SECUDRIVE USB CAD
User Guide
Doc Ver. 2.0.5.383
2013-12-23
Brainzsquare, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SECUDRIVE USB CAD and is the answer not in the manual?

Questions and answers

Summary of Contents for Brainzsquare SECUDRIVE USB CAD

  • Page 1 SECUDRIVE USB CAD User Guide Doc Ver. 2.0.5.383 2013-12-23 Brainzsquare, Inc.

  • Page 2: Table Of Contents

    Features ....................................3 1.2 Product ..............................4 Glossary ....................................4 How to use SECUDRIVE USB CAD ....................5 Running the Login Program Manually ........................5 Agreeing to the End User License Agreement (EULA) .................. 5 Setting up the Password ............................. 6 User Info ....................................

  • Page 3: Overview

     Prevent Copy & Paste: Data saved in the USB stick is prevented from being copied to a local disk or other removable disks.  Prevent Save As: Saving a file in SECUDRIVE USB CAD to a local PC with another name (Save As) is also denied.

  • Page 4: Product

    For both options, the product runs in administrator mode.  User PC: User’s PC where SECUDRIVE USB CAD is connected to.  Secure zone: Data saving area of SECUDRIVE USB CAD. A user can only access this area by executing the login program with the correct password.

  • Page 5: How To Use Secudrive Usb Cad

    2. How to use SECUDRIVE USB CAD 2.1 Running the Login Program Manually License agreement or the login window automatically displays when SECUDRIVE USB CAD is  connected to PC. If either the license agreement or the login window does not appear, you should manually run the login program.

  • Page 6: Setting Up The Password

    SECUDRIVE USB CAD User Guide 2.3 Setting up the Password At your first use of the product, you should set up your login password to access the secure zone.  The password must be more than 6 alphanumeric characters. ...

  • Page 7: Auto-Notification

    SECUDRIVE USB CAD User Guide check box near the bottom. Click ‘Next’ to continue. This section is optional so click ‘Next’ to skip this section.  2.5 Auto-notification Choose whether or not you wish to have automatic notifications for the latest updates for USB CAD.

  • Page 8: Drm Policy Management Setting

    SECUDRIVE USB CAD User Guide 2.6 DRM Policy Management Setting  After setting the password, click OK and the DRM Policy Management window is displayed.  Use this PC for DRM policy management: DRM policy setup and change is only available on the current PC where the USB flash drive is connected to.

  • Page 9: Features Of Usb Cad

    SECUDRIVE USB CAD User Guide 2.8 Features of USB CAD To change the auto lock and DRM policy settings, right-click on the SECUDRIVE icon in the windows  task bar. Click “Finish” to proceed to login.  2.9 Login...

  • Page 10: How To Use The Vaccine Program

    SECUDRIVE USB CAD User Guide  The login window will be displayed as follows. Enter the configured password and click “OK” to login.  To execute the device in read-only mode, check “Login as read-only” and login.  After 10 consecutive incorrect password inputs, the USB flash drive is locked and unavailable.
  • Page 11 SECUDRIVE USB CAD User Guide Click “Finish” to complete installation.  Once installed, the vaccine program initiates when USB flash drive is logged in and the icon is  displayed in the system tray. The program terminates when the USB flash drive is logged out.
  • Page 12 SECUDRIVE USB CAD User Guide The vaccine program runs for 1 year from the date of agreement. After 1 year, it stops operation. To  continue Trend Micro USB Security service, the user should purchase the license update tool and extend the period.

  • Page 13: Secudrive Usb Cad Menu

    SECUDRIVE USB CAD User Guide 2.11 SECUDRIVE USB CAD Menu Right click the tray icon and you will see the menu as follows.   Shortcut to Secure Zone: Access the secure storage area of the USB flash drive.  Change Password: You can change the login password.
  • Page 14 SECUDRIVE USB CAD User Guide [Auto Lock] Right click on the tray icon and select “Auto Lock”.  If keyboard and mouse are not in use for a designated time period, the secure zone will lock.  It is set to “Never” by default. Select your own time period and click “OK”.
  • Page 15 SECUDRIVE USB CAD User Guide [DRM Policy Settings] Right click on the tray icon and select “DRM Policy Settings”.  The DRM Policy Settings window will be displayed as follows. ...

