User Manual
SunReadable Solution
15", 17", 19", 22" screen size
Options :
- BNC + S-Video
- Audio
SunReadable LCD Display
Models
RP-H717 / RP-H819
SunReadable Widescreen LCD Display
Models
RP-HW719 / RP-HW822
SunReadable LCD Drawer
Models
RP-H117 / RP-H119
SunReadable LCD Keyboard Drawer
Models
H-117 / 119
- With KVM options
- DVI
- Quad Display
- Touchscreen
- DC power
Advertisement
Table of Contents
Summary of Contents for Cyber Viev RP-H717
-
Page 1: User Manual
User Manual SunReadable Solution 15", 17", 19", 22" screen size SunReadable LCD Display Models RP-H717 / RP-H819 SunReadable Widescreen LCD Display Models RP-HW719 / RP-HW822 SunReadable LCD Drawer Models RP-H117 / RP-H119 SunReadable LCD Keyboard Drawer Models H-117 / 119... -
Page 2: Table Of Contents
Contents Chapter 1 Getting Started Important Safeguards............1 Regulatory Notice...............2 Before Installation...............3 Unpacking................3 Optional Accessories............3 Peripheral Products............4 Part 1 RP-H717 & RP-H819 Chapter 2 Installation Package Contents..............5 Installation................6 Structure Diagram...............7 Connection.................7 Part 2 RP-HW719 / RP-HW822 Chapter 3 Installation Package Contents...............8 Structure Diagram...............9... - Page 3 Part 3 RP-H117 / RP-H119 Chapter 4 Installation Package Contents.............12 Structure Diagram.............13 Connection...............13 How to Install “One Man” Installation Slides....14-15 How to Use The Slides............16 Part 4 H-117 / 119 Chapter 5 Installation Package Contents.............17 Optional Accessories............18 Structure Diagram.............18 How to Install “One Man” Installation Slides....19-20 How to Use The Slides............21 H-117 / 119 (Single Console) .......22...
- Page 4 Chapter 6 Operation On-screen Display Operation...........25 On-screen Menu...............26 Chapter 7 LCD Specifi cation ..........27-28 Chapter 8 Optional Specifi cation DVI-D Option..............29 BNC + S-Video Option............30 Audio Option..............31-33 Chapter 9 Touchscreen Options .........34-35 Chapter 10 Front NEMA 4 / IP65 Options ......36 Chapter 11 Quad Display Option ..........37...
-
Page 5: Important Safeguards
Chapter 1 1.1 Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover ■ Any product, on which the serial number has been defaced, modifi ed or removed. ■... -
Page 6: Regulatory Notice
Chapter 1 1.2 Regulatory Notice Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without no- tice. -
Page 7: Before Installation
Chapter 1 1.3 Before Installation ■ It is very important to locate the Rackmount LCD Drawer / Display in a suitable environment. ■ The surface for placing and fi xing the Rackmount LCD Drawer / Display should be stable and level or mounted into a suitable cabinet. -
Page 8: Peripheral Products
Chapter 1 1.6 Peripheral Products Item Model No. Description MU-1602 / MU-1603 / MU-1604 Matrix Cat6 16 port KVM MU-IP1613 / MU-IP1614 / MU-IP1624 Matrix IP Cat6 16 port KVM Matrix Cat6 KVM MU-3202 / MU-3203 / MU-3204 Matrix Cat6 32 port KVM MU-IP3213 / MU-IP3214 / MU-IP3224 Matrix IP Cat6 32 port KVM M-802 / M-803 / M-804... -
Page 9: Part 1 Rp-H717 & Rp-H819
Chapter 2 2.1 Package Contents RP-H717 & RP-H819 Rackmount LCD display x 1 pc 6' VGA cable (male to male) x 1 pc User manual x 1 pc Power cord x 1 pc Auto switch power adapter x 1 pc... -
Page 10: Installation
Chapter 2 2.2 Installation RP-H717 & RP-H819 ■ Install each screw shown in Figure 1. Figure 1. ■ Fixed the LCD into the rack. * M6 screws are not provided. Figure 2. -
Page 11: Structure Diagram
Chapter 2 2.3 Structure Diagram RP-H717 & RP-H819 LCD interchangeable module kit LCD membrane 2.4 Connection RP-H717 & RP-H819 DB-15 VGA female connector Power input Caution : The Rackmount LCD Drawer & Display are hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable. Plug- ging and unplugging cables while servers and KVM are powered on may cause irreversible damage of the servers, KVM and Rackmount LCD Drawer. -
Page 12: Package Contents
Chapter 3 3.1 Package Contents RP-HW719 & RP-HW822 Rackmount LCD display x 1 pc 6' VGA cable (male to male) x 1 pc User manual x 1 pc Power cord x 1 pc Auto switch power adapter x 1 pc... -
Page 13: Structure Diagram
Chapter 3 3.2 Structure Diagram RP-HW719 & RP-HW822 LCD interchangeable module kit LCD membrane 3.3 Connection RP-HW719 & RP-HW822 DB-15 VGA female connector Power input Caution : The Rackmount LCD Drawer & Display are hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable. Plug- ging and unplugging cables while servers and KVM are powered on may cause irreversible damage of the servers, KVM and Rackmount LCD Drawer. -
Page 14: Installation
Chapter 3 3.4 Installation RP-HW719 ■ Install each screw shown in Figure 3. Figure 3. ■ Fixed the LCD into the rack. * M6 screws are not provided. Figure 4. P.10... - Page 15 Chapter 3 3.4 Installation RP-HW822 Figure 5. Figure 6. ■ ■ Install each screw shown in Figure 5. Insert the upper part of the LCD display to the rack shown in Figure 6. * M6 screws are not provided. Figure 7. Figure 8.
