ABTronic TX User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the TX and is the answer not in the manual?

Questions and answers

Summary of Contents for ABTronic TX

  • Page 1 USER MANUAL...
  • Page 2 TENS pain Relief Device. Please read this manual before first use. Read before you use! ABTRONIC™TX should never be used to mask or relieve undiagnosed pain. Before treating any symptoms of pain, it is mandatory to diagnose the cause of pain by...
  • Page 3 PAGE 3 What is ABTRONIC™TX? ABTRONIC™TX, an innovative One Piece Self-Adhesive electro pain relieve incorporating TENS technology to target specific pain. Elegantly designed using ultra-thin and flexible medical grade silicone to perfectly match the contour of your body. This complete new approach to relieve pain offers a safe and effective non-drug treatment alternative for you.
  • Page 4 PAGE 4 ABTRONIC™TX USER MANUAL The AbTronicTX TENS pain Relief device passes electrical currents over the skin. The gel pad is a conducting medium and is a consumable item, subject to wear and tear. Please replace the gel pad if it stops providing sufficient contact, if you start to...
  • Page 5 PAGE 5 What is TENS? TENS, transcutaneous electrical nerve stimulation, which stimulates nerves through the skin. It is recognized as a clinically proven, effective, non- medication method of treating pain from certain causes. It manages pain by stopping the pain gate to prevent pain signal transmission to the brain, and helps to release endorphin to sooth pain by stimulating nerves.
  • Page 6 PAGE 6 ABTRONIC™TX USER MANUAL LED Light 2 LED Light 1   OFF/Low  Button, decrease Intensity ON/HI  Button, increase Intensity...
  • Page 7 PAGE 7 CONTROLS A self-timer switches the unit off after 10 minutes. 1. ON/HI: Turns the unit on and increases the output intensity. Press once to increase the output intensity. The higher the intensity - the larger the contraction. To adjust to maximum output power you need to push this button 10 times.
  • Page 8 PAGE 8 ABTRONIC™TX USER MANUAL The ABTRONIC™TX unit has the following 2 program modulation: LED 1 LED 2 Description AbTronicTX controller is now operating Both Led light will keep flashing GREEN GREEN The flashing speed is proportion to the output intensity For the Max.
  • Page 9 PAGE 9 CYCLE MODE PULSE WIDTH PULS RATE ON-TIME Constant 70 Hz 120 s Burst 70 Hz 120 s...

  • Page 10: Operation

    PAGE 10 ABTRONIC™TX USER MANUAL OPERATION BATTERY 1. Open the battery door by pushing it in the direction of the arrow: 2. Insert one piece CR 2032 Lithium battery into the battery compartment. The positive “+” pole of the battery should be facing you.

