Dear user!

Thank you for purchasing this 3 in 1 Rear view panoramic mirror with a 4.3 inch

mirror dual-channel car DVR. Study this manual thoroughly in order to use the

device correctly and to make its service life longer. Do not throw the user's

manual away because you may need to consult it in future

[ Table of Contents]

Operating conditions .....................................................................................................................2

Technical characteristics ...............................................................................................................3

Completing parts ............................................................................................................................3

Description of connectors and buttons ..................................................................................4

Meaning of buttons ........................................................................................................................5

Operation guide ..............................................................................................................................7

System menu ....................................................................................................................................8

Operation modes ......................................................................................................................... 11

Video recording mode............................................................................................................................ 11

Photo mode ............................................................................................................................................... 11

Playback mode .......................................................................................................................................... 11

Other functions ............................................................................................................................. 12

Mounting and operating a rear-view camera ................................................................... 13

Possible problems and their causes ...................................................................................... 14

Table of Contents

Need help?

Do you have a question about the X23 and is the answer not in the manual?

Questions and answers

Summary of Contents for G-Tech X23

Page 1: Table Of Contents
Dear user! Thank you for purchasing this 3 in 1 Rear view panoramic mirror with a 4.3 inch mirror dual-channel car DVR. Study this manual thoroughly in order to use the device correctly and to make its service life longer. Do not throw the user‘s manual away because you may need to consult it in future [ Table of Contents] Operating conditions ........................2...
Page 2: Operating Conditions
[ Operating conditions] 1. Before start of using the device, study the user’s manual thoroughly. 2. Get acquainted with warranty terms 3. Before launching the device, charge its in-built battery fully using a car power sup- ply adapter included in the kit. 4.
Page 3: Technical Characteristics
• Incoming voltage: DC 5V, 1.5A • Car charger input: DC 12-24V • Dimensions: 285x110x13 mm • Weight: 315 g [ Completing parts] • Mirror Neoline G-tech X23 • Additional camera • Mirror cleaning wipe • Car power charger • USB cable •...
Page 4: Description Of Connectors And Buttons
[ Description of connectors and buttons ] 7. OK button 1. Mini USB connector 8. Down/Microphone 2. AV outlet (rear-view camera) button (DOWN/MIC) 3. TF card slot 9. Modes button (MODE) 4. On/off power switch button 10. Switch button (SWITCH) (POWER) 11.
Page 5: Meaning Of Buttons
[ Meaning of buttons] 1. Power feeding button (POWER) Press and hold – switching the device on/off. Short press in Operation mode – switching the screen lighting on/off. 2. MENU button Stop video recording. Short press in standby mode opens/closes Settings menu.
Page 6 6. MODE button Stop video recording. Short press in standby mode allows switching the operation modes: Video / Photo / Playback. 7. SWITCH button Short press – switching between front and rear cameras. 8. RESET button If your video recorder fails to react to the pressing of buttons, press RESET but- ton for forced resetting of the device.
Page 7: Operation Guide
10. USB connector USB connector is meant for charging and connecting to computer. In order to transfer data from your device to computer, use cable from the supplied kit, switch off the device by pressing POWER button, and make sure that the device is switched off.
Page 8: System Menu
Automated switching on/off: As soon as power is supplied to the video recorder (ignition switch on), the device will switch on automatically, starting video recording. As soon as power supply is cut off, the video recorder will automatically stop the recording and switch off. Note: If voltage in your car is supplied to the dashboard outlet even after the ignition switch off, remove the plug from the dashboard socket.
Page 9 Video settings Description Submenu Recording upon Automated start • Recording on switching on of recording upon • Recording off switching on Stamp date/time Switching on the date • Stamp on and time stamp • Stamp off Motion sensor Switching on •...
Page 10 Settings In order to enter the menu of general settings, press Menu button twice in Video mode or Photo mode, then select any menu item for setting setting. Settings Description Submenu Parking mode Selection of G sensor’s sensitivity Off/Low/Medium/High level in Parking mode G sensor Selection of G sensor’s sensitivity Off/Low/Medium/High...
Page 11: Operation Modes
[ Operation mode ] 1. Video recording mode Upon switching on the video recorder it gets into Video recording mode automatically. Cyclic recording is set as default; recorded in this mode, video files of equal duration are saved on the memory card consecutively; as soon as the memory card is full, automated removal of old files and saving of new ones starts.
Page 12: Other Functions
[ Other functions ] 1. Motion sensor This function is meant for monitoring the environment. As soon as camera spots any motion within its lens range, recording stops automatically for a while. To switch the motion sensor on, press and hold REC button in Standby mode or activate this func- tion through Settings menu.
Page 13: Mounting And Operating A Rear-View Camera
[Mounting and operating a rear-view camera] 1. Mount your rear-view camera as shown in Fig.1. mirror camera black rear light car body 2. Fix the camera on the rear car bumper using self-tapping screws or inside the car using 3M scotch tape (included ion the kit) as shown in Fig.2. Mounting the parking camera: 1) Inside the car with 3M scotch 2) On the rear car bumper...
Page 14: Possible Problems And Their Causes
[Possible problems and their causes ] If any problems with the device emerge although the equipment maintenance and operation terms have been observed, read this section to solve them. - It is impossible to shoot photos and record videos. Check if there is enough free space on Micro SD card, and if it is not blocked. - Spontaneous stop occurs during the recording.
