Table of Contents

Advertisement

Quick Links

Download this manual
Kadey-Krogen Yachts
Owner's Manual

Hull Number 5814
February, 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5814 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kadey-Krogen Yachts 5814

  • Page 1 Kadey-Krogen Yachts Owner's Manual   Hull Number 5814  February, 2008...
  • Page 2 Kadey-Krogen 58’ Pertinent Information Hull #5814 General Specifications LOA: 62’11” AC Voltage/Service: 110v/50 amp. LWL: 52’3” DC Voltage: 12v /24v Beam 18’1” Fuel Tank Capacity: 1,760 gals. (Molded) Beam 18’10” Water Tank Capacity: 450 gals. (Over Rub Rail): Draft: 5’3”...

  • Page 3: Table Of Contents

    Stateroom/Den ......................22 Guest Head........................ 22 Engine Room ......................23 Bow Thruster Compartment ..................23 Forward Machinery Space ..................23 Amidships Machinery Space ..................24 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 4 Cablemaster System Basic Service and Maintenance ..........56 Davit System ........................57 Operation........................57 Davit System Basic Service and Maintenance.............. 60 Digital Stabilizers ......................61 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 5 Figure 13 – Top Down View – Lower Deck ..............97 Exhaust System ....................... 99 Propulsion Engine Exhaust ................... 99 Generator Exhaust......................99 Exhaust System Basic Service and Maintenance............100 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 6 Switching from Shore Power to Generator..............133 Switching from Generator to Shore Power..............134 Shutdowns and Alarms ....................135 Generator Basic Service and Maintenance ..............136 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 7 Initialization ........................ 159 Operation........................160 Station Transfer......................160 Control Head Tones ....................160 Engine Control System Basic Service and Maintenance..........162 General Cleaning ....................162 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 8 Lowering the anchor ....................192 Raising the anchor....................193 Capstan (Warping Drum) Operations ................. 194 Windlass Basic Service and Maintenance ..............195 Windshield Wiper/Washer System ................197 Operation........................197 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 9 HOUSEKEEPING ......................221 Convenience Features....................223 Watch Berth ........................ 223 Convertible L Shaped Settee..................223 Table ........................... 223 Cable TV Outlets ......................223 Phone Outlets ......................224 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 10 Generators ....................... 244 Propulsion Engines ....................245 Raw Water Washdown ................... 245 Refrigerator ......................245 Winterizing ........................247 Air Conditioning ..................... 247 Battery System ......................248 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. viii Krogen 58’ Manual, Hull 58014...
  • Page 11 Sanitary System ...................... 265 Stabilizers........................ 265 Steering System ...................... 266 Transmission ......................266 Windshield Wiper/Washer System ................. 266 Appliances........................266 Microwave ......................266 Refrigerator ......................266 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 12 Component Manufacturers List – Sorted by Manufacturer ........301 Component Manufacturers List – Sorted by Component ........... 317 APPENDICES ....................... 337 Appendix A – Inspection Check List................339 Pre-Start ........................339 Battery........................339 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 13 Six Months ........................344 Antivibration System ....................344 Digital Stabilizers....................344 Fire Suppression System..................344 Steering System ...................... 344 Transmissions ......................344 Windlass........................344 Annually........................345 Bonding........................345 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 14 Stabilizer System ....................383 Windlass........................383 Interior......................... 383 Appliances....................... 383 Owner Installed Equipment ..................385 Appendix H - Approved Service Centers..............387 Appendix I - Warranties ....................389 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 15 Appendix N - VHF Channel Usage ................407 NOAA Weather Radio Frequencies................409 NATO Phonetic Alphabet................... 409 Appendix O - Notes....................... 411 GLOSSARY........................415 INDEX..........................423 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. xiii Krogen 58’ Manual, Hull 58014...

  • Page 17: Table Of Figures

    Figure 21 – Clear Water Waste Schematic ..............181 Figure 22 – Steering System Schematic ................. 187 Figure 23 – Exalto Wiper Control Panel................. 197 Figure 24 – Docking Plan ....................233 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. TABLE OF FIGURES...

  • Page 19: Introduction

    INTRODUCTION About Your Owner’s Manual ……………………………………………………………. 3 Owner’s Information Record and Details …………………………………………………5 Warranty Information ………………………………………………………………..7 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 INTRODUCTION...

  • Page 21: About Your Owner's Manual

    A prudent owner or operator will rely not only on a recommended maintenance and servicing schedule, but consider all other variables that may have an impact on a safe and successful voyage. These considerations should include, but not necessarily be limited to: ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 22 FOUND IN THE EQUIPMENT MANUFACTURER’S MANUAL IS TO TAKE PRECEDENCE. While we have made every effort to be accurate, we at Kadey-Krogen Yachts, accept no responsibility for damage or injury resulting from misunderstanding of, or omission from the contents of this manual. Furthermore, we do not accept liability for any personal injuries or damage occurring as a result of misuse of the equipment, or as a result of badly maintained equipment.

  • Page 23: Owner's Information Record And Details

    (State or Country) Completely fill out the owner’s information record and keep it updated. Store it with your owner’s manual in a secure and accessible location. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Owner’s Information Record and Details...

  • Page 25: Warranty Information

    KADEY-KROGEN YACHTS, INC. LIMITED WARRANTY Kadey-Krogen Yachts, Inc. (the “Seller”) warrants that the hull and superstructure of the Yacht shall be free of defects in material and workmanship for a period of one (1) year from date of delivery of Yacht to the Buyer, subject to extension to: (a) five (5) years...
  • Page 26 To obtain warranty service, the Buyer must notify the Seller, in writing, of the alleged defect within the relevant warranty period and no more than thirty (30) days of the defect’s having become apparent. The Buyer’s notice must be sent to: Kadey-Krogen Yachts, Inc. 815 Colorado Ave., Suite 101 Stuart, FL 34994 via overnight courier (e.g., Federal Express or DHL) or facsimile transmission to (772)

  • Page 27: Vessel Specifications

    VESSEL SPECIFICATIONS Vessel Specifications …………………………………………………………………… 11 Construction ……………………………………………………………………………. 13 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. VESSEL SPECIFICATIONS Krogen 58’ Manual, Hull 58014...