  • Page 11: Basic Use

    PAGE 11 BASIC USE 1. Attach the Abtronic™TX control unit onto the silicon pad holder. Insert the controller by aligning the marking on the controller case with the holder:...
  • Page 12 PAGE 12 ABTRONIC™TX USER MANUAL Insert the control unit aligning it with the shorter marking on the holder at position (1) and turn it clockwise until it aligns with the longer marking on the holder at position (2):  ...
  • Page 13 PAGE 13 APPLYING GEL PAD Precautions Do not use damaged, worn or dirty gel pad as this might „ result in burns. Always, stick gel pad to all electrodes while using the „ product. Don’t apply the product directly to skin, this may be painful or cause irritation or burns.
  • Page 14 PAGE 14 ABTRONIC™TX USER MANUAL 2. Stick the gel pad onto each of the 2 conductive areas on the rear side of the stimulation pad. If there is an air bubbles under the gel pad use a finger and press the air to the side of the pad to...
  • Page 15 PAGE 15 3. After affixing all gel pad properly, peel off the remaining film. Do not peel off the gel pad affixed to the electrode, until you need to replace them with new ones!
  • Page 16 PAGE 16 ABTRONIC™TX USER MANUAL 4. Gel pad Storage After use, do NOT remove the gel pad, but always place protective board back to electrode after use.
  • Page 17 ABTRONIC™TX USER MANUAL PAGE 17 Removing Gel Pad 1. Only remove the gel pad if you need to replace them with new ones. Turn off the product before removing the gel 3. Peel off the complete gel pad slowly in one pad.
  • Page 18 PAGE 18 ABTRONIC™TX USER MANUAL ABTRONIC™TX PLACEMENT: ABTRONIC™TX was design to be used to effectively target specific pain. Back pain • Joint pain (e.g. knee joint, hip joint, shoulder) • Neuralgia • Headache • Menstrual Pain • Pain after injuries to musculoskeletal system •...
  • Page 19 PAGE 19 FRONT BACK...
  • Page 20 PAGE 20 ABTRONIC™TX USER MANUAL Control Unit: 1. Press the ON/HI button to power up the ABTRONIC™TX control unit. 2. Select the intensity by pressing the “+”/”-” button repeatedly. The LED light up and the flashing speed is proportion to the output intensity.
  • Page 21 PAGE 21 3. Push the ON/HI button several times to carefully increase the intensity. Adjust the intensity according to your comfort level. You should feel a light tingling.
  • Page 22 PAGE 22 ABTRONIC™TX USER MANUAL Push HI button 10 x to increase intensity 10 steps 0 <> 1 <> 2 <> 3 <> 4 <> 5 <> 6 <> 7 <> 8 <> 9 <> 10 Push LOW button 10 x to decrease intensity 10 steps 4.
  • Page 23 “1”. If ABTRONIC™TX is removed during use, the intensity is automatically reset to “1”. If it is not placed back into contact with the skin, the unit will turn off after 20 seconds.
  • Page 24 Important Notes If there is no gel pad on the ABTRONIC™TX, or if it is not placed tightly against the skin, an uncomfortable tingling sensation can occur.
  • Page 25  Hint: VERY IMPORTANT: You MUST apply a gel pad to ABTRONIC™TX that is not worn or dirty. The ABTRONIC™TX must make contact with your skin. It will not work through clothing.
  • Page 26 PAGE 26 ABTRONIC™TX USER MANUAL TAKING CARE OF YOUR UNIT The ABTRONIC™TX is made of quality materials. only maintenance required with ABTRONIC™TX is to clean the conductive area gently, while you are replacing the gel pad, with a wet cloth and soapy water, further the battery needs to be replaced.
  • Page 27 PAGE 27 Batteries, last for approx.100 sessions of ten minutes. If the output becomes weak or the unit switches off automatically in less than 10 minutes, it is time to change the batteries (even if the LED is still lit up). The electronic control unit is built very reliable and uses SMT technology.
  • Page 28 PAGE 28 ABTRONIC™TX USER MANUAL If the gel pad are worn out, or dirty, an uncomfortable tingling sensation can occur. This can also happen if the body has built up excessive oil on the skin. DO NOT bend the conductive areas.
  • Page 29 PAGE 29 MAINTENANCE & DAMAGE „ If the unit is not functioning properly or cause discomfort, stop using it immediately. „ Pause ABTRONIC™TX before remove/move stimulate region. „ Use only for the specific pain problem diagnosed by professionals. „ Consult your local authorities for proper battery...
  • Page 30 PAGE 30 ABTRONIC™TX USER MANUAL WARNINGS „ Never use this unit near the heart, around the mouth, or on diseased skin. „ Do not use this unit in places with high humidity such as the bathroom. „ May need to use under the supervision of a physical therapist.
  • Page 31 PAGE 31 „ Do not use ABTRONIC™TX during the first 12 weeks of pregnancy. „ Consult a doctor before you use this device if you receive other medical treatments. „ Do not disassemble or remodel this unit. „ Do not use this unit while sleeping, driving or bathing.

  • Page 32: Troubleshooting Guide

    PAGE 32 ABTRONIC™TX USER MANUAL TROUBLE SHOOTING GUIDE PROBLEM POSSIBLE CAUSE SOLUTION LEDs do not Batteries are Install batteries „ „ light up at all not installed Batteries Check polarity „ „ are installed “+” sign incorrectly. Batteries are Replace „...
  • Page 33 Controller not Check that „ „ connected controller is to the pad connected correctly firmly with ABTRONIC™TX pad. Increase intensity „ by pushing the up button Controller hang Perform a „ „ RESET, remove Batteries for 1...
  • Page 34 PAGE 34 ABTRONIC™TX USER MANUAL LEDs light up, Intensity set to Increase „ „ but nothing low level intensity by occurs pushing the up button Worn or dirty Make sure the „ „ gel pad. gel pad are still adhesive Otherwise use „...
  • Page 35 PAGE 35 LEDs light up, Microprocessor Perform a „ „ but all buttons hang up RESET, remove do not work batteries for 1 minute for full RESET Battery is low Change Battery „ „...
  • Page 36 PAGE 36 ABTRONIC™TX USER MANUAL IMPORTANT: POWER RESET If the unit does not switch on, or if you can’t change to different programs, the microprocessor may have “hanged”. Please perform a simple RESET by removing batteries and replace them after one minute.

