Note VCC3: 3.3 VDC output...

  • Page 10: Factory Default Settings

    For infrastructure mode XXXX is the access point name and YYYYYYYY is the encryption key and MMMM should be managed. For Ad-Hoc mode mode XXXX is the Matrix-510 device name and YYYYYYYY is the encryption key MMMM should be ad-hoc.

  • Page 11: File System

    & or ifconfig wlan0 192.168.2.127 netmask 255.255.255.0 3.13 File System Matrix-510 configures the root file system as RAMDISK and the user disk (/disk) which includes /home and /etc directory are configured as Flash Disk. To find out the file system information, please use command /mount as show as above.

  • Page 12: Devices List

    5. ttyUSB0 to ttyUSB1: USB RS-232 adaptor (fdti_sio.ko) 6. rtc: Real Time Clock 7. gpio: General Purpose digital I/O 8. ttyACM0 and ttyACM1: USB Modem (CDC compliant) 3.15 Utility Software Matrix-510 includes busybox utility collection and Artila utility software as follow: ‧8‧...

  • Page 13: Artila Utility Software

    Matrix-510 User Guide 4. Artila Utility Software The introduction of Artila utility software as follow: 4.1 update Update loader, kernel or root file system image. Also use update —FORMAT to format user disk. Type update—help to find the command usage.

  • Page 14: Gpioctl

    Matrix-510 User Guide 4.4 gpioctl gpioctl is used to control the programmable digital I/O port located on the DB25 connector. Following example is to configure DIO1 as digital input and DIO2 as digital output with low output state. 4.5 vplay vplay is used to play audio file in wave format.

  • Page 15: Mp3Play

    You might also find utility software available on Artila FTP under /Matrix 510/utility such as ntpclient, ssh, scp, bluez and ssh-keygen. If you want, you can ftp or copy the utility software to Matrix-510 user disk (/disk). Also you can use find the source code and use the GNU Toolchain to make the utility by yourself.

  • Page 16: Web

    /ntpclient [time server ip] 4.13 SSH Console Matrix-510 support SSH. If you use Linux computer, you can use SSH command to login Matrix-510. The configuration of SSH and key are located at /etc/config/ssh The key generation program is available on Artila FTP: /matrix 510/utility/ssh_keygen User can copy this program to Matrix-510 to generate the key.

  • Page 17: Install Gnu Toolchain

    Matrix-510 toolchain. #tar zxvf arm-linux-3.3.2.tar.gz 4.15 Getting Started with the Hello Program There are many example programs on Artila FTP. To compile the sample you can use the Make file to and type: make To compile and link the library. Once done, use ftp command ftp 192.168.2.127...