  • Page 29: Vessel Specifications

    1,780 Nautical Miles (3,296.56 km) 10 knots 1,240 Nautical Miles (2,296.48 km) Calculated with 176-gallon reserve (10%) and 1 gallon-per-hour additional for genset consumption. Ranges are approximate ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Vessel Specifications Krogen 58’ Manual, Hull 58014...

  • Page 30: Hydrostatic Data

    3,425 lbs. (1,553.58 kg) Moment-To-Trim One Inch 10,070 ft. lbs. Longitudinal Center of Buoyancy (LCB) 52.5% (Aft) Longitudinal Center of Flotation (LCF) 55.9% (Aft) ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Vessel Specifications Krogen 58’ Manual, Hull 58014...

  • Page 31: Construction

    Krogen 58’ more comfortable in all weather and climate conditions. As a result, the yacht is quieter and easier to heat and cool. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 32: Decks

    The laminate is fabricated by the contact or hand-lay up process for either single-skin or sandwich construction. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Construction...

  • Page 33: Quality Control

    The ends of all internal structural members are to provide end-fixity and load transmission to the supporting member. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 34: Fastening

    Shanks of all threaded fastenings are long enough to pass through the joints. Where watertight joints are required, suitable sealants or bedding compounds are used in addition to the fastenings. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Construction...
  • Page 35 Joints are lapped and bolted. Where flanges are used, the hull flanges are equal in thickness to the hull laminates, and the deck flanges are equal in thickness to the deck laminates. Faying surfaces are set in “3M 5200” Polyurethane Adhesive/Sealant. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 36: General

    Starboard FRP weather door, hot/cold fresh water transom shower, a fresh water washdown spigot, fiberglass swim platform, a Lazarette, emergency tiller, convenience cabinet with sink and storage space, and two remote controlled Glendinning® Cablemaster systems. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Construction...

  • Page 37: Portuguese Bridge

    Anchor Locker. There are two Shore Power Connections, and a TV/Cable and phone connection. There is ample storage below the Portuguese bridge seats. There is an additional fresh water spigot below the Portuguese bridge seat on the Starboard side. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Construction...

  • Page 38: Interior

    4 burner propane Range with oven; a GE combination Microwave- Convection oven and exhaust fan is installed over the range; a Miele® Dishwasher; and a GE Trash Compactor. The Galley has a deep stainless steel sink with GE Garbage ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 39: Pilothouse

    The Master Stateroom located Forward has a full 6 feet 10 inches of head room. Natural ventilation is provided via four 8” x 16” (20.32 cm x 40.64 cm) stainless steel port holes ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 40: Master Head

    Formica®. The shower compartment is molded fiberglass with bi-fold door. The household size toilet is SeaLand VacuFlush® with status panel, push button flush, and Hush/Flush seat gasket. The toilet is fresh water flush. The basin is Corian® white, with ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 41: Engine Room

    SeaLand® vacuum tanks and pumps for both Heads. The holding tank vent filter is on the Starboard side overhead. Also located in this compartment are the Raw Water Washdown intake seacock and sea strainer, and the Groco PJRW pump. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 42: Amidships Machinery Space

    Glendinning® Cablemaster systems, the circuit breakers for Shore Power 1 labeled “inlet #4” and for Shore Power 2 labeled “inlet #3”. There is ample storage space in this compartment. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 43: Systems Operation & Basic Maintenance

    Should there be a discrepancy between information found in this manual, and information found in the manual provided by an equipment manufacturer, THE INFORMATION FOUND IN THE EQUIPMENT MANUFACTURER'S MANUAL IS TO TAKE PRECEDENCE. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 45: Air Conditioning System

    There are five SMXir Keypad/Display thermostat units each controlling the temperature in the area in which it is located. One is located in the Main Saloon, one in the Master ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 46: Basic Operation

    6. Turn ON the circuit breaker on the 24V DC Main Panel Disconnect labeled ‘# 2 CONDENSATE DRAIN PUMP’ if operating the air conditioning unit for the Galley and the Main Saloon. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 47: Remote Fan Operation

    In automatic mode, the fan speed is determined by the unit as a function of the difference between the temperature setting on the thermostat and the inside temperature. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 48: Fan Speed Adjustment

    In cycle mode, the fan cycles on and off with the compressor. See the SMX II Control Systems (DX) Installation-Operation Manual for more information. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Air Conditioning System...

  • Page 49: Air Conditioning Basic Service And Maintenance

    3. Clean with mild liquid soap and warm water. 4. Let dry in the sun. 5. Replace when completely dry. 6. Turn ON the unit at the SMXir Keypad/Display. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Air Conditioning System...
  • Page 50 • Warm water The refrigerant gas used in your Cruisair system is adequate for the life of the system. Routine ‘seasonal’ charging of the system is not typically necessary. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Air Conditioning System...

  • Page 51: Air Horn System

    Key Pad In addition to the ‘HORN’ button, the Air Horn can be activated by the key pad located Starboard side of the steering wheel in the Pilothouse. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Air Horn System...

  • Page 52: Figure 1 - Kahlenberg Display

    Air Horn for that code will start after a 10 second delay. A new code can be selected at any time during automatic operation and will commence after the 10 second delay. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 53 USCG regulation. To change the cycle time, depress and hold the ‘AUTO ON/OFF’ button for five seconds and then release. The next LED will be lit. Continue this until the desired interval is indicated by the LED. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 54: Air Horn System Basic Service And Maintenance

    • Carnauba wax • Non-abrasive polishing product such as “Flitz” or “Simi- chrome” chrome polish • Soft cloth • Windex (or equivalent) ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Air Horn System Krogen 58’ Manual, Hull 58014...

