Introduction
Thank you for choosing the CT-2000ES inverter unit, this inverter unit is suitable for operating squirrel cage
induction motors. Please read this instruction manual carefully before actual usage in order to ensure proper
operation and suit your needs.

Table of Contents

1. Inspection upon receiving...............................................................................................
2. Installation and Storage............................................................
A. Installation ...........................................................................................................
B. Storage...............................................................................................................
C. Outline dimension..................................................................................................
3. Application notes...........................................................................................................
4. Block diagram and wring ...............................................................................................
A. Wiring of main and control circuit ..............................................................................
.
B
Signal circuit.....................................................................
.
C
.
D
R.S.T. for Power source reactor............................................................................
.
F
Standard external connection diagram......................................................................
.
G
Control circuit specification....................................................................................
.
H
Terminal specifications.........................................................................................
5. Operation Test........................................................................
6. Adjust and Function Specification...................................................................................
.
A
Keypad operation................................................................................................
.
B
Display specification.............................................................................................
C. Keypad specification............................................................................................
D. Function Code....................................................................................................
7. Description of alarm display indications .......................................
8. Troubleshooting............................................................................................................
9. Maintenance and Inspection...........................................................................................
10. Standard Specification..................................................................................................
A. 200V series 1 phase..............................................................................................
B. 200V series 3 phase..............................................................................................
C. 400Vseries 3 phase...............................................................................................
11. Function code Table..................................................................................................
12. Modbus Address of Display Data..............................................
13. Series Communication User Manual................................................................................
A. The physical link...................................................................................................
B. Data structure in communication...............................................................................
C. Function code in Modbus........................................................................................
D. Error check generation...........................................................................................
E. Group & global broadcasting....................................................................................
.................................................................
02413.281.181-0989.984.666
................................ 2
.............................
............................
...............................
............................... 43
................................ 53
2
2
2
3
4
4
4
4
4
..
5
5
. 6
.
7
.
8
9
.. 11
11
11
11
13
44
. 45
46
46
47
48
... 49
54
54
55
56
58
59
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT-2000ES and is the answer not in the manual?

Questions and answers

Summary of Contents for VIET-TRUNG CT-2000ES

  • Page 1: Table Of Contents

    02413.281.181-0989.984.666 Introduction Thank you for choosing the CT-2000ES inverter unit, this inverter unit is suitable for operating squirrel cage induction motors. Please read this instruction manual carefully before actual usage in order to ensure proper operation and suit your needs.

  • Page 2: Inspection Upon Receiving

    90% or less. Avoid installing at places where there is dust, iron particles, corrosive gas, water spray, direct sunlight or too much vibration. And places where has good ventilation. 10cm min 10cm 10cm Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 3: Outline Dimension

    C.TY TNHH TỰ ĐỘNG HÓA VIỆT TRUNG 02413.281.181-0989.984.666 10cm min C. Outline Dimension: CT2002ES-A75、CT2002ES-1A5、CT2004ES-A75、CT2004ES-1A5 CT2002ES-2A2、CT2002ES-3A7、CT2004ES-2A2、CT2004ES-3A7 Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 4: Application Notes

    (3) When motors with brakes are being operated, the power for the brake and inverter should be taken from the same power supply and the brake operation must be in phase when the unit is started and stopped. 4. Block diagram, wring Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 5: Wiring Of Main And Control Circuit

    Where power supply capacity is larger than 500 KVA. b. Using thyrister, phase advance capacitor etc. from the same power supply. A.C.L. Specifications table: Voltage (V) Model Current (Ar.m.s) Induction Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 6: Brake Resistor Standard Of Usage

    If inertia is too large or cycle of discharge is higher, user can increase wattage of resistor. Brake resistor Voltage (V) Type standard CT2002ES-A75 120Ω 80W CT2002ES-1A5 80Ω 160W Mark CT2002ES-2A2 60Ω 250W CT2002ES-3A7 36Ω 400W CT2004ES-1A5 360Ω 300W CT2004ES-2A2 250Ω 500W CT2004ES-3A7 150Ω 800W Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 7: Standard External Connection Diagram