  • Page 37: Product Specification

    PAGE 37 PRODUCT SPECIFICATION Power CR2032 Lithium 3V Pulse Rate 70Hz Pulse Width 200µs Output Voltage Max. 65 Vpp, based on 500 Ω load ±-10% Treatment Time 10 minutes; auto-off Pulse Strength 0 ~ 15 stages adjustable Operation -10 ~ 40ºC, 30 ~ 85% Relative Humidity Environment Storage -10 ~ 50ºC, 10 ~ 95% Relative Humidity...
  • Page 38 Electromagnetic Emissions-For all EQUIPMENT and SYSTEMS Guidance manufacture’s declaration- electromagnetic emission The “ABTRONIC™TX” is intended for use in the electromagnetic environment specified below; The customer or the user of the “ABTRONIC™TX” should assure that it is used in such and environment.
  • Page 39 PAGE 39 Electromagnetic Emission test Compliance environment- guidance “ABTRONIC™TX” uses RF energy only for its internal function. Therefore, RF emissions Group 1 its RF emissions are CISPR 11 very low and are not likely to cause any interference in nearby electronic...
  • Page 40 PAGE 40 ABTRONIC™TX USER MANUAL RF emissions Class B CISPR 11 “ABTRONIC™TX” is suitable for use in Harmonic emissions Class A all establishments, IEC 61000-3-2 other than domestic and those directly connected Voltage to the public low- fluctuations/flicker voltage power...
  • Page 41 Electromagnetic Immunity - For all EQUIPMENT and SYSTEMS Guidance manufacture’s declaration – electromagnetic immunity The “ABTRONIC™TX” is intended for use in the electromagnetic environment specified below. The customer or the user of “ABTRONIC™TX” should assure that it is used in such an environment.
  • Page 42 PAGE 42 ABTRONIC™TX USER MANUAL Electromagnetic IEC 60601 Compliance Immunity test environment test level level -guidance Floors should be wood, concrete or ceramic Electrostatic tile. If floor ±6 kV discharge ±6 kV contact are covered contact (ESD) IEC ±8 kV air with synthetic ±8 kV air...
  • Page 43 PAGE 43 Mains power quality should ±1 kV line to ±1 kV line to be that of Surge IEC line line a typical 61000-4-5 ±2 kV line to ±2 kV line to commercial ground ground or hospital environment. Power frequency magnetic Power fields should...
  • Page 44 PAGE 44 ABTRONIC™TX USER MANUAL Mains power <5% UT quality should be (>95% dip <5% UT that of a typical in UT) (>95% dip in commercial for 0.5 cycle UT) for 0.5 or hospital cycle environment. If Voltage 40% UT...
  • Page 45 SYSTEMS that are not LIFE-SUPPORTING Guidance manufacture’s declaration – electromagnetic immunity The ABTRONIC™TX” is intended for use in the electromagnetic environment specified below. The customer or the user of the ABTRONIC™TX” should assure that it is used in such an environment.
  • Page 46 Portable mobile communications equipment should be used no closer to any part of the “ABTRONIC™TX”, including cables, than the recommended separation distance calculated from the equation applicable to the frequency of the transmitter. Recommended separation distance 3 Vrms...
  • Page 47 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the “ABTRONIC™TX” is used exceeds the applicable RF compliance level above, the “ABTRONIC™TX” should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the “ABTRONIC™TX”...
  • Page 48 Recommended separation distances between portable and mobile RF communications equipment The “ABTRONIC™TX” is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the “ABTRONIC™TX” can help prevent electromagnetic interference...
  • Page 49 PAGE 49 Rated Separation distance according to frequency of transmitter (m) maximum output power of 150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2.5 GHz transmitter 0.01 0.35 0.12 0.23 0.37 0.73...
  • Page 50 PAGE 50 ABTRONIC™TX USER MANUAL For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
  • Page 52 This product is brought to you by: AbTronic by Red Lemon Incorporation www.abtronic.co © by Red Lemon Incorporation MMXV RLTX Eng V1. , 97x97...