  • Page 55: Antivibration System

    Aquadrive® resilient mounts. See Equipment List for complete details on system parts. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 56: Antivibration System Basic Service And Maintenance

    Check all bolts after 50 hours of operation and 100 hours thereafter. Every six months, spray the units with two coats of a corrosion protector. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 57: Battery System

    All batteries are the Absorbed Glass Mat (AGM) type provided by Lifeline Batteries and are maintenance free, other than charging and Equalization. ©2009, Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 58: Battery Charging

    • The ship’s service/house batteries charge the engine start battery bank through the Balmar Digital Duo Charge. • 12V DC Dolphin Battery Charger charges the Generator start batteries. ©2009, Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Battery System...

  • Page 59: Battery Equalizer

    Flybridge, is to extract 12V DC service from the NAV./COM. battery bank for equipment and accessories needing 12V DC, while electronically maintaining battery voltage balance (equalization). This prevents overcharging and damage to the batteries. ©2009, Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 60: Battery Operation

    When conditions return to normal, position the parallel switch to its original setting. CAUTION To prevent overloading of the alternators, ship’s service/house batteries should be fully charged before engaging parallel switches. ©2009, Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Battery System...
  • Page 61 Equalize procedure built into the battery charger basically charges the batteries at 31 volts for eight hours and returns to normal charging operation when Equalizing is completed. The Xantrex Inverter/Charger does not require periodic maintenance. ©2009, Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 62: Bilge System

    1 ¼ inches (31.8 mm). If the PUMPSWITCH™ SENIOR housing fills with 3 ½ inches (89 mm) of water, the High Water Alarm in the Pilothouse will activate with a very loud 105 decibels. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 63: Forepeak

    Island Queen berth in the Master Stateroom and locate the two valves in Forward section of this compartment under the mattress. One valve is in the center of the bulkhead between the anchor locker and the compartment under the mattress. This valve is ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 64 OPENED position. As a reminder that sea cocks have been left in the CLOSED position, you may want to attach the engine start keys to one of the ‘closed’ handles. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 65: Bilge System Basic Service And Maintenance

    6. Replace the High Water Alarm unit back into the cabinet. 7. Test the High Water Alarm by moving the toggle switch to ‘TEST’. 8. Leave the toggle switch in the ON position. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 68: Bonding System

    Generators. The inspection and possible replacement of those anodes is covered in other sections of this manual. The Stabilizers have two zinc anodes; one on each fin. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 69: Bonding System Basic Service And Maintenance

    An anode that is even slightly loose will not be doing its job. After these checks, if an anode still appears to have not deteriorated, there is a possibility that the anode contains impurities which could make the anode ineffective. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 70 The NewMar® Galvanic Isolators normally requires no maintenance. However, if you suspect an Isolator is not performing satisfactorily, follow the Troubleshooting procedure as outlined in the NewMar® Installation Guide. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Bonding System...

  • Page 72: Bow Thruster

    The light in the button will illuminate. 8. Push the jog lever in the direction you want the Bow to move. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 73: Hydraulics

    Master Stateroom, Starboard side, which provides oil to the thruster motor. Keep the header tank approximately half full of oil and use ONLY Chevron Delo Gear Lubricant SAE 80-90. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Bow Thruster...

  • Page 74: Cablemaster System

    4. Unlock the hawse pipe cap from its upright position and secure it over the hawse pipe opening. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Cablemaster System...

  • Page 75: Remote Operation

    At least once a year, check all wiring connections to be sure they are secure and free of corrosion. Check the neoprene covers on the in-limit and power switches to be sure they are free of cracks or fracture. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 76: Davit System

    11. Rotate the Davit over the tender. 12. Lower the cable to the tender by operating “WINCH DOWN”. 13. Attach the lifting bridle to the weighted hook. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Davit System...
  • Page 77 9. Rotate the Davit so the tender is positioned over the cradles. DO NOT rotate the tender with the boom below 30º angle. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 78 16. Attach the boom tie-down assembly to the underside of the Davit’s boom. 17. Turn OFF the ‘BOAT DAVIT’ circuit breaker. 18. Unplug the hand-held controller and store in a dry, secure location. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 79: Davit System Basic Service And Maintenance

    1200-2 Hydraulic Davit System Operations Manual”. It will take approximately 1.5 gallons (5.6 L) of hydraulic oil to fill the reservoir. Never use automatic transmission or aircraft fluid in the Davit hydraulic system. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 80: Digital Stabilizers

    The pump on the Port engine is the default pump. If the Port engine is not available, press the STBD PUMP button to make the Starboard pump available for the Stabilizers. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 81: Position Indicator Bars

    Fins automatically go to CENTER when transmission goes into reverse. However, BEFORE applying rpm, glance at the Position Indicator Bars on the Home screen to ensure fins are in CENTER position. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 82: Alarm Button

    SPEED Screen The Stabilizer’s control processor must know the vessels speed to function properly. This is done by a photoelectric speed sensor on the propeller shaft. On the SPEED screen, ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 83: Enabling One Fin Only

    The yokes will then remain locked in a near center position even in the absence of system hydraulic power. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 84 In some cases, the vessel may be operated with one fin locked and one fin operating normally. All normal operating procedures will apply to the “Enabled” fin. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Digital Stabilizers...

  • Page 85: Digital Stabilizer System Basic Maintenance

    250 hours (same schedule as propulsion engines). Remove the zincs and tap with a hammer. If the zinc flakes apart, install a new 3/8” NPT zinc, available at most marine supply stores. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 86: Electrical Systems

    GFIs provide NO PROTECTION against touching “hot” and neutral wires at the same time. WHEN USING ELECTRIC HAND TOOLS ABOARD, USE ONLY ONE OF THE GFI PROTECTED RECEPTACLES. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System...

