- Page 1 DeWils Guide to Designer Series Framed Cabinetry Installation www.dewils.com...
- Page 2 This is the point to which the tops of the base cabinets should be level. Because DeWils customizes cabinet heights, it is best to unwrap one of the cabinets and measure from the bottom of the toe kick to the top of the cabinet to determine how far up from the high spot you should strike the Base Level line.
- Page 3 DeWils Industries, Inc.- July, 2008 Next, locate the wall studs using either an electronic or magnetic stud finder or by measuring in 16” increments starting in a corner or next to a doorway. Ordinarily, studs are located 16” apart (from the center point to center point of the stud) in each wall.
- Page 4 Beginning with the doors, loosen the appropriate screw, adjust the door into position and tighten the screw again. DeWils Designer series cabinets uses two main types of hinges with the most prominent one pictured at left. Repeat this until all doors are adjusted properly.
- Page 5 DeWils Industries, Inc.- July, 2008 Wood Drawer Box Adjustments Tandem Installation, removal and adjustment information DeWils reserves the right to make changes to products without notice...
- Page 6 Twist the chrome rods clock wise or counter clock Note: drawer heads 8” and larger will have one rod per side. Drawer heads 12” and larger will have 2 rods per side DeWils reserves the right to make changes to products without notice. July, 2008...
