Summary of Contents for Monoprice 18806
- Page 1 Gooseneck Microphone and LED Light MIC 1 TREBLE MIC 2 BASS MIC 3 AUX 1 MIC 2 AUX 1 REC OUT PRE-OUT 1 - GND 2 - HOT 3 - COLD 18806 Made in China POW ER 50-6 0Hz AC 120V 18806 User’s Manual...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. Do not install this device on an unstable surface where it could fall and cause either personal injury or damage to the device and/or other equipment. - Page 3 Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or detergents. For stubborn deposits, moisten the cloth with warm water. This device has no user serviceable parts. Do not attempt to open, service, or modify this device.
-
Page 4: Customer Service
If you have any problem with your order, please give us an opportunity to make it right. You can contact a Monoprice Customer Service representative through the Live Chat link on our website www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat- Sun: 9am-6pm PT) or via email at support@monoprice.com... -
Page 5: Product Overview
PRODUCT OVERVIEW 1. Gooseneck microphone 2. Gooseneck LED lamp 3. Light switch 4. Lectern top 5. Lectern apron 6. MIC 1 volume control 7. MIC 2 volume control 8. MIC 3 volume control 9. Treble control 10. Bass control 11. AUX 1 volume control 12. - Page 6 ASSEMBLY Perform the following steps to assemble the lectern. 1. Place the Lectern Column upside down on the floor. 2. Using a #2 Phillips screwdriver, remove the 6 screws from the bottom of the Lectern Column. 3. Place the Lectern Base on the bottom of the Lectern Column with the screw holes aligned.
- Page 7 15. Using the screws removed in step 10 and a #2 Phillips screwdriver, attach the Lectern Top to the Lectern Apron. 16. Ensure that the Lamp Switch on the underside of the Lectern Top is in the off position. 17. Plug the Gooseneck Microphone into the MIC XLR connector on the upper side of the Lectern Top.
-
Page 8: Operation
LED Lamp on or off. TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates. -
Page 9: Specifications
SPECIFICATIONS Model 18806 Output Power 60 watts Frequency Response 80 Hz ~ 16 kHz Total Harmonic Distortion less than 0.5% Signal-to-Noise Ratio more than 65dB Bass Control Range ±10dB Treble Control Range ±10dB Pre Out Sensitivity 1V ±20mV Rec Out Sensitivity 200mV ±20mV... - Page 10 Modifying the equipment without Monoprice’s authorization may result in the equipment no longer complying with FCC requirements for Class B digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any interference to radio or television communications at your own expense.