  • Page 87: Ac Electrical Source

    Allow for tidal rise and fall, making sure the power cords are never in the water. 9. Turn ON, one at a time, the circuit breakers at the Shore Power connections on the dock. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 88 It will also boost 240V AC to approximately 270V AC, which could cause circuit breakers to close. This is why it is important to check the input voltages as described above. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 89: Disconnecting From Shore Power

    4. If a circuit breaker IS tripped, power off ALL 120/240V AC equipment and then reset the circuit breaker. 5. If the circuit breaker trips again, call the Dockmaster for assistance. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 90: Switching From Shore Power To Generator

    Operation. If the Forward Shore Power connections were used, disconnect the Shore Power cords on the vessel and store the power cords in a secure, dry indoor location. 9. Close inlet covers tightly. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System...

  • Page 91: Ac Electrical Distribution

    18. For each Generator, move the Engine Control switch on the Generator panel to the STOP position momentarily, until the engine stops. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 92: Inverter

    At the top right of the Panel are four digital displays which provide you with volt, hertz and ampere readings of the Shore Power or Generator power source being used. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 93 Starboard Guest Stateroom. • AIR CONDITION PORT GUEST S.R. – provides power to the 16,000 BTU air conditioning system for the Port Guest Stateroom. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System...
  • Page 94 • ESI FUEL POLISHING SYSTEM – provides power to the ESI Fuel Polishing System. A panel illumination light, with adjustable neck, is located at the lower part of the panel. A switch is located at the base of the light. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System...
  • Page 95 • Washer/Dryer • Water Heater The Inverter/Charger accepts 240V AC and distributes 120V AC. No electrical equipment on the 120V AC Inverter Bypass Panel operates off of 240V AC. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System...

  • Page 96: Figure 4 - 120/240V Ac Distribution Panel - Top

    120/240V AC DISTRIBUTION PANEL NO. 2 SHORE SHORE GEN. #1 GEN. #1 SHORE SHORE GEN. #2 GEN. #2 Figure 4 – 120/240V AC Distribution Panel – Top ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System Krogen 58’ Manual, Hull 58014...

  • Page 97: Figure 5 – 120/240V Ac Distribution Panels No. 1 & No. 2

    ENGINE ROOM EXHAUST FAN 12V BATT. CHARGER BOAT DAVIT FRESH WATER PUMP Figure 5 – 120/240V AC Distribution Panels No. 1 & No. 2 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System Krogen 58’ Manual, Hull 58014...
  • Page 98 • MACHINERY RECEPTACLES – provides power to the 120V AC receptacles in the Engine Room. • PROPANE STOVE – provides power to the electrical starter elements for the Galley range and oven. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System...

  • Page 99: Dc Electrical Source

    PORT GUEST S.R. RECEPTACLES GALLEY RECEPTACLES SALOON RECEPTACLES PILOT HOUSE RECEPTACLES MACHINERY RECEPTACLES PROPANE STOVE Figure 6 – 120V AC Inverter Bypass Panel ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System Krogen 58’ Manual, Hull 58014...

  • Page 100: 12V Dc Electrical Source

    ON, all equipment and accessories on the panel can be made operational and the displays will indicate the amps being consumed and the voltage condition of the 12V DC side of the NAV./COM. Battery bank. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 101 • DC 12V RECEPTACLES – provides power to the 12V DC receptacles in the vessel. • SPARE • SPARE • SPARE • SPARE • SPARE • SPARE • SPARE ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System Krogen 58’ Manual, Hull 58014...

  • Page 102: Dc Main Panel Disconnect

    12V DC NAV./COM. ELECTRONICS PANEL 12V DC PANEL DISCONNECT COMPASS PROPANE SOLENOID DC 12V RECEPTACLES Figure 7 – 12V DC NAV./COM. Electronics Panel ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System Krogen 58’ Manual, Hull 58014...

  • Page 103: 24V Dc Electrical Distribution

    • OIL CHANGE PUMP – provides power to the Oil Change pump located in the Engine room. • SPARE • SPARE • SPARE • SPARE • SPARE • SPARE ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System Krogen 58’ Manual, Hull 58014...
  • Page 104 Machinery Space, Forward Machinery Space, and Bow Thruster Machinery Space. • PILOT HOUSE LIGHTING – provides power to the Pilothouse lighting. • SPREADER LIGHTING – controls power to the spreader lights. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System...

  • Page 105: Figure 8 - 24V Dc Main Disconnect Panel

    S.R. LIGHTING SALON/DECK LIGHTING GALLEY LIGHTING ENG/LAZARETTE LIGHTING UNDER SOLE LIGHTING PILOTHOUSE LIGHTING SPREADER LIGHTING Figure 8 – 24V DC Main Disconnect Panel ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System Krogen 58’ Manual, Hull 58014...

  • Page 106: Navigation Lights

    HOUSE batteries by selecting ‘2’ on the 24 Volt Meter Source Selector switch while the 24V DC Panel Source Selector switch is still set to ‘NAV/COM BAT’. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 107 • HOLDING TANK MONITOR – controls power to the SeaLand TANKWATCH™ Status Panel located in the Pilothouse. • SPARE • SPARE • SPARE • SPARE • SPARE • SPARE ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System Krogen 58’ Manual, Hull 58014...

  • Page 108: Figure 9 - 24V Dc Nav./Com. Electronics Panel

    PARALLEL ENGINE SOLENOID CONTROLS (R) ENGINE CONTROLS (L) HOLDING TANK MONITOR STABILIZERS BOW THRUSTER WINDLASS Figure 9 – 24V DC NAV./COM. Electronics Panel ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Electrical System Krogen 58’ Manual, Hull 58014...

  • Page 117: Exhaust System

    The Gen-Sep™ will eliminate virtually all discharge noises normally found in systems that discharge water and exhaust together. It is normal for a small amount of water to still be discharged out the transom. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 118: Exhaust System Basic Service And Maintenance

    Once a year, usually at annual haul-out, have a qualified marine technician check the exhaust risers for internal corrosion. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Exhaust System...

