- Page 1 PEX 500-C-TICK INFORMATION & OPERATING INSTRUCTIONS MODEL: 56384886 CAUTION: DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THIS INSTRUCTION MANUAL IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY FORM NO. 56042658 REV A...
-
Page 2: Table Of Contents
Pallet System 500-1 C-TICK ........18-19 Pallet System 500-2 C-TICK ........20-21 Recovery System ............22 Solution System............23 Wiring Diagram ............24-25 Options & Accessories..........25 Water Flow Diagram ............. 26 A-2 - FORM NO. 56042658 - PEX 500-C-TICK... -
Page 3: Introduction
Repairs, when required, should be performed by your Authorized HydraMaster Service Center, who employs factory trained service personnel, and maintains an inventory of HydraMaster original replacement parts and accessories. Call the HYDRAMASTER DEALER named below for repairs or service. Please specify the Model and Serial Number when discussing your machine. MODIFICATIONS Modifications and additions to the cleaning machine which affect capacity and safe operation shall not be performed by the customer or user without prior written approval from HydraMaster. -
Page 4: Important Safety Instructions
Water that has flown through backflow preventers is considered to be non-potable. • Do not use the machine if a supply cord or important parts of the machine are damaged, e.g. safety devices, high pressure hoses, trigger gun. A-4 - FORM NO. 56042658 - PEX 500-C-TICK... -
Page 5: Grounding Instructions
Extension cords connected to this machine should be 12 gauge, three-wire cords with three-prong plugs and outlets. DO NOT use extension cords more than 50 feet (15 m) long. WARNING! • If an extension cord is used, the plug and socket must be of watertight construction. • Inadequate extension cords can be dangerous. FORM NO. 56042658 - PEX 500-C-TICK - A-5... -
Page 6: Know Your Machine
A-6 / ENGLISH KNOW YOUR MACHINE Solution Hose Quick Disconnect Solution Tank Fill Opening Vacuum Hose Barb Drain Hose Handles Roller Balls Wheel Castor Solution Filter 10 Recovery Tank Shutoff Float A-6 - FORM NO. 56042658 - PEX 500-C-TICK... - Page 7 14 Pressure Adjustment Knob 15 Pressure Gauge 16 Pressure Relief Valve 17 Cord Retainer Straps (four) 18 Hour Meter (Optional) 19 Wand Retainer Bracket 20 Pigtail Power Cords 21 Hose Hangers (two) FORM NO. 56042658 - PEX 500-C-TICK - A-7...
-
Page 8: Know Your Switch Plate
Vacuum Switch - This switch turns the second of the two vacuum motors ON and OFF. Heat Switch - This three position switch controls the water temperature. Position (I) is low temperature, Position (O) is OFF and Position (II) is high temperature. A-8 - FORM NO. 56042658 - PEX 500-C-TICK... -
Page 9: Preparing The Machine For Use
Never use water above 130º F/54º C in the solution tank. CAUTION! Use low-sudsing, liquid detergents designed for carpet extraction. FORM NO. 56042658 - PEX 500-C-TICK - A-9... -
Page 10: Operating The Machine
Recovery Tank Drain Hose (4) into its side storage location, then remove the plug (hold the end of the hose above the water level in the tank to avoid sudden, uncontrolled flow of waste water). 17 Follow the instructions in the After Using the Machine section of this manual. A-10 - FORM NO. 56042658 - PEX 500-C-TICK... - Page 11 ENGLISH / A-11 OPERATING THE MACHINE FORM NO. 56042658 - PEX 500-C-TICK - A-11...
