No.5224-F15A

Please read all instructions thoroughly before operation.

The contents are subject to change without prior notice due to product improvements and specification changes.

Thunder Tiger Corporation guarantees this model sub to be free from defects in both material and workmanship.

The total monetary value under warranty will in no case exceed the cost of the original sub purchased. This

warranty does not cover any components damaged by use or modification. Part or parts missing from this sub must

be reported within 60 days of purchase. No part or parts will be sent under warranty without proof of purchase.

To receive part or parts under warranty, the service center must receive a proof of purchase and/or the defective

part or parts. Should you find a defective or missing part, contact the authorized Thunder Tiger Service/Distributor

nearest you. Under no circumstances can a dealer or distributor accept return if the operation has started.

Table of Contents

Need help?

Do you have a question about the Ocean Master and is the answer not in the manual?

Questions and answers

Summary of Contents for TTRobotix Ocean Master

Page 1 No.5224-F15A Please read all instructions thoroughly before operation. The contents are subject to change without prior notice due to product improvements and specification changes. Thunder Tiger Corporation guarantees this model sub to be free from defects in both material and workmanship. The total monetary value under warranty will in no case exceed the cost of the original sub purchased.
Page 2: Table Of Contents
As the pump fills the ballast with water, the Ocean Master could dive without anyway assistant from sails planes and the power unit. This gives the Ocean Master an advantage to stay in water static for long hours. The powerful propulsion system and large surface planes allows the Ocean Master glide through water gracefully.
Page 3: Content
CONTENT Check all contents as the list below, contact authorized dealer if there is any part missing. Action Camera Controller & Submarine Charger & Cable Mount w/CCD Monitor Holder Tool Bag 20M Cable Front Cap & Hood Monitor TOOLS MAY NEED FOR Needle Nose Pliers MAINTENANCE Thread Locking Glue...
Page 4: Configuration
CONFIGURATION Switch-Power On Verticle Stabilizer Front Cap & Hood Switch-Not in Used Rudder Charging Plug Propeller Front Elevator Water Inlet/Outlet hole Rear Elevator Clips...
Page 5: Radio Control Vs Ocean Master Movement
RADIO CONTROL vs OCEAN MASTER MOVEMENT Forward Backward Throttle Pump Operation: Floating / Diving Dive: Pump water into the ballast Surface: Drain water out from the ballast Right turn Steering Left turn (Forward) Nose up Elevator Nose down (Forward) NOTE: The control of the Seawolf is similar to Mode 2 of RC airplanes: throttle is at the left stick and elevator is at the right one.
Page 6: Charge
CHARGE 4. Connect the balance lead as shown. 1. Take the Seawolf Ocean Master out from the carry box. Remove the front protection foam and keep the foam in a safe place. The bullet weight will come off if submarine is nose down.
Page 7: Monitor
1. Press "Power" for 5 seconds to turn on the monitor. 2. The monitor screen should pick up the signal from Seawolf Ocean Master immediately. If not, check all the 9. Use "<" and ">" button to select "NTSC M". Press "Enter"...
Page 8: Camera Installation
CAMERA INSTALLATION 1. Install your Action Camera in place, as it is tight fit so user may pull the front plate of the camera mount for easier d. Install the camera with its waterproof case and secure with installation. Make sure the camera is all the way in. the its hand screw.
Page 9: Hood/Front Cap Installation
HOOD / FRONT CAP INSTALLATION 1. Lock the front cap and hood to place. Make sure that the notch on the hood is lined up with the clips and locked firmly. 2. As the cap needs to be tight fit to the collar for deep waterproof, it is a little bit hard to install at this step.