  • Page 119: Fire Suppression System

    7. DO NOT OPEN THE ENGINE ROOM DOOR OR HATCH FOR AT LEAST 15 MINUTES to allow agent to ‘soak’ all areas of the Engine Room and for metals and fuels to cool. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 120: Manual Activation

    The system alarm should be tested daily by pressing the ‘TEST’ button at either station. This will indicate that the alarm is electrically connected to the pressure switch and also that the system has not been discharged. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 121: Fire Suppression System Basic Service And Maintenance

    1. Visual inspection of the gauge (should always be in the ‘green’) and the actuator to determine if the unit has discharged. 2. Weighing; this is the surest method of determining the contents of the agent in the cylinder. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 123: Fresh Water System

    Mach5 would be selected when 120V AC is available (Generators running or connected to shore power). The XR-124 fresh water pump is made operational by turning ON the circuit breaker labeled ‘FRESH WATER PUMP’ located on the 24V DC Main Panel ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 124: Dockside Water Pressure Regulators

    Even with the Water Pressure Regulator DO NOT OPEN DOCKSIDE WATER SPIGOT MORE THAN TWO TURNS. High pressure from the dockside water, exceeding 100 psi, could damage the fresh water system. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 125: Deck Washdown

    3. Turn OFF the supply shut-off valve at the bottom of the fresh water tank. 4. Disconnect from dockside water, if connected. 5. Turn OFF the spigot at the dockside water source. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 126: Fresh Water System Basic Service And Maintenance

    1. Turn OFF the circuit breaker labeled ‘FRESH WATER PUMP’ on the 24V DC Main Panel Disconnect and the circuit breaker labeled ‘FRESH WATER PUMP’ on the 120/240V AC Distribution Panel No.1. There should be no ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 127 Tools and Equipment Required: • Air gauge • Automotive type air pump ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 133: Fuel System

    Forward Starboard fuel tank. The fuel supply for the Port engine and 20Kw Generator is always from the Forward Port fuel tank. The Aft Starboard and Aft Port tanks are for ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 134: Fuel Return System

    Over time, the temperature of the fuel in the tank and air space in the tank above the fuel level will both ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 135: Fueling Procedure

    9. Fill the Port tanks first (Tanks 1 and 2). This is because the weight of the fuel in the full Starboard tanks, if the Port tanks are empty, will cause the vessel to list to Starboard and cause subsequent difficulty in fueling the Port tanks. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 136 This gel and the zinc flakes will quickly plug fuel filters, damage injection nozzles and injection pumps. DO NOT use brass-coated containers for Diesel fuel storage. BRASS is an alloy of copper and zinc. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Fuel System...

  • Page 137: Fuel System Basic Service And Maintenance

    8. Replace the lid and snugly tighten the T-handle by hand. HAND TIGHTEN ONLY. 9. Turn the filter selection handle to bring the filter just serviced on line. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Fuel System...
  • Page 138 2. Select the filter to stay on-line by positioning the handle to point to the ON-LINE filter, thereby selecting the off-line filter for service. 3. Place a suitable collection container under the filter to be serviced. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 139 3. Place a suitable collection container under the fuel filter. 4. Examine the collection bowl for water and contaminants and drain as necessary into the collection container. 5. Remove the lid and T-handle by hand. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Fuel System...
  • Page 140 1 Racor Model 2010 TMOR fuel filter element • A quart container of Diesel fuel • Absorbent disposable towels or clean rag • Collection container ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Fuel System Krogen 58’ Manual, Hull 58014...

  • Page 143: Fuel Polishing System

    11. Close the valve manifold supply and return valves. 12. Close both sight gauge valves on the supply and return tanks. 13. Close the supply and return tank shut off valves. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 144 14. Make sure the supply shut off valve at the bottom of the tank that will be in use is OPEN. 15. Turn OFF the circuit breaker labeled ‘FUEL POLISHING’ on the 120/240V AC Distribution Panel. No. 2. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Fuel Polishing System...

  • Page 145: Fuel Polishing Basic Service And Maintenance

    1 Racor Model 2020 SMOR 2 micron fuel filter element (brown in color) • Absorbent disposable towels or clean rag • Collection container ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Fuel Polishing System...

  • Page 147: Generators

    30W, such as Chevron Delo®. Use the proper oil viscosity based on the expected air temperature range during the period between oil changes. Refer to the “Northern Lights Operator’s Manual”, page 12. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 148: Voltage

    ASTM D3306 or ASTM D4656). These coolants do not contain the correct additives to protect heavy-duty diesel engines. They often contain a high concentration of silicates and may damage engine or cooling system. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 149: Supplemental Coolant Additives

    The battery switch must always be kept ON while the Generator is running. If the switch is turned OFF while the Generator is running, the battery charger regulator could be ruined. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 150: Starting

    1. Check that the Selector Switch on 120/240V AC Distribution Panel No. 1 or Panel No. 2 is selected to the correct setting for each Generator. The 20Kw Generator is ‘GEN 1’ and the 12Kw Generator is ‘GEN 2’ on both Panels. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 151: Stopping

    Operation. If the Forward Shore Power connections were used, disconnect the Shore Power cords on the vessel and store the power cords in a secure, dry, indoor location. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 152: Switching From Generator To Shore Power

    16. Turn back ON the 120/240V AC equipment and appliances you need. 17. Allow the Generators to run 3-5 minutes with NO LOAD before shutting down to allow coolant and fuel to carry away heat from engines. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 153: Shutdowns And Alarms

    OFF fuel supply and position Generator battery selector switches to OFF. Shutdowns and Alarms Refer to “Northern Lights Operator’s Manual”, page 9 for detailed information on Shutdowns and Alarms. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 154: Generator Basic Service And Maintenance

    • V-Belts • Winterizing/Out-of-Service Troubleshooting The Troubleshooting section starting on page 20 of your “Northern Lights Operator’s Manual” contains a detailed guide on trouble shooting. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Generators Krogen 58’ Manual, Hull 58014...