  • Page 16: Usb Settings Tab

    SECUDRIVE USB CAD User Guide This window has two tabs, USB Settings and DRM Settings.  2.12 USB Settings Tab [Secure Zone Access] Read-only: Set the USB flash drive in read-only mode. When you login again after setting this ...
  • Page 17 SECUDRIVE USB CAD User Guide If you set “Pin Code Authentication” to ON, you can set the pin code in the following window.  If the master token already has a pin code, you should enter it to set “Pin Code Authentication” to ...
  • Page 18 To use the product again, the stored logs should be deleted on the policy setup PC.  No log: It does not save any event log from SECUDRIVE USB CAD.  View: You can view the stored logs.
  • Page 19  Time sync with: Check the valid period based on the internet time server which provides standard time. To use this feature, the PC where SECUDRIVE USB CAD is connected must have access to the Internet. If the PC cannot communicate with the internet time server, the USB flash drive cannot be used.

  • Page 20: Drm Settings Tab

    SECUDRIVE USB CAD User Guide 2.13 DRM Settings Tab Press the DRM Settings tab at the top to modify DRM policy. ...
  • Page 21 SECUDRIVE USB CAD User Guide [DRM Settings] [Apply Data Leakage prevention]  Prevent copying files out of the secure zone of the USB flash drive If it is set “ON”, the file saved in the USB flash drive is prevented from being copied out of the device ...
  • Page 22 SECUDRIVE USB CAD User Guide [Secure Process Settings] Click “Settings” and the following window will be displayed. Only the selected application from the  “Secure Process List” can access the secure zone of the USB flash drive. For example, if you only select ‘AutoDesk Autocad’ from the “Secure Process List”...
  • Page 23 SECUDRIVE USB CAD User Guide For selected applications that can access the secure zone, network connection is blocked by default.  You can make exceptions and allow network access for designated processes by changing the  “Allowed IP”, “Allowed Port”, or “Allowed URL”.
  • Page 24 SECUDRIVE USB CAD User Guide After selecting an item(s) on the list, click by “Allowed IP”, “Allowed Port”, or “Allowed  URL” to change the secure network settings as follows.  No item is set (All network settings are “NULL”): All network paths are blocked.
  • Page 25 SECUDRIVE USB CAD User Guide  Allowed Port Settings: Enable access by certain Port. Type in the Port number and click “Add. ”  Allowed URL Settings:Enable access by certain URL. Type in the URL and click “Add.”...
  • Page 26 SECUDRIVE USB CAD User Guide [User Information] Right click the tray icon and select “Information” “User Information”.  In the window below, fill in items and click “OK”.  If you have checked “View user information before login”, you can view user information in the ...
  • Page 27 SECUDRIVE USB CAD User Guide [About SECUDRIVE] Right click the tray icon and select “Information” “About SECUDRIVE”.  You can view hardware and software information of the USB flash drive. ...

  • Page 28: Unlocking The Usb Flash Drive

    SECUDRIVE USB CAD User Guide [Close] Right click the tray icon and select “Close”.  When you close the program, the secure zone is logged off and you can remove the USB flash drive  from the PC. 2.14 Unlocking the USB Flash Drive Drive will lock and a user cannot log in to the device any more.

  • Page 29: Running The Product With Administrator Privileges In Windows Vista / 7

    To use the product in user mode on the PC for the first time, a user should run the login program with  administrator privileges. Right click CD area of SECUDRIVE USB CAD and click “Open”.  Right click on Login.exe and select “Run as administrator”.

  • Page 30: How To Uninstall Secudrive Agent

    SECUDRIVE USB CAD User Guide When you run “Login.exe” with administrator privileges, the SECUDRIVE Agent installation  message will be displayed as follows. Click “Yes” to continue installation. For the installed SECUDRIVE Agent program, you can uninstall it by executing “Uninstall.exe” in ...