    F. Standard external connection diagram (Note: While external is required for DBR, disconnect inter DBR first) 3-phase power 200V/50Hz 200~230V/50,60Hz 400V/50Hz 400~460V/50,60Hz Adaptor R S T Voltage detect Current detect Transformer Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 8 C.TY TNHH TỰ ĐỘNG HÓA VIỆT TRUNG 02413.281.181-0989.984.666 External Operation controller 5K Ω 1/2W External signal 4~20mA Terminal Terminal Terminal Terminal Reverse operation Forward operation Braking control Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 9 02413.281.181-0989.984.666 Intreface CPU Power Control Operational panel VOUT CC D/A output terminal Multi-function Relay Output terminal Twisted or shield wires RJ45 REMOTE A+ A- B+ B- RS422/485 Series communication interface terminal Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 10: Control Circuit Specification

    C.TY TNHH TỰ ĐỘNG HÓA VIỆT TRUNG 02413.281.181-0989.984.666 G. Control circuit Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 11: Terminal Specifications

    1- COM, set CD10 Select 2 deceleration time mode by shorting 2- COM, set CD11 Shorting 3-COM Shorting 4-COM C1, NC1, Control output terminal Multifunctional relay output terminal Connector capacity AC 220V, 0.1A Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 12: Operation Test

    (3) Make sure there is no loosening of screws. (4) Check external sequence control circuit. (5) Check voltage of power supply. B. Operation Method CT-2000 series inverter unit has both operator panel and external operation methods. (1) Operator panel Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 13 C.TY TNHH TỰ ĐỘNG HÓA VIỆT TRUNG 02413.281.181- 0989.984.666 Panel input CT2000ES (2)External signal operation CT2000ES Switch control C. Operational test Test according to the following procedure and be aware of indications. (1) Basic operational test Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 14 1. Is motor operation direction correct? (Changing any two of U.V.W output terminals to change motor operation direction) 2. Is there any noise or vibration on motor? 3. Is it run smoothly during acceleration and deceleration? 4. Is there any power failure? Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 15: Adjust And Function Specification

    Hz and I LED mean of recent revolution voltage on the display. 2.FWD、REV ： FWD means motor operate at forward direction. REV means motor operate at reverse direction. (3) Keyboard specification： Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 16 Cd- (General parameter input area) or CE- (Failure display and engineering mode). Press and hold ▲,▼ key can progressively increase or decrease value. Parameter modification：Press ▲,▼ key at parameter input mode can Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 17: Function Code