  • Page 155: Lpg System

    LPG service center to adjust the regulator pressure setting. To operate your Range, see “Range” in the Appliances section in this manual. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 156: Changing Lpg Tanks

    Never attempt to locate leaks by using an open flame. Repair and re-test the system before putting the system into operation. If leaks persist, consult a qualified LPG Service Center. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 159: Oil Change System

    To drain the oil, you should do the following: 1. Turn ON the circuit breaker labeled ‘OIL CHANGE PUMP’ on the 24V DC Main Panel Disconnect. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 160: Filling With Oil

    Oil Change System Basic Service and Maintenance There is essentially no service or maintenance needed on either the pump or manifold. The pump is gear driven and has no impellers to change. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 161: Propeller Shaft Assembly System

    Reverse and the Starboard Clutch Sender is in Neutral, the Stern will have a tendency to move to Starboard. When the Starboard Clutch Sender is in Reverse and the Port Clutch Sender is in Neutral, the Stern will have a tendency to move to Port. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 162: Propeller Shaft Assembly Basic Service And Maintenance

    FORWARD. When installing the propeller, always make sure the safety tab ends are bent Forward to secure the large nut from being able to spin off. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Propeller Shaft Assembly System...

  • Page 165: Propulsion System - Engines And Transmissions

    1. In the Twin Disc “Marine Transmission Operator’s Manual”, page iii. 2. In this Owner’s Manual, Appendix G – Equipment Serial Numbers. 3. Somewhere safely off the boat. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 166: Engine Break-In

    The reaction of the zinc, when exposed to the salt water, causes the plugs to deteriorate instead of critical engine components. After ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 167: Transmission Break-In

    Refer to the John Deere “Operations and Service Manual”, page 10-6. The oil capacity for the 6068TFM75 is 20.8 quarts (19.6 L). Multi-viscosity Diesel engine oils are preferred. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 168: Synthetic Lubricants

    Coolant to provide year-round protection against corrosion and cylinder liner pitting, and winter freeze protection to -34º (-37ºC) and has a service life of five years/5,000 hours provided the coolant is tested annually and additives are added as needed. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 169: Water Quality

    John Deere LIQUID COOLANT CONDITIONER is recommended as a supplemental coolant additive. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 170: Disposing Of Coolant

    Operate the engines under a lighter load and at slower than normal speed for the first 15 minutes after start-up. DO NOT run the engine at slow idle. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 171: Starting The Engines

    11. Make a thorough inspection of the engine compartment. Look for oil or coolant leaks, worn drive belts, loose connections, and trash. Remove trash and make repairs as needed. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 172 15. Observe engine coolant temperature gauge. Normal engine coolant operating temperature range is 176ºF – 202ºF (80ºC – 94ºC). DO NOT place engine under full load until engine is operating within that range. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 173 5. The TCS must be turned ON to operate the Windlass. 6. Enable both Stabilizers on the Touchscreen Panel in the Pilothouse and Center the Stabilizer fins. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 174: Emergency Engine Start Up

    4. Turn ‘OFF’ the circuit breakers labeled ‘ENGINE CONTROL (L)’ and ‘ENGINE CONTROL (R)’, on the 24V DC NAV./COM. Electronics Panel in the Pilothouse. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Propulsion System – Engines and Transmission...

  • Page 175: Emergency Shut Off

    2. Stop the fuel flow by pushing this lever to Starboard (rotate down) until the engine shuts down. 3. If you cannot reach the fuel injection pump, turn off the fuel supply at the Racor fuel filter. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 176: Engine And Transmission Basic Service And Maintenance

    Should you live or cruise in a moist and cold climate, it is recommended the transmission oil be changed every 500 hours or annually. Remember that most oil additive packages will ‘fade’ after six months or so. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 177: Propulsion Engine Controls

    Accept command at any station by positioning the Command Head levers into the Neutral position and depressing the station transfer button at the base of the Control ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 178: Operation

    • Repetitive Signal – One Long, One Short Tone signals a Shift position feedback error. Refer to Appendix B in the “ZF Marine Operation & Installation Manual”. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Propulsion Engine Controls...
  • Page 179 • Repetitive Signal – One Long, Three Short Tones signals a Control Head failure of the remote station that was in command at the time the tone started. Refer to Appendix B in the “ZF Marine Operation & Installation Manual”. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 180: Engine Control System Basic Service And Maintenance

    To clean, use warm water and mild soap. Do not attempt to use an abrasive compound. Tools and Equipment Needed: • Clean rag • Liquid soap • Warm water ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Propulsion Engine Controls Krogen 58’ Manual, Hull 58014...

  • Page 181: Propulsion Engine Raw Water Cooling System

    Tides Marine STRONG® Shaft Seal. Refer to Figure 19 for detailed diagram of Engine Raw Water Cooling System. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 182: Propulsion Engine Raw Water Cooling System Basic Service And Maintenance

    • Spanner wrench At least annually, remove and inspect the impeller in the raw water pump on each engine and replace if needed. Refer to John Deere Owner’s Manual for details. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 185: Raw Water Washdown

    Engine vibration and boat movement may cause the pump to loose prime and cause the pump to “cycle”. This is normal if the circuit breaker switch is left ON. Always turn the circuit breaker switch OFF when the pump is not is use. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 186: Raw Water Washdown Basic Service And Maintenance

    Forward Machinery Space. DO NOT lubricate any internal part of the pump. Should the belt or impeller need to be replaced, refer to Spare Parts in this manual. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 187: Sanitary System

    Each flush consumes 1.5 pints (.7 L) of fresh water. To add water to the bowl, press the ADD WATER switch until the desired water level is ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 188: System Start Up

    HEAD VACUUM PUMP’ and ‘GUEST HEAD VACUUM PUMP’ 4. Turn ON the switch on the VacuFlush® Status Panel located on the front panel of the sink in each Head. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Sanitary System...

  • Page 189: Water Refill Level

    Manual Override In the event of a power failure, the toilet can be flushed manually by a switch under the access cover. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Sanitary System Krogen 58’ Manual, Hull 58014...