-
Page 16: Rp-H117 / Rp-H119
Chapter 4 4.1 Package Contents RP-H117 & RP-H119 LCD drawer x 1 pc 6’ VGA cable (male to male) x 1 pc User manual x 1 pc Auto switch power adapter x 1 pc Power cord x 1 pc Mounting bracket x 2 pcs M6*15mm screw x 8 pcs M6 cage nut x 6 pcs Cup washer x 8 pcs... -
Page 17: Structure Diagram
Chapter 4 4.2 Structure Diagram RP-H117 & RP-H119 LCD interchangeable module kit Carry handle to release the 2-pt lock “One Man” Installation Slide 2-point lock LCD membrane 4.3 Connection RP-H117 & RP-H119 Caution : The Rackmount LCD Drawer & Display are hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable. -
Page 18: How To Install "One Man" Installation Slides
Chapter 4 4.4 How to Install "One Man" Installation Slides Install into rack Rear side Right bracket ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the rear mouting bracket to fi t your rack. ■... -
Page 19: How To Install "One Man" Installation Slides
Chapter 4 4.4 How to Install “One Man” Installation Slides ■ Attach front left and right mounting ears of the LCD keyboard drawer to vertical mounting rails. ■ M6 screw and cup washer x 2 pcs included. Complete the installation ■... -
Page 20: How To Use The Slides
Chapter 4 4.5 How to Use the Slides RP-H117 & RP-H119 ■ A black arrow release button is located on the outside of each slide. (shown in Figure 9). Figure 9. ■ Pull and hold the black arrow button on either side of the LCD drawer to unlock. -
Page 21: Package Contents
Chapter 5 5.1 Package Contents H-117 & H-119 LCD keyboard drawer x 1 pc CE-6 Combo 4-in-1 KVM cable x 1 pc User manual x 1 pc Power cord x 1 pc Auto switch power adapter ( for external power version) x 1 pc Mounting bracket x 2 pcs M6*15mm screw x 8 pcs M6 cage nut x 6 pcs... -
Page 22: Optional Accessories
Chapter 5 5.2 Optional Accessories 1. Combo 4-in-1 KVM cable 1.1 CE-6 6 feet 1.2 CE-10 10 feet 1.3 CE-15 15 feet 2. Power Cord 2.1 IEC power cord 2.2 NEMA 5-15 power cord (US) 2.3 BS 1363 power cord (UK) 2.4 CEE 7/4 power cord (German) 2.5 AS 3112 power cord (Australia) 5.3 Structure Diagram... -
Page 23: How To Install "One Man" Installation Slides
Chapter 5 5.4 How to Install "One Man" Installation Slides Install into rack Rear side Right bracket ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the rear mouting bracket to fi t your rack. ■... -
Page 24: How To Install "One Man" Installation Slides
Chapter 5 5.4 How to Install "One Man" Installation Slides ■ Attach front left and right mounting ears of the LCD keyboard drawer to vertical mounting rails. ■ M6 screw and cup washer x 2 pcs included. Complete the installation ■... -
Page 25: How To Use The Slides
Chapter 5 5.5 How to Use the Slides ■ A black arrow release button is located on the outside of each slide. (shown in Figure 12). Figure 12. ■ Pull and hold the black arrow button on either side of the LCD keyboard drawer to unlock. (shown in Figure 13). -
Page 26: H-117 / 119 (Single Console)
Chapter 5 5.6 H-117 / 119 (Single Console) - Use CE-6 to connect to server via PS/2 interface Figure 15. Example of connecting CE-6 4-in-1 Combo KVM cable to server via PS/2 interface 5.7 H-117 / 119 (Single Console) - Use CE-6 to connect to KVM via PS/2 interface CE-6 KVM Cable Figure 16. -
Page 27: H-117 / 119 (Single Console)
Chapter 5 5.8 H-117 / 119 (Single Console) - Use CE-6 to connect to server via USB interface Figure 17. Example of connecting CE-6 4-in-1 Combo KVM cable to server via USB interface 5.9 H-117 / 119 (Single Console) - Use CE-6 to connect to KVM via USB interface CE-6 KVM Cable Figure 18. -
Page 28: Keyboard & Mouse
Chapter 5 5.10 Keyboard & Mouse H-117 & H-119 Supporting layouts N keyboard integrated with touchpad N keyboard integrated with trackball P.24... -
Page 29: On-Screen Display Operation
Chapter 6 6.1 On-screen Display Operation RP-H717 & RP-H819 RP-HW719 & RP-HW822 RP-H117 & RP-H119 H-117 & H-119 LCD membrane Membrane Switch Function Power light Green = On Orange = Power saving Power on / off LCD Display the OSD menu... -
