Aquatic Nature aquachill 200 User Manual

Electric chiller
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

Technical Products
ELECTRIC CHILLER
AquaChill 200
Features:
1. Thermo-electric Chiller
2. For Fresh- and Marine water aquariums
3. Micro-processor conducted
4. Silent - Easy to install
5. Temperature reach 15°C - 30°C
6. Reduces water temperature 3°C - 4°C in a
200L. aquarium
www.aquatic-nature.com
Instructions /
Warranty
Technical Products
Safety precautions
Read the instructions carefully before use.
1. Do not disassemble nor modify the AquaChill 200 in order
to avoid electrical shock or fire hazard. If opened warranty expires.
2. Do not use other electric wires or plugs than the ones supplied with
the AquaChill 200.
3. To prevent electric shock, do NOT touch the power source with wet
or sweaty hands, or when the power source itself is wet.
4. A pump with a water debit of 1000 to 2000 liters per hour is
recommended.
Parts List
AquaChill 200
1. Water inlet
2. Water outlet
3. Function display indicator (LED)
4. Temperature indicator
5. Temperature adjuster (higher)
6. Temperature adjuster (lower)
7. Ventilation inlet
8. Ventilation outlet
9. 24V electric connecting wire set
Power source
10. Radiator fan
11. Power source switch
12. Socket
13. Power source 115V/230V
14. Radiator grid
15. 24V socket
www.aquatic-nature.com
selector switch

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the aquachill 200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aquatic Nature aquachill 200

  • Page 1 Read the instructions carefully before use. Instructions / AquaChill 200 1. Do not disassemble nor modify the AquaChill 200 in order Warranty to avoid electrical shock or fire hazard. If opened warranty expires. 2. Do not use other electric wires or plugs than the ones supplied with Features: the AquaChill 200.

  • Page 2: Installation

    The Aquachill 200 produces heat while cooling, so make sure the air damaged (short circuit). inlet and outlet of the Aquachill 200 is not blocked. Assure a good air flow, as it increases the efficiency of the Aquachill 200. (fig. 17) - Plug the connecting wire of the AquaChill 200 into the Power source Put the Aquachill 200 on a flat and stable surface.

  • Page 3: Maintenance

    The AquaChill 200 has a very low maintenance, yet a few rules have to be applied : - On top of the AquaChill 200 you’ll find a display (fig. 31) This display has 2 buttons, one with the arrow pointing upwards (red field), and one with...

  • Page 4: Actual Application Examples

    In other words, keep the distance from the outlet of the position). In other words, keep the distance from the outlet of the filter to the inlet of the AquaChill 200 as short as possible. filter to the inlet of the AquaChill 200 as short as possible.

  • Page 5: Technical Specifications

    5. Volume of the Lower volume of aquarium aquarium higher than 200 liters 6. Pumps are blocked Clean tubes or replace them 7. Distance between Reduce distance between pump and AquaChill pump and AquaChill 200 200 is too big www.aquatic-nature.com www.aquatic-nature.com...
  • Page 6 Chiller cools off, until it’s frozen. If this happens, wait 30 minutes until you restart the Chiller. NEVER let the AquaChill run out of water. Innovative products R & D Aquatic Nature www.aquatic-nature.com www.aquatic-nature.com...
  • Page 7 Technical Products Technical Products Fig. 22 Fig. 24 Fig. 23 Fig. 25 Fig. 26a Fig.26b Side View Fig. 27 Fig. 28 Fig. 29a Fig. 17 Fig. 18 Fig. 16 Fig. 29b Fig. 30 Fig. 31 Fig. 19 Fig. 32 Fig. 33 Fig.