Page 10: Connection
CONNECTION UPSIDE DOWN Finally turn on the Ocean Master. The main power switch is located at the bottom of the front flange. From the bottom view, 1. Connect the Seawolf Ocean Master and controller with the right switch controls the main power while the left switch is the cable (Included).
Page 11: Buoyancy Check & Weight Adjustment
ADJUSTMENT Seawolf Ocean Master performs the best when it is balanced properly with correct water line. Check the balance and waterline of the Seawolf Ocean Master before operation. Use the bullet–style steel weight to trim the balance of the Seawolf Ocean Master. The waterline should be near the deck of the Seawolf Ocean Master.
Page 12: Pre-Launch Check
● Find a good launch location, with the possibility to stand stable with no risk of falling into the water. The water surface should be easily reachable and must not be too low. Be careful with tide. ● Lift the Seawolf and gently place it into the water. NEVER DROP Seawolf Ocean Master into water as it might cause structural damage.
Page 13: Operation
Seawolf submerged. The opposite command will let the pump to empty the ballast and the Seawolf will raise to the surface. 3. Seawolf Ocean Master will begin to dive in 10 seconds after the pump activate. The water ballast will be full in 20 to 30 seconds.
Page 14: Cautions
● Place the Seawolf in the water, check any bubbles released from the Seawolf. When the water bubbles observed, retrieve the Seawolf Ocean Master IMMEDIATELY. ● The water ballast should be full in less than 1 minute. If the Seawolf Ocean Master failed for static diving, please retrieve the Seawolf Ocean Master and inspect the problem at once.
Page 15: Maintenance
3. Remove the outer hull panels and clean every part. 4. Before storing the Ocean Master for a long time keep the inner hull open and disconnect the fuse. 5. Check the fail safe system (switch off the controller and see if the protection system activates).
Page 16 SPARE PARTS PJ6102 CONE PJ6140 CONTROL ARM SET PJ6141-1 SERVO HORN & ROD PJ6155 RR ELEV. MOUNT TUBE PJ6157 WEIGHT MOUNT ROD PJ6160 WEIGHT/B(2),WT740G PJ6161 O-RING(2),Ø124MM PJ6162 O-RING(2),Ø120MM PJ6164 SEALED RUBBER/S(4) PJ6165 CONE RUBBER(20) PJ6168-1 RUBBER FEET PJ6169 LINKAGE ROD SET PJ6180 O-RING(2),Ø119MM PJ6183 WEIGHT(4),WT120G PJ6408-1 OUTER HULL-L...
Page 17 SPARE PARTS PJ6421 WEIGHT/C(2),WT540G PJ6427 PROPULSION MOTOR PJ6428 FRONT CAP PJ6429 HOOD PJ6431-1 ACTION CAMERA HOLDER PJ6432 CLIP PJ6430 HANDLE SET PJ6431 GOPRO HOLDER PJ6433 BULLET WEIGHT-SHORT PJ6433-1 BULLET WEIGHT-MEDIUM PJ6433-2 BULLET WEIGHT-LONG PJ6434 CONNETING CABLE 2540S-1 E6AC CHARGER<US> 5002 CARRY BOX 5004 FLASHLIGHT 5003 20M CABLE 2540S-2 E6AC CHARGER<EU>...
Page 18: Spare Parts List
SPARE PARTS LIST PART# DESCRIPTION NOTE PJ6102 CONE PJ6140 CONTROL ARM SET PJ6141-1 SERVO HORN & ROD PJ6155 RR ELEV. MOUNT TUBE PJ6157 WEIGHT MOUNT ROD PJ6160 WEIGHT/B(2),WT740G PJ6161 O-RING(2),Ø124MM PJ6162 O-RING(2),Ø120MM PJ6164 SEALED RUBBER/S(4) PJ6165 CONE RUBBER(20) PJ6168-1 RUBBER FEET PJ6169 LINKAGE ROD SET PJ6180...
Page 19: Declaration Of Conformity
Declaration of Conformity according to 2014/30/EU For the following equipment: Product Ocean Master Type Designation/Trademark 5224-F / TTRobotix Manufacturer’s Name Thunder Tiger Corp. Manufacturer’s Address No.7, 6th Road, Industry Park, Taichung, Taiwan 40755 EUROPEAN COUNCIL Directive 2014/30/EU and the technical standards...
Page 20 This product is not a toy. Before you assemble and use this product, More information can view the tutorial videos on our please read this manual thoroughly. TTR official website (www.ttrobotix.com) or YouTube channel This product and its contents may different from the graphics shown (https://www.youtube.com/user/ThunderTigerVideo) on this manual and are subject to change without prior notice due to product improvements and specification changes.
