- Page 1 Intelligent All In One Negative Ions (NO OZONE) UV Light Air Quality Sensor (PM2.5) Remote Control Ultra Quiet Sleep Mode Multi Stage Filtration Odor Sensor U s e r M a n u a l...
-
Page 2: Table Of Contents
C O N T E N T S Performance Indicators Purifier Features Illustration of the Product Installation Instructions Function Descriptions Humidifier Functions Cleaning the Filter s Precautions Intelligent AirQualitySystem Troubleshooting Warranty... -
Page 3: Performance Indicators
P E R F O R M A N C E I N D I C A T O R S Product Name Air Purifier Model D950 1. Cold Catalyst Filter 2. Cellular Activated Carbon Filter Purification 3. Anti-Bacterial Filter 4. - Page 4 Cellular-Activated Carbon Filter The cellular-activated carbon carries high efficient additives. It has excellent absorption and dust collection abilities. Anti-bacterial Filte The 5-microns filter with antimicrobial agents can efficiently kill bacteria in the air. High Efficiency HEPA Filter The precision of the HEPA filter is 0.01-0.03 micron. It is able to eliminate particles larger than 0.03 micron with the filtration rate of 99.07% or more.
-
Page 5: Illustration Of The Product
I L L U S T R A T I O N O F T H E P R O D U C T Control Panel Odor Sensor Outfalls Air Quality Handle Control Button Display Board Front Plate Air Outlet Display Panel Remote Control Middle Case... -
Page 6: Installation Instructions
I N S T A L L A T I O N I N S T R U C T I O N S Filter Installation Instructions With your thumb against the front panel, and your right hand in the gap at the front panel of the machine, gently pull on the panel to open the front panel. - Page 7 Filter Replacement Diagram and Instructions Place Filter 2 (Antimicrobial Place Filter 1 (Cold Catalyst and Filter and HEPA Compound Activated Carbon. Compound Filters) back into the inner side Filters) back into the inner side of the product. Note: Ensure the of the product.
-
Page 8: Function Descriptions
F U N C T I O N D E S C R I P T I O N S The product is equipped with a remote controller powered by DC3V batteries. If no power please configure the battery by yourself. - Page 9 When pressing on the sleep button, the machine will be at low speed and the intelligent odor sensor control is turned off. The speed and sleep buttons are controlled in a mutually exclusive manner. When one is turned on, the other is turned off. Press the anion button to turn on the anion generator.
-
Page 10: Humidifier Functions
F U N C T I O N S O F H U M I D I F I E R Press and hold the water tank clasp at 45 ° and remove the water tank. Rotate the valve in an anti-clockwise manner. Remove the valve and fill the tank with water. -
Page 11: Cleaning The Filter S
Best Practices on Cleaning of Filter, Humidifier and Anion Generator Filter maintenance and cleaning In order to extend the filter life, the filters should be exposed to sunlight periodically in order to release the harmful gas and odor, at the same time, to kill bacteria. Humidifier maintenance and cleaning Use citric acid detergent and follow the instructions to configure solution, pour into... -
Page 12: Precautions
P R E C A U T I O N S Do not use this machine in the following environments When using the machine, there should be a gap of at least 8 inches at both sides and back of the product, and 12 inches from the top surface for proper air circulation. -
Page 13: Intelligent Airqualitysystem
This product is not supposed to be used as daily ventilator, dust cleaner, or cooker hood. 10. lf the water tank leaks, turn off the power and put the product in an upright position for 30 minutes before use. 11. Note: Clean odor sensor area and humidity sensor area often to prevent collecting dust and affecting the efficiency. -
Page 14: Troubleshooting
T R O U B L E S H O O T I N G When the filter system must be cleaned or replaced Problem Solution No air comes out from Please check whether the product is turned the outlet on and connected to the power supply. -
Page 15: Warranty
W A R R A N T Y DrevalAir warrants this product against defects in materials and workmanship for the 2 Year period of time from the date of purchase. During this period, DrevalAir warrants that upon receipt of the product from the owner found to be defective in material or workmanship, DrevalAir will repair or replace, at its discretion, any defective item at no charge for that item.
Need help?
Do you have a question about the D950 and is the answer not in the manual?
Questions and answers
How do you fill water tank
To fill the water tank of the DREVAL D950:
1. Press and hold the water tank clasp at a 45° angle and remove the water tank.
2. Rotate the valve in an anti-clockwise direction.
3. Remove the valve and fill the tank with water.
4. Once filled, turn and shut the valve in a clockwise direction, ensuring the rubber seal remains in place.
5. Keep the water tank inclined at a 45° angle when reinstalling it into the machine.
6. After installation, ensure no bubbles are generated before pressing the humidify button.