Page 30: On-Screen Menu
Chapter 6 6.2 On-screen Menu OSD Confi guration Page Image: To enter into the brighness, contrast, color temp, red, green, and blue Geometry: To enter into the auto adjust, H position, V position, phase and clock Video: To enter into the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio: To enter into volume, bass, treble, balance, AVL and mute... -
Page 31: Lcd Specifi Cation
Chapter 7 7.1 LCD Specifi cations RP-H717 & RP-H819 RP-H117 & RP-H119 H-117 & H-119 Item Description Grade A industrial TFT LCD panel LCD Grade Diagonal Size 17" TFT 19" TFT Max. Resolution 1280 x 1024 1280 x 1024 Brightness (cd/m²) -
Page 32: Chapter 7 Lcd Specifi Cation
Chapter 7 7.1 LCD Specifi cations RP-HW719 & RP-HW822 Item Description Grade A industrial TFT LCD panel LCD Grade Diagonal Size Wide 19" TFT Wide 22” TFT Max. Resolution 1440 x 900 1680 x 1050 Brightness (cd/m²) Color Support 16.7 M 16.7 M Contrast Ratio (typ.) 900:1... -
Page 33: Dvi-D Option
Chapter 8 8.1 DVI-D Option RP-H717 & RP-H819 RP-HW719 & RP-HW822 DVI-D Power Remarks ■ Package includes 1 x 6ft DVI-D cable RP-H117 & RP-H119 H-117 & H-119 Power DVI-D Remarks ■ Package includes 1 x 6ft DVI-D cable P.29... -
Page 34: Bnc + S-Video Option
Chapter 8 8.2 BNC + S-Video Option RP-H717 & RP-H819 RP-HW719 & RP-HW822 S-Video BNC Power RP-H117 & RP-H119 H-117 & H-119 Power S-Video BNC Remarks ■ Package includes 1 x 6ft S-Video cable P.30... -
Page 35: Audio Option
Chapter 8 8.3 Audio Option RP-H717 & RP-H819 RP-HW719 & RP-HW822 Audio Power Remarks ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.31... - Page 36 Chapter 8 8.3 Audio Option RP-H117 & RP-H119 Power Audio Remarks: ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.32...
- Page 37 Chapter 8 8.3 Audio Option H-117 & H-119 Power Audio Remarks: ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.33...
-
Page 38: Touchscreen Options
Chapter 9 9.1 Touchscreen Options RP-H717 & RP-H819 RP-HW719 & RP-HW822 USB interface Power Serial interface Serial Power RP-H117 & RP-H119 USB interface Power Serial interface Power Serial P.34... -
Page 39: Chapter 9 Touchscreen Options
Chapter 9 9.1 Touchscreen Options H-117 & H-119 USB interface Power Serial interface Power Serial e-Resistive -17TRB / -19TRB / -19WTRB / -22WTRB / Model -17TRS -19TRS -19WTRS -22WTRS Screen size 17" 19" 19" wide 22" wide Interface USB / serial Optical transmittance 80% ±... -
Page 40: Chapter 10 Front Nema 4 / Ip65 Options
Chapter 10 10.1 Front NEMA 4 / IP65 Options RP-H717 & RP-H819 RP-HW719 & RP-HW822 Rear case LCD panel 4mm protective glass (Front NEMA 4 / IP65 protection) Aluminum front panel Remarks ■ 4mm thickness of protective glass is not toughened one, please handle it carefully. -
Page 41: Chapter 11 Quad Display Option
Chapter 11 11.1 Quad Display Option Specifi cations Video IN 1 ~ 4 RS-232 VCR in Video Loop Alarm I/O VCR out AV BNC VGA Power 1 ~ 4 Item Description Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16.7 M Imaging System... -
Page 42: Chapter 12 Dc Power Options
Chapter 12 12.1 DC Power Options RP-H717 & RP-H819 RP-HW719 & RP-HW822 DC Power input RP-H117 & RP-H119 DC Power input H-117 & H-119 DC Power input Model Input rating Input voltage: 24-Volt 48-Volt Input range: 18 ~ 36V 36 ~ 75V... -
Page 43: Chapter 13 Dimensions
Chapter 13 13.1 Dimensions RP-H717 & RP-H819 RP-HW719 & RP-HW822 RP-H117 & RP-H119 H-117 & H-119 Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 480 x 57 mm 565 x 450 x 156 mm 7 kg 8.5 kg... -
Page 44: Chapter 14 Troubleshooting
Chapter 14 14.1 Troubleshooting 1. How do I adjust the resolution? To change monitor resolution, click Start -> Control Panel -> Display. Select Setting tab to adjust the monitor resolution in Desktop Area. The available resolutions, "640 x 480", "800 x 600", "1024 x 768", "1152 x 864", "1280 x 1024", are deter- mined by the display card in your computer.