  • Page 190: Holding Tank And Level Monitor

    Continue flushing until the discharge from the holding tank, as seen through the ’sight view’ glass on the dockside suction pump discharge hose, is clear. 10. Have assistant or Dockmaster stop the dockside discharge pump. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 191 Discharge Zone. This is a Coast Guard requirement. Do Not turn the Discharge Pump ON without first opening the waste discharge thru-hull seacock. Remember to close the thru-hull seacock when discharge has completed. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Sanitary System...

  • Page 192: Sanitary System Basic Service And Maintenance

    SeaLand® cleaner will help restore the shine. If this cleaner is not available (try your nearest SeaLand® dealer), you ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 193 “duck bill” valve is not sealing (needs replacement) or the outlet side of the vacuum tank is clogged CAUTION Always wear protective gloves when working on or around the sanitary system. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Sanitary System...

  • Page 197: Shower/Sink Drain System

    Sink Drains The sinks in the Galley, Master Head, and Guest Head drain by gravity directly overboard. Refer to Figure 21 – Clear Water Waste Schematic for details. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Shower/Sink Drain System...

  • Page 198: Shower Drain/Sump System Basic Service And Maintenance

    10. Leave the rocker switches in the OFF position. Tools and Equipment Needed: • Clean rag • Liquid dishwashing soap • Phillips screw driver • Small bucket • Warm water ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Shower/Sink Drain System Krogen 58’ Manual, Hull 58014...

  • Page 201: Steering System

    Inside the hull, the stock is enclosed in a fiberglass tube finished flush with the outside of the hull ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 202: Flanged Roller Bearing

    (parallel to the hydraulic line). CAUTION DO NOT stow articles or equipment around the rudder assembly that could jam the hydraulic cylinder and prevent it from moving. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Steering System...

  • Page 203: Steering System Basic Service And Maintenance

    3. Replace and tighten the filler plug. 4. Pressurize the system with a tire pump or using the hand plunger at the top of the reservoir to 25-30 psi (172 Mpa – 207 Mpa). ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 204: Rudder Bearing Linkage

    Once a year, lubricate the rudder bearing with water proof grease. Tools and Equipment Needed: • Clean rag • Waterproof grease and grease gun ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Steering System Krogen 58’ Manual, Hull 58014...

  • Page 207: Ventilation System

    Engine Room is occupied. The exhaust fan is operated by turning ON the circuit breaker on the 120/240V AC Distribution Panel No. 1 in the Pilothouse labeled ‘ENGINE ROOM EXHAUST FAN’. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 209: Windlass System

    Starboard of the steering station in the Pilothouse labeled ‘BOW THRUSTER WINDLASS’. 3. An indicator light will be illuminated on both the remote control stations, indicating the system is ready for operation. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.. Windlass System...

  • Page 210: Lowering The Anchor

    CAUTION DO NOT ALLOW the chainwheel to free wheel as this will allow dangerously high chain speeds to build up. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Windlass System Krogen 58’ Manual, Hull 58014...

  • Page 211: Raising The Anchor

    Refer to page 42 in the Maxwell “Owners Manual”. 4. Take off the weight by pulling the crank lever in a clockwise direction as far as possible at the same time bringing in the chain. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.. Windlass System...

  • Page 212: Capstan (Warping Drum) Operations

    DO NOT put so many turns on the drum that easing the load on the tail will not allow the line to slip on the drum. THREE turns is usually maximum. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 213: Windlass Basic Service And Maintenance

    • Marine grease, Lithium based or Lithium complex based (Duckhams ‘Keenol’ or Castrol LMX) • SAE 90 Oil (Shell Omala 320, Castrol Alpha SP320 or equivalent • Soft cloth ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.. Windlass System Krogen 58’ Manual, Hull 58014...

  • Page 215: Windshield Wiper/Washer System

    Press to Press to DECREASE INCREASE Wiper Wiper Frequency Frequency ON/OFF Push to All Wipers WASH Figure 23 – Exalto Wiper Control Panel ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Windshield Wiper/Washer System...

  • Page 216: On/Off Switching

    Refer to Figure 14 – Fresh Water Piping Schematic for details. The circuit breaker labeled ‘FRESH WATER PUMP’ on the 24V DC Main Panel or the 120/240V AC Distribution Panel No. 1 must be ON for the Wash function to operate. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 217: Windshield Wiper/Washer System Basic Service And Maintenance

    To preserve the life of the wiper blades, rinse the windshields with fresh water after each exposure to salt spray. Replacement parts are available from Imtra. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 219: Appliances

    Range …………………………………………………………………………………. 211 Refrigerator……………………………………………………………………………. 215 Trash Compactor ……………………………………………………………………… 217 Washer ………………………………………………………………………………… 219 WARNING Use common sense and caution when operating and maintaining any appliance. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. APPLIANCES Krogen 58’ Manual, Hull 58014...

  • Page 221: Dishwasher

    The circuit breaker labeled ‘FRESH WATER PUMP’ on the 24V DC Main Panel Disconnect or the 120/240V AC Distribution Panel No. 1 must also be ON or the vessel must be connected to dockside water supply to operate the Dishwasher. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 222: Dishwasher Basic Service And Maintenance

    When contacting the Miele Technical Service Department, quote the model and serial number of your appliance. These can be found on the data plate on the upper inside edge of the Dishwasher door. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 223: Dryer

    Use the serial number and model number when ordering parts and in correspondence. Operation In order to be able to use the Dryer, turn ON the circuit breaker labeled ‘WASHER DRYER’ located on the 120/240V AC Distribution Panel No. 1. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Dryer...

  • Page 224: Dryer Basic Service And Maintenance

    Your Dryer is Model T761. The type plate with the type name and serial numbers is located behind the door in the upper left corner. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 225: Icemaker

    WATER PUMP’ on the 24V DC Main Panel Disconnect or the 120/240V AC Distribution Panel No. 1 must be ON or the vessel must be connected to dockside water supply. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 226: Icemaker Basic Service And Maintenance

    Icer-Ette™. Because of high voltage, high pressure refrigeration, and presence of water in the unit, a person who is not technically qualified may be subject to electric shock hazard. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 227: Microwave/Convection Oven

    The Microwave/Convection Oven can only operate on 120V AC. To operate the Microwave/Convection Oven, the circuit breaker labeled ‘MICROWAVE’ on the 120V AC Inverter Bypass Panel must be ON. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Microwave...

