Offel PO 150 G series User Manual

User manual
Parabole in alluminio serie PO 150 G
Aluminium satellite dishes PO 150 G series
art. 11-135
PO 150 G

TECHNICAL SPECIFICATIONS

OP150S
Frequency range (GHz)
Outside dimension (cm)
Reflecting dimension (cm)
Illumination efficiency * (%)
Gain * @ 10.70 GHz (dBi)
Gain * @ 11.70 GHz (dBi)
Gain * @ 12.75 GHz (dBi)
Cross polarization * on axis (dBc)
First side lobe level * (dBc)
Noise temp. * @ 12GHz, 36° elevation (K)
F/D radio
3dB Beam width* @ 11.7GHz
Offset pointing angle
WARNINGS
We strongly encourage you to read this manual before installation and use
of the product and strictly observe the recommendation hereof.
OP150S
satellite offset antenna Ø 150cm
Offel s.r.l. Via Lato di Mezzo, 32 Lugo (RA) - Italy
GIBERTINI
®
10.00 - 13.00 Feed illumination angle
155.0 x 166.0 Feeder clamp (mm)
150.0 x 161.0 Elevation angle
70
43.00 Mast clamp (mm)
43.70 Alu reflector thickness (mm)
44.50 Steel reflector thickness (mm)
- 28
Antenna net weight (kg.)
- 25
31 Wind load @ 120 km/h (kg) [worst-case]
0.66 Working temperature
1.07° Humidity
21.3°
The producer
Tel. +39 0545/22542
®
70°
40 / 23
20° - 90°
55 - 100
2.0
not available
alu 23,8
steel n. a.
250
- 30° / + 70°
0 – 100%
-
Installation Guide
-
-
-
Fax +39 0545/30439 P.I. 00449020395
Made in Italy
Rev. 0 01.2017
pag. 1
