Summary of Contents for Optical Systems OSD1250
- Page 1 OPERATOR MANUAL OSD1250 SELF HEALING RING DUPLEX DATA TRANSCEIVER...
-
Page 3: Table Of Contents
FIGURE 5: LED FRONT PANEL INDICATORS................14 FIGURE 6: BUS CONFIGURED SYSTEM ..................15 FIGURE 7: RING CONFIGURED SYSTEM ..................15 TABLE 1: OSD1250 SPECIFICATIONS ....................8 TABLE 2: SWITCH SETTINGS ......................10 TABLE 3: DATA I/O CONNECTION ....................11 TABLE 4: LED INDICATOR FUNCTIONS .................. -
Page 4: Technical Summary
The OSD1250 card is designed to mount in the OSD350N or OSD370N chassis. The OSD1250C is designed to mount on a flat surface .The OSD1250 operates from an unregulated DC supply of +12 to 24V @ 6VA. -
Page 5: T Ypical D Esign A Pplication
1 second. This ensures that a faulty unit cannot monopolise the bus for more than 30% of the time. The OSD1250 does not require any special settings for user data rates from 300bps to 2Mbps (25% distortion max). -
Page 6: Figure 1: Basic Block Diagram
OPTICAL SYSTEMS DESIGN FIGURE 1: BASIC BLOCK DIAGRAM PAGE 6 DOC ID: 10106110 OSD1250 OPERATOR MANUAL... -
Page 7: Frame Structure
RS232 or RS422 signals. Translation between RS232 and RS422 is possible. The OSD1250 generates Data Set Ready only when it detects the adjacent units are in their correct operating state. The OSD1250 does use Data Terminal Ready as true input to determine if DTE is operational. -
Page 8: Specifications
128W x 142D x 50H (Card) Weight 350g (card), 500g (module) Operating Temperature -20C to 70C Relative Humidity 0 to 95% non-condensing Power Requirements +9 to 30V @ 6VA 102125005 TABLE 1: OSD1250 SPECIFICATIONS PAGE 8 DOC ID: 10106110 OSD1250 OPERATOR MANUAL... -
Page 9: Installation And Operating Instructions
OPTICAL SYSTEMS DESIGN 2 INSTALLATION AND OPERATING INSTRUCTIONS This section briefly outlines the steps required to install and operate the OSD1250 successfully. It should be studied carefully to avoid undue damage to the equipment and poor operation. This equipment has been fully tested before dispatch and is ready for immediate operation. However, it is advisable to check for external transportation damage before operation. -
Page 10: Switch Settings
The OSD1250 card version requires DC power which is connected via a DB9 connector and supplied by the OSD370N or OSD350N chassis. The card should be fixed into the chassis using the captivated screws. The cards can be plugged in or out of the chassis with power on or off. -
Page 11: Data I / O Connection
OPTICAL SYSTEMS DESIGN DATA I/O CONNECTION The OSD1250 Interface Card uses HDB26 connector. The data formats supported are RS232, RS422, RS485, and RS485 4- wire. Signal RS232 Pin RS422 Pin RS485 Pin RS485 4W Pin GND PIN 1 TXD2 RXD2... -
Page 12: Alarm
ALARMS The OSD1250 has an open drain MOSFET rated at 200mA @ 50V max on pin 26 of the DB26 connector. Output at pin26 is 0Ω when unit is powered and ring/bus fiber link present. The output at pin26 becomes high impedance on all units on ring/bus when any fiber link is broken or the unit is off along the ring/bus. -
Page 13: Optical Power Level S
▲ Laser equipment should be positioned above or below eye level where possible. Apertures should be positioned away from personnel. ▲ Protective eyewear should be worn in the vicinity of laser equipment. The standard OSD1250 is designed to operate with no adjustment to transmit power levels over distances from zero to maximum link. PAGE 13... -
Page 14: Osd1250 Indicators
When set as a Master or as Slave and repeating User Data Orange Optical data is transmitted to fiber from copper No data is being transmitted to fiber TABLE 4: LED INDICATOR FUNCTIONS PAGE 14 DOC ID: 10106110 OSD1250 OPERATOR MANUAL... -
Page 15: Figure 6: Bus Configured System
1250 SLAVE 1250 SLAVE 1250 SLAVE 1250 SLAVE MASTER INTERFACE INTERFACE INTERFACE INTERFACE INTERFACE 3 + n.. In WDM systems only one fiber connects between adjacent units. FIGURE 7: RING CONFIGURED SYSTEM PAGE 15 DOC ID: 10106110 OSD1250 OPERATOR MANUAL... -
Page 16: Maintenance
OPTICAL SYSTEMS DESIGN 3 MAINTENANCE The following section briefly outlines the faultfinding procedures for the OSD1250 modem. Please take note of the following: Personnel without considerable technical training should not attempt any maintenance other than that outlined below. If further maintenance is attempted than which is outlined below, you are warned that every care should be taken to ensure that internal measurements made while the equipment is running are taken carefully. -
Page 17: Warranty
For warranty period, please call your local OSD distributor. REPAIRS Optical Systems Design reserves the right to repair or replace faulty modules/units. Please obtain a “Return Material Authorisation” (RMA) form and number before returning goods. Goods must be returned in adequate packing material to Optical Systems Design, Warriewood or its nominated authorised representative, for all repairs. - Page 18 OPTICAL SYSTEMS DESIGN PAGE 18 DOC ID: 10106110 OSD1250 OPERATOR MANUAL...
- Page 19 OPTICAL SYSTEMS DESIGN PAGE 19 DOC ID: 10106110 OSD1250 OPERATOR MANUAL...
- Page 20 OPTIC L Optical Systems Design Pty. Ltd. 7/1 Vuko Pl. Warriewood 2102 P.O. Box 891 Mona Vale SYSTEMS N.S.W. Australia 2103 Telephone: +61 2 9913 8540 Facsimile: +61 2 9913 8735 DESIGN Email: sales@osd.com.au Web Site: www.osd.com.au PTY LTD A.B.N. 83 003 020 504...
