InfraTec GmbH
Infrarotsensorik und Messtechnik
Gostritzer Straße 61 – 63
01217 Dresden/GERMANY
VarioCAM
User Manual
State: March 2016
Phone
+49 351 871-8615
Fax
+49 351 871-8727
Email
service@InfraTec.de
www.InfraTec.de
®
HD head
© InfraTec 2016
(All mentioned product names and trademarks remain the
property of their respective owners.)
Advertisement
Table of Contents
Summary of Contents for InfraTec VBIP-G
- Page 1 ® VarioCAM HD head User Manual State: March 2016 © InfraTec 2016 InfraTec GmbH Phone +49 351 871-8615 (All mentioned product names and trademarks remain the Infrarotsensorik und Messtechnik +49 351 871-8727 property of their respective owners.) Gostritzer Straße 61 – 63 Email service@InfraTec.de...
-
Page 3: Table Of Contents
Establishing a connection to the IRBIS 3* software ..........27 Maintenance of the device ..................30 10.1 Cleaning of lenses and protective windows ................. 30 10.2 Calibration ............................ 30 Protection of the environment ................... 31 Service .......................... 32 User Manual © InfraTec GmbH 2016... -
Page 4: Introduction
Note: Without the written consent of Jenoptik and InfraTec GmbH, no part of this user manual must be reproduced or edited, copied or distributed using electronic systems in any form (print, copy, microfilm, or any other procedure). This user manual was developed applying due diligence. No liability shall be assumed for any damages caused by the non-observance of the information contained in this user manual. - Page 5 Typical fields of application of the thermography system are, amongst other things: ■ Research and development ■ Optimization of components and assemblies ■ Material inspections ■ Control of process temperatures ■ Quality assurance ■ Stationary micro-thermography ■ Security technology and early fire detection User Manual © InfraTec GmbH 2016...
-
Page 6: Equipment Safety-Related Instructions
Elektrische Mess-, Steuer-, Regel- und Laborgeräte - EMV-Anforderungen - Teil 1 : Allgemeine Anforderungen (IEC 61326-1 :2005) / Electrical equipment for measurement, control and laboratory use – EMC requirements – Part 1: General requirements (IEC 61326-1 :2005) © InfraTec GmbH 2016 User Manual... - Page 7 HD head is not in use, the supplied protective lens cap must be attached at all times. The lens should not be replaced in rooms with high amounts of dust or moisture, because the degree of protection is not provided for when the lens is removed. User Manual © InfraTec GmbH 2016...
-
Page 8: Technical Description
(85 x 63) min. 70 (54 x 40) Close-up 0.5x for 30 max. 47 (34 x 25) min. 33 (30 x 22) Close-up 0.5x for 60 max. 100 (35 x 27) min. 78 (29 x 22) © InfraTec GmbH 2016 User Manual... - Page 9 (depending on the equipment) is implemented: ■ Detector electronics interface ■ Gain and offset correction ■ Defect pixel treatment ■ Low-pass filtration ■ Zoom generator ■ Graphics overlay* ■ IR/graphics mixer* ■ GigE-Vision interface* User Manual © InfraTec GmbH 2016...
- Page 10 Process interface* Simultaneously using several interfaces on the 14-pin LEMO socket is allowed for by means of a breakout box*. When using a breakout box*, the breakout box* is also used for external power supply. © InfraTec GmbH 2016 User Manual...
-
Page 11: Technical Data
* (Properties and technical specifications depend on the camera configuration and vary within the equipment packages of VarioCAM ® Design and specification are subject to continuous further development; subject to changes within the meaning of technical progress.) User Manual © InfraTec GmbH 2016... -
Page 12: Dimensions
30 mm (bayonet interface). When using other lenses, the total dimensions will change accordingly. Fig. 1 View from the right side Additional fasting thread M5/ maximum depth 5 mm (4x) Fig. 2 View from the left side © InfraTec GmbH 2016 User Manual... - Page 13 (4x) M5/maximum depth 5 mm Rubber pumper Tripod socket UNC 1/4" - 20 G Guide bore Ø 4.5 H10 maximum depth 6 mm usable width max. 6 mm Fig. 5 View from below User Manual © InfraTec GmbH 2016...