    E. Set external voltage (Cd01=2 or 4) Note: Set value should be in accordance with V/F slope (Cd05) and upper limit frequency (Cd17). Set by function key A. At display function, press READ and setting (Cd01=0) Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 18 Meanwhile the operation speed (Cd00) has been changed but not saved yet (power cut off and supply again Cd00 still be10.00 )，press PROG/SET and save data. READ Use PROG key to input procedure (Cd01=0) PROG/ READ Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 19 The monitor is consisted of four 7-segment LEDs, displays frequency, current and various data by digital number and character. Cd02=0 Display the frequency, LED HZ active Cd02=1 Display the current, LED A active Cd02=2 Display Ultimate speed, Hz and A LED de-active. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 20 Cd04=0 Operation on operation panel 1 ▲▼key no active Cd04=1 Operation by external terminal, including FR, RR, terminal (1, 2, 3, 4) Cd04=2 Operation on operation panel 2 ▲▼key fine tuning frequency Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 21 50HZ 60HZ 50HZ 100HZ 60HZ 120HZ 50HZ 150HZ 60HZ 180HZ 50HZ 200HZ 60HZ 240HZ 87HZ 174HZ 103HZ 206HZ When Cd05=11, V/F slope is determined by Cd57, Cd58 Cd05=12 1.5 power curve Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 22 This function is to raise output voltage to increase torque of motor. It can also be used to increase load slope of low voltage produced by long wiring between inverter and motor, as well as fluid, fan and pump. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 23 FR (or RR) which accommodate terminal 3, 5, the setting value cannot exceed the allowed range. Cd12 = 2 speed setting Cd13 = 3 speed setting Cd14 = 4 speed setting Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 24 Settable range of frequency from 0.5Hz to 30Hz, accuracy is 0.01Hz. Frequency Start Frequency Time Note: The most appropriate range for start frequency is 0.5Hz to 10Hz. Cd17 § Upper limiter of frequency (Selective range 10~240) Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 25 △F: Frequency changed Cd20, 21 § Jump frequency (Settable range 0~240) This function is to avoid mechanical resonance frequency Frequency operation automatically jumps to point ＋/－ jump width (set by Cd22) Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 26 This function must accommodate Cd23, CD24, and Cd26. DC braking torque setting Cd25=1-15, the higher value the higher output brake torque Note: When DC brake voltage is high, be aware of over current. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 27 C.TY TNHH TỰ ĐỘNG HÓA VIỆT TRUNG 02413.281.181- 0989.984.666 Cd26 § DC braking time (Settable range 1~60) Adjust DC braking time Start Frequency Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 28 Cd27=1 both forward and revise directions available, No stop required. Cd27=2 only forward operation is available. Cd27=3 only reverse operation is available. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 29 PCB control circuit, this function is to return to the original setting of speed and frequency after power recovery. Power Supply External Switch Motor Speed Power Failure, Voltage loss 15msec Time needed for Inverter to detect motor free run Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 30 “ON” again to restart if you select external control, if you select panel control, just press “FWD” or “REW” key to restart. Restart motor under free run. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 31 Stop by panel key (Settable range 0~1) Cd30=0 No function Cd30=1 with function Stop function: This function enables the inverter to be stopped by panel key while the inverter is operated by external sequence. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 32 Cd36=1 All of the contents of data will be “nOnE”, display of “LoAd” after setting Note: After this function is active, content value automatically returns to “0”, thus readable value is always “0”. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 33 100%, set voltage to 2V,MAX. Frequency (FH) is 120Hz: Output Frequency = (2V/10V) ×120Hz ×100% = 24Hz If change frequency gain to 150%, then Output Frequency = (2V/10V) ×120Hz ×150% = 36Hz 200% 100% 20mA Analog Setting Signal Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 34 Cd38=99: 99% of initial factory Cd38=101: 101% of initial factory Set Cd54 to select analog output Cd39 § Frequency command bias (Settable range 0~250) External analog frequency command bias setting Output Frequency Setting range Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 35 ○ ○ ○ ○ ○ ○ ○ ○ : Stands for external terminal to put in. Note: Apply to multi-speed setting external control is required for operation control mode (e.g. Cd04=1). Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 36 2. RPM = Frequency ×Cd46 3. If the value overflow, it will show “9999”. Cd47 § Relay 1 output select (Settable range 0~6) The function sets the mode of relay1 to activate. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 37 Function to lock data (Settable range 0, 1) To lock data, prevent errors by none operator. Cd49=0 Data change capable Cd49=1 Data change not capable Cd50 § Software version (Read only) Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 38 If the motor rated voltage 380Vrms. Power supply voltage 380Vrms, then setting Cd51=380/1.73=220, then the inverter output Vrate=380Vrms. c. If the motor rated voltage 460Vrms. Power supply voltage 460Vrms, then setting Cd51=460/2=230, then the inverter output Vrate=460Vrms. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 39 Fb: base frequency Cd52 § Auto voltage compensation (settable range 0.5%~15.0%） The function cannot be modified during revolution. The function is to compensate torque of motor in low r.p.m. Auto voltage compensation Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 40 = 100 / 1800 ×100% = 5.5%, Setting Cd52=55 Slip differential compensation Load variation Time Motor speed Motor speed Output frequency Without slip differential compensation With slip differential compensation With slip differential compensation Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 41 Instantaneous load increase during steady operation and current exceeding over current stall, revolution frequency will drop till current dropped to within stall current level. Normal Status Stall preventive mode Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 42 Maximum frequency setting FH (Settable range 10~240) This function cannot be modified during revolution. When Cd05=11, the maximum frequency V/F slope FH Settable range 10Hz-240Hz Please refer to function code table Cd60. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 43 V / F frequency FC (Settable range 0.5~240) This function cannot be modified during revolution. To set V/F slope frequency FC when Cd05=11. Settable range 10Hz-240Hz (FC ≦Fb) Cd7 VB Cd60 Cd58 Cd57 (HZ) Output Frequency Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 44: Description Of Alarm Display Indications

