ThePondguy ClearVac Installation & Maintenance Manual

ThePondguy ClearVac Installation & Maintenance Manual

Dual-chamber pond vacuum

Advertisement

REPLACEMENT PARTS:

18
NUMBER
NAME
1
Collection Chamber
160277
2
Handle
160241
3
Intake Distributer
160242
4
Filter Foam
160243
5
Clamp Replacement Kit
160244
6
Suction Hose – 13' x 1.5"
160246
7
Discharge Hose – 8'
160247
8
Gravel Nozzle
160248
9
String Algae Nozzle
160249
10
Filter Retainer Plate
160266
WARRANTY:
All ClearVac™ Vacuums carry a 3-year warranty. The Pond Guy® will repair or replace any units found to be defective. This
limited warranty is extended exclusively to the original purchaser and begins from the date of original purchase receipt. The
filter foam and o-rings are wearable items and are not covered by this warranty. Abuse or misuse of this product, power cord
alterations or use of an improper extension cord voids all warranty. Please call for a Return Authorization Number prior to
returning product by calling our Customer Care Department at 866-766-3435. Failure to request an RMA number may result
in delay or dismissal of your warranty claim.
THANK YOU FOR CHOOSING:
The Pond Guy
®
Inc.
866-POND-HELP (766-3435)
thepondguy.com
We Know Ponds
15425 Chets Way
Armada, MI 48005
8
View other great products on-line at www.thepondguy.com
19
SKU
NUMBER
NAME
11
Suction Extension Tube (Black)
12
Suction Extension Tube (Clear)
13
Narrow Nozzle
14
Replacement Plug
15
Wide Nozzle
16
Wheel
17
Debris Bag
18
Vacuum Seal Replacement Kit
19
Vacuum Distributer Assembly
SKU
160267
160268
160269
160278
160271
160272
160273
160274
160275
Table of Contents:
Important Information. . . . . . . . . . . . . . . . . . . . . . . . 2
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Technical Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . 4-5
Using Your ClearVac™ Vacuum . . . . . . . . . . . . . . . . . . 6
Maintenance, Storage & Troubleshooting . . . . . . . 7
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Warranty Information. . . . . . . . . . . . . . . . . . . . . . . . . 8

ClearVac
Dual-Chamber Pond Vacuum
Installation & Maintenance Manual
(Item # 160192)
3 Year Warranty

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ClearVac and is the answer not in the manual?

Questions and answers

Summary of Contents for ThePondguy ClearVac

  • Page 1 ® Inc. 866-POND-HELP (766-3435) thepondguy.com Using Your ClearVac™ Vacuum ....6 We Know Ponds ™ 15425 Chets Way Maintenance, Storage & Troubleshooting ..7 Armada, MI 48005 Replacement Parts .
  • Page 2 • Prior to installation, inspect the ClearVac™ Vacuum to ensure there was no damage during transportation. • If the ClearVac™ Vacuum falls into the water, DO NOT reach for it. First unplug and then retrieve it. • Close supervision is necessary when used near children.
  • Page 3 Attach the Extension Tubes Attach extension tubes to the suction hose. The clear Attach Wheels extension tube will allow you to monitor the ClearVac™ Attach the wheels to the rear base of the ClearVac™. performance. Step 8 Step 3 Choose a Nozzle...
  • Page 4 For your protection, always unplug the ClearVac™ from your power source before servicing. Little or no suction is produced: • Be sure the ClearVac™ is positioned at or near water level.