-
Page 12: After Using The Machine
• *Check Carbon Brushes • * Have a HydraMaster service technician check the vacuum motor carbon brushes once a year or after 300 operating hours. Check the pump motor carbon brushes every 500 hours or once a year. IMPORTANT! Motor damage resulting from failure to service the carbon brushes is not covered under warranty. See the Limited Warranty Statement. -
Page 13: Troubleshooting
Protection Grade Sound Pressure Level 68.7 dB LpA, 3 dB (IEC 60704-2-1) Total Weight 112 lbs. (50.8 kg) Solution Tank Capacity 12 gal (45.5 L) Recovery Tank Capacity 10 gal (37.8 L) FORM NO. 56042658 - PEX 500-C-TICK - A-13... -
Page 15: Section Ii - Parts List
56113034 Hinge Plate 56113103 Kit-Hardware Solution Tank Specify the model and serial number of the machine. Use the space below to record the model and serial number for future reference. Model _____________________________ Serial No. ________________________________ 7/2016 56042658 - PEX 500-C-TICK... -
Page 16: Decal System
PARTS LIST DECAL SYSTEM C-TICK PEX 500-C-TICK - 56042658 7/2016... -
Page 17: Decal System
PARTS LIST DECAL SYSTEM C-TICK Kit Item Ref. No. Description 4339 Label Caution / Extension Cord 4344 Label Gauge Priming Warning 2 56384917 Decal-PEX 500 56380692 Label Danger Electric Shock 56380831 Decal-CRI Gold 7/2016 56042658 - PEX 500-C-TICK... -
Page 18: Pallet System 500-1 C-Tick
To Pressure Gauge To Heater To Heater To Pump To Pump To Barb On Recovery Tank To "T" Barb From Unloader To Barb On Solution Tank To Barb On Pump To Barb On Solution Tank PEX 500-C-TICK - 56042658 7/2016... -
Page 19: Pallet System 500-1 C-Tick
Kit-Heater Repair PEX 56113135 Vac Hose Rubber 7.75 X 2.0 ID [ ] = Not Shown 56412277 Solution Hose * = Optional, Not Included 56113063 Hose 3/8 ID = Revised or new since last update 56113064 Gasket-Pallet 7/2016 56042658 - PEX 500-C-TICK... -
Page 20: Pallet System 500-2 C-Tick
PARTS LIST PALLET SYSTEM 500-2 C-TICK PEX 500-C-TICK - 56042658 7/2016... - Page 21 Kit-Heater Repair PEX 56113135 Vac Hose Rubber 7.75 X 2.0 ID [ ] = Not Shown 56412277 Solution Hose * = Optional, Not Included 56113063 Hose 3/8 ID = Revised or new since last update 56113064 Gasket-Pallet 7/2016 56042658 - PEX 500-C-TICK...
-
Page 22: Recovery System
Recovery Tank Gasket 56113039 Ball Float Assy 56105265 Drain Hose 56105266 Cap-Drain Hose (for 56105265) Lid and Ring 6 Lid W/Clear 56383436 O-Ring = Revised or new since last update Service Kits 56113100 Kit-Recovery Tank Lid PEX 500-C-TICK - 56042658 7/2016... -
Page 23: Solution System
Filter 40 Mesh S/S 1/2NPT FEM 901A Lid-Tank-Sol 92BUSP Nipple PVC 1/2 N.P.T. 1083 Hose Barb, 3/8 Barb X 1/4 Mpt 1113 Hose Barb 90 Degree 1/2 Hos FHP-10-32 5-8 Service Kits 56113103 Kit-Hardware Solution Tank 7/2016 56042658 - PEX 500-C-TICK... -
Page 24: Wiring Diagram
UNITS IN [ ] ARE ISO METRIC 56113044 AS NOTED. ORCAD FIRST USED ON SCALE NONE ASSY. 56113E01 SHEET TEMP 1 TEMP 1 TEMP 2 TEMP 2 GRN/YEL TEMP CUT-OFF TEMP CUT-OFF HEATER HEATER HEAT ELEMENT HEAT ELEMENT PEX 500-C-TICK - 56042658 7/2016... -
Page 25: Options & Accessories
Kit-Hour Meter FP203 Vac Hose/Pressure Ln. 15’ Exte FP196 Vac Hose/Pressure Ln. 25’ Exte 000-163-034 Evolution Wand 1 1/2” x 13” Head (all models) 000-163-220 DriMaster 3 Upholstery Cleaning Tool SUBSYP1 Syphon-Hose-Red (for priming pump) 7/2016 56042658 - PEX 500-C-TICK... -
Page 26: Water Flow Diagram
GREEN = 500PSI WATER FLOW PURPLE = PRESSURE RELIEF RETURN TO TANK RED = 500PSI HEATED WATER FLOW Item Description Solution Tank Fresh Water Inlet Filter 500PSI Pump Unloader Valve Pressure Gauge Pressure Relief Valve 500PSI Quick Connect Heater PEX 500-C-TICK - 56042658 7/2016... - Page 28 800.426.1301 / 425.775.7272 11015 - 47th Avenue West / Mukilteo, WA 98275 www.hydramaster.com...