    Ex: Cd62 = 30, PWM Frequency = 3.0KHz Cd63 § Start frenquency of auto voltage compensation（Settable range 3.0〜20.0HZ） The function cannot be modified during revolution. This function is the point of motion to assume auto compensation voltage start Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 45 This function is to adjust instant initial field current of motor. Shorter of the time is higher of the field current. Cd65 Instant initial field time 64mS 128mS 256mS 512mS 1024mS 2048mS 4096mS Output Frequency Set frequency DC braking frequency in stopping Cd24 Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 46 Increasing the figure to stabilized frequency while noise of external analogue input is higher. Decrease the figure when inverter required to response faster. Cd 66 Digital filter time 4 ms 8 ms 16 ms Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 47 400V series: protection point voltage (VDC)= Cd70 ×400V ×% ×√2 Description of alarm display indications Cd71 § Over Voltage prevention function active point (Settable range 130~150) This function cannot be modified during revolution Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 48 This function can’t be modified during revolution. Setting of Baud rate during communication Cd82=0 2400 bps Cd82=1 4800 bps Cd82=2 9600 bps Cd82=3 19200 bps Note: Re-start inverter after setting Baud rate. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 49 Setting waiting time for response when inverter receive correction data. MODBUS RESPONE TIME=4ms * CD83 Cd90 § Series communication parameter store eeprom（settable range 0〜1） Cd90=0 unstore Cd90=1 store one data and reset 0 Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 50 CE18 14 step speed setting CE19 15 step speed setting CE20 16 step speed setting CE21 ~ CE36 § Multi-step process control time setting（settable range 0 - 100Min） Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 51 CE47=1 Gradually operation. (Perform time can set to zero, when perform time set to 0, perform time will according to CD08, CD09 increase or decrease. If the step frequency set to 0, the step will be ended.) Liner operation Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 52 The function cannot be modified during revolution Selection of shut down or start from 1 step while entire operation procedure finished. CE49=0 Not continuous operation. CE49=1 Continuous operation. From 1st steps’ speed continuous operation. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 53 P e rfo rm s p e ed a s th e la s t s p e e d in th e s te p , till the R S T o r C E 48 s e t to 1 , th e n c h a ng e to firs t s tep ’s s p e e d to c o n tin u o u s o pe ra tio n Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 54 3. Make sure this parameter setting does not conflict with the setting for Cd01 (Set frequency source). Ex: If Cd01=1 then the parameter CE61 cann’t be modify to 2, 4 or 7. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 55 02413.281.181-0989.984.666 Description of alarm display indications CE62 § Proportion gain (settable range 0~10.0) This parameter specifies proportional control and associated gain (P). Bottom freq. Cd58 CE67 CE61 CE62 CE63 Output limit Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 56 Operation error Was the unit operated as indicated in the manual Use the correct procedure Operation error of internal ROM, RAM Switch off the power and then apply Replace the unit again Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 57 Improve the voltage condition and confirm inverter model Exchange the cooling fan Lower the ambient temperature Check the load conditions Overload detected for Increase the capacity of the Is the motor being overloaded more than one Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 58: Troubleshooting

    Terminals of inverter and motor Banish circuit shorted or ground connection is started. (Overcurrent protects operation during acceleration.) (U.V.W.) circuit shorted or ground connection Overload Reduce the load or increase inverter capacity Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 59 “OL” is displayed Overload Reduce load or increase inverter capacity during inverter operation “OH” is displayed during inverter Is inverter over current limiter appropriate Check if the cooling fan is still working Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 60: Maintenance And Inspection

    Once a year 1. Use clean, dry air to remove dust buildup from the guards, the stack and the cooling fan. 2. Check for parts burns or damage and make any exchanges necessary. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 61: Standard Specification

    EMI (with CT2000ESe only) Relay Output Arrival with timer, failure, stop, acceleration, frequency equal, deceleration, over frequency Frequency setting Digital setting by keypad, or external analog signal（DC0〜10V，DC4〜20mA） Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 62: 200Vseries 3 Phase

    DC Injection Braking（Setting mode, torque, time, active frequency） Standard feature Free run restart, jogging speed, upper/lower frequency limit setting, jump frequency setting, 8-step speed setting, frequency indicated output (DC0〜10V), operation direction setting, Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 63: 400Vseries 3 Phase

    Digital setting: ±0.1% Analog setting: ±0.5% (35℃) Frequency accuracy Frequency resolution Digital setting: 0.5〜100Hz→0.01Hz 100Hz〜240Hz→0.1Hz Analog setting: (setting value/1000)Hz Frequency range 0.5〜240HZ（Initial frequency 0.5〜30Hz） V/F ratio 10 pattern, or any V/F pattern Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 64: Function Code Table