-
Page 14: Unpacking And Control
Breakout box, including connecting cable and 14-pin LEMO connector, trigger cable ■ Gigabit Ethernet card ■ Ethernet cable with 8-pin LEMO connector ■ Device tripod ® 3 ■ Thermography software of the IRBIS family © InfraTec GmbH 2016 User Manual... -
Page 15: Denomination Of The Camera Components
RS232, analog OUT USB 2.0, DVI-D (HDMI) (Breakout box) Fig. 7 View from the rear Red mark for lens installation Lens In order to engage the lens, turn clockwise Fig. 8 View from the lens side User Manual © InfraTec GmbH 2016... -
Page 16: Quick Guide
When using an optional “ever on” wall plug transformer or an “ever on” breakout box, the VarioCAM ® HD head can only be switched off by disconnecting the power supply. © InfraTec GmbH 2016 User Manual... -
Page 17: Display
SDHC card or by using the respective interface to the control unit. ■ In order to analyze the thermography images, the supplied analysis software must be installed and started. ® Fig. 9 Analysis using the IRBIS 3 software User Manual © InfraTec GmbH 2016... -
Page 18: Start-Up
In order to avoid confusions, the Ethernet cable is marked in a blue color, just like the left LEMO socket. ■ The Power over Ethernet interface supports supply devices in accordance with IEEE 802.3at standard for type 1 (corresponds to the 13 W standard according to IEEE 8022.3-2008). © InfraTec GmbH 2016 User Manual... -
Page 19: Replacing The Lens
HD head hand side, blue mark). The wall plug connector is connected to the right 14-pin LEMO socket. LEMO Ethernet Power supply ® Fig. 12 VarioCAM HD with Ethernet cable and wall plug transformer User Manual © InfraTec GmbH 2016... -
Page 20: Operation Using Breakout Box (Rs232*, Video Output Fbas*, Trigger I/O*, Analog Out*)
As an alternative, a breakout box with “ever on” function is available. If the VarioCAM ® HD head is connected to this breakout box, it automatically activates as soon as the power supply is established. © InfraTec GmbH 2016 User Manual... -
Page 21: Trigger Channels Variocam ® Hd Head
Commercially available BNC cables can be used in order to connect the trigger signal sources to the breakout box. ■ Trigger channel 1 is used by the IRBIS ® 3 software. ■ Trigger channel 2 is reserved for the SDK and further specific applications. User Manual © InfraTec GmbH 2016... -
Page 22: Syncout
The synchronisation pulse has a length of approx. 600 µs. The voltage level on the output is 5 V. The signal should be uncoupled with a high impedance. © InfraTec GmbH 2016 User Manual... -
Page 23: Software Installation
For the installation described below, you must dispose of the access rights of the user group “Administrators”. Installation of WinPcap Upon execution of the file “WinPcap_4_1_2.exe“, please follow the setup wizard by always clicking “Next >“. Fig. 16 Start window User Manual © InfraTec GmbH 2016... - Page 24 VarioCAM ® HD head 8. Software installation Fig. 17 Start of the installation Fig. 18 Confirmation of the terms and conditions of the license agreement © InfraTec GmbH 2016 User Manual...
- Page 25 VarioCAM ® HD head 8. Software installation Fig. 19 Define automatic start of WinPcap Fig. 20 Completion of the installation The installation is finished by clicking the “Finish” button. User Manual © InfraTec GmbH 2016...
-
Page 26: Setting The Network Adapter
Please note that you only need the components described above in order to establish an Ethernet connection to the VarioCAM ® HD head. Therefore, we recommend deactivating any further components contained in the input mask. © InfraTec GmbH 2016 User Manual... - Page 27 In this case, no connection can be established to the VarioCAM ® HD head. User Manual © InfraTec GmbH 2016...
-
Page 28: Configuration Of The Network Card
Speed and duplex mode Please select the highest possible value from the available drop-down list. Please preferentially select the value “1.0 Gbit/s full duplex” and the “Automatic negotiation” menu item only if this value is not available. © InfraTec GmbH 2016 User Manual... -
Page 29: Establishing A Connection To The Irbis 3* Software
Establishing a connection to the IRBIS ® 3* software Within the IRBIS ® 3 program, the "Connect" button must be clicked in the "Camera" menu item in order to establish the connection between camera and software. User Manual © InfraTec GmbH 2016... - Page 30 VarioCAM ® HD head 9. Establishing a connection to the IRBIS® 3* software © InfraTec GmbH 2016 User Manual...
- Page 31 "Accept" button will start the establishment of the connection to the thermography system. ® Fig. 27 IRBIS 3 – "Select camera" All further functions of the program are described in detail in the manuals "RBIS ® 3 – Infrared thermography software". User Manual © InfraTec GmbH 2016...
-
Page 32: Maintenance Of The Device
Wipe extremely slowly and only in one direction. Rapid wiping in multiple directions can cause scratches. Use a new cloth, cotton or cotton swab for each cleaning. The only suitable cleaning solutions are ethanol or methanol. If smudges persist even after following these steps, please contact InfraTec service. 10.2 Calibration The VarioCAM ®... -
Page 33: Protection Of The Environment
In this case, please return the device to the address mentioned in chapter 12 Service – page 32. User Manual © InfraTec GmbH 2016... -
Page 34: Service
InfraTec GmbH Infrarotsensorik und Messtechnik Gostritzer Straße 61 - 63 01217 Dresden GERMANY Phone: +49 351 871-8615 Fax: +49 351 871-8727 Email: service@InfraTec.de www.InfraTec.de © InfraTec GmbH 2016 User Manual...