    Note 3: Braking resistor specification refer to page 5 ＊: Under development 11. Function Code Table Function Detail of Data Initial factory setting MODBUS Address Set frequency 0~240Hz Frequency setting procedure Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 65 13: V/F 1.7 power curve 14: V/F square curve Motor rated current 25~100% 0.0~15.0% Torque boost 0.1~6000 (S/50HZ) acceleration time 0.1~6000 (S/50HZ) deceleration time 0.1~6000 (S/50HZ) acceleration time 0.1~6000 (S/50HZ) deceleration time Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 66 DI2 External terminal setting DI31 External terminal setting DI4 External terminal setting 0: No motion 1: 2DF 5：2DC 2: 3DF 6：JOG 3: 5DF 7：MBS 4: 2AC 8：RST Memory clear for fault annunciation Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 67 0: P.W.M. Frequency set by Cd62 1: 4KHZ 2: 5KHZ 3: 6KHZ 4: 7KHZ 5: 8KHZ 6: 9KHZ 7: 10KHZ P.W.M. Frequency 2 15~160 Start frequency of auto voltage compensation 3.0~20.0HZ Dynamic braking mode Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 68 Cd90=1 store one data and reset 0 Function Detail of Data Initial factory setting MODBUS Address CE00 None Fault annunciation (The last) CE01 Fault annunciation (Before the last) None Fault annunciation (The 2 before the CE02 Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 69 Multi-step function continuous operation selection CE52 Multi-step function time error adjust CE53 All Files Restore CE54 File copy Target Feedback De-active CE67 PI control CE61 Target value/feedback terminal select CE67 KEYPAD KEYPAD Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 70: Modbus Address Of Display Data

    Bit4, 3, 2, 1, 0= Failure 0:None 4:OCPA 5:OCPd 6:OCPn 8:OV 10:OH 12:OL 14:OC 15:PLU 16:OL2 17:BuOH IN 1(0~20mA) 0~1023 IN 2(0~10V) 0~1023 KEYPAD (0~10V) 0~1023 Automatic procedure control operation time 0~999 1min Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 71: The Physical Link

    The wiring of this product can use either RS422 (4 wires) or RS485 (2wires), by jumper. Figure Single RS422 Pin 1-2 short 13-1 Single RS485 Pin 2-3 short 13-2 INVERTER INVERTER ……………….. A+ A- B+ B- A+ A- B+ B- 1/2W 150Ω Master Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 72: Data Structure In Communication

    Char ‘ 8 ’ ‘ 9 ’ ‘ A ’ ‘ B ’ ‘ C ’ ‘ D ’ ‘ E ’ ‘ F ’ ASCII code Char ‘ : ‘ Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 73: Function Code In Modbus

    The maximum parameters supported by various controller models are listed on page. Ex: Read data from 3 continuous addresses in register. The beginning address is 0080H, the data frame are listed as follow. Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 74 LRC (2 chars) CRC (16 bits) Trailer CR LF None Total Bytes (2)Function 06H：preset signal register Presets a value into a single holding register (4 x reference). When broadcast, the function Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 75 0000 0000 Register Address Lo 1000 0000 Preset Data Hi 0001 0111 Preset Data Lo 0777 0000 Error Check LRC (2 chars) CRC (16 bits) Trailer CR LF None Total Bytes Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 76: Error Check Generation

    CRC16 == CRC16 XOR DATA FOR (j=1;j=8;J++) /* BIT LOOP */ IF (CRC16 AND 0001H) = 1 THEN CRC16 == (CRC16 SHR 1) XOR POLYNOMIAL; ELSE CRC16 == CRC16 SHR 1; Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...

  • Page 77: Website: Www.viet-Trung.com.vn Đ/C: 194- Nguyễn Trãi- Võ Cường-Tp.bắc Ninh

    33…48 Group 4 49...64 Group 5 65...80 Group 6 81…96 Group 7 97…112 Group 8 113...128 Group 9 129...144 Group 10 145...160 Group 11 161...176 Group 12 177...192 Group 13 193...208 Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
  • Page 78 C.TY TNHH TỰ ĐỘNG HÓA VIỆT TRUNG 02413.281.181-0989.984.666 Group 14 209...224 Group 15 225...240 Website: www.viet-trung.com.vn Đ/c: 194- Nguyễn Trãi- Võ Cường-TP.Bắc Ninh...