  • Page 228: Microwave/Convection Oven Basic Service And Maintenance

    JVM1190SY) CAUTION Turn off the circuit breaker labeled ‘MICROWAVE’ on the 120V AC Inverter Bypass Panel before cleaning any part of this oven. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Microwave Krogen 58’ Manual, Hull 58014...

  • Page 229: Range

    If you smell such an odor, check for leaks and repair IMMEDIATELY. CAUTION It is a good idea to store fire extinguisher near the Galley. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 230: Changing Lpg Tanks

    If leaks persist, consult a qualified LPG Service Center. CAUTION Keep combustible materials away from burners when in use. CAUTION Vessel motion may cause hot liquids to spill. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Range Krogen 58’ Manual, Hull 58014...

  • Page 231: Operation

    When using a large pot on either back burner, DO NOT position the burner on High as the flame may extend from under the pot and scorch the Safety Panel. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 232: Range Basic Service And Maintenance

    The surface burners can still be used, but will need to be lit with a match or lighter. Do Not attempt to operate the oven. Make sure the oven control is in the OFF position. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 233: Refrigerator

    Keep the Refrigerator full to near capacity so less cold air will escape when the freezer door is opened. When the freezer is less than two-thirds full, place milk cartons half full of water in the freezer. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 234: Refrigerator Basic Service And Maintenance

    Consult the “Jenn-Air Refrigerator Guide” for information on the operation and service of your Refrigerator. CAUTION To avoid electrical shock which can cause severe personal injury or death, disconnect power to the Refrigerator before cleaning. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Refrigerator Krogen 58’ Manual, Hull 58014...

  • Page 235: Trash Compactor

    You must use the specially designed heavy-duty trash bags included with your compactor. Replacement bags can be obtained by calling 800-626-2000, or by ordering from the GE website www.geappliances.com. The part number for replacement bags is WC60X5015. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Trash Compactor...

  • Page 236: Trash Compactor Basic Service And Maintenance

    ‘TRASH COMPACTOR’ located on the 120/240V AC Distribution Panel No. 2. CAUTION Glass fragments may be lying in the bottom of the cabinet. USE EXTREME CAUTION AND WEAR GLOVES. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Trash Compactor...

  • Page 237: Washer

    ‘FRESH WATER’ on the 24V DC Main Panel Disconnect or the 120/240V AC Distribution Panel No. 1 must be ON, or the vessel must be connected to dockside water supply. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 238: Washer Basic Service And Maintenance

    Your Washer is Model W6761. The type plate with the type name and serial number is located above the glass door. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 239: Housekeeping

    HOUSEKEEPING Convenience Features ………………………………………………………………… 223 Care and Cleaning ……………………………………………………………………. 225 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 HOUSEKEEPING...

  • Page 241: Convenience Features

    Pilothouse Starboard side on the side of the electronics console, in the Guest Stateroom, in the Stateroom/Den, and in the Master Stateroom. The Splitter for the cable is in the cabinet just Aft of the Main Electrical Panel, Starboard side in the Pilothouse. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 242: Phone Outlets

    Pilothouse Starboard side on the side of the electronics console, in the Guest Stateroom, in the Stateroom/Den, and in the Master Stateroom Starboard side by the Island Queen berth. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Convenience Features...

  • Page 243: Care And Cleaning

    Appliances Refer to the service manuals provided by the manufacturers of the various appliances for detailed information on the care and cleaning of each appliance. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Care and Cleaning...

  • Page 244: Yacht Exterior

    CAUTION Stainless steel IS NOT rust proof. It will discolor, rust and even corrode when in contact with salt water, sulfides, or rusting metals. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Care and Cleaning...

  • Page 245: Teak Decks

    WARNING Be certain NOT TO USE a wax containing abrasives such as Collinite #850 metal wax. Obvious abrasive scratches on chrome finish will void all warranty claims. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Care and Cleaning...

  • Page 246: Below The Waterline

    A qualified diver should inspect and clean the bottom of your vessel between haul-outs and inspect and replace the zinc anodes as necessary (See the “Bonding System” section of this manual). ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 247: Lay-Up And Haul-Out

    LAY-UP AND HAUL-OUT Haul-Out ………………………………………………………………………………. 231 De-Commissioning ……………………………………………………………………. 235 Re-Commissioning ……………………………………………………………………. 243 Winterizing ……………………………………………………………………………. 247 De-Winterizing …………………………………………………………………………255 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. LAY-UP AND HAUL-OUT Krogen 58’ Manual, Hull 58014...

  • Page 249: Haul-Out

    • Inspect the Bow Thruster – clean and repair as necessary • Inspect the Stabilizer – clean and repair as necessary • Rudder assemblies • Zinc anodes on the hull, propeller shafts, stabilizer fins, and rudders ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Haul-Out...

  • Page 253: De-Commissioning

    9. Loosen the screws on the raw water intake pumps and allow water to drain into the bilge. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 254: Battery System

    1. Turn OFF the circuit breaker labeled ‘STABILIZERS’ on the 24V DC NAV./COM. Electronics Panel. Engine Controls The ZF Mathers Micro Commander Engine Controls require no de-commissioning. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. De-Commissioning Krogen 58’ Manual, Hull 58014...

  • Page 255: Fresh Water System

    7. Turn OFF the power. 8. Prop OPEN the door at least two inches to allow the inside to defrost. 9. After the unit has defrosted, wipe it dry. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. De-Commissioning...
  • Page 256 4. Shut off water supply to the toilet by turning OFF the circuit breakers on the 24V DC Main Panel Disconnect and the 120/240V AC Distribution Panel No .1 labeled ‘FRESH WATER PUMP’. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 257: Fuel System

    Also, when the propulsion engine is de-commissioned, some anti-freeze/distilled coolant mix will stay in the seal and tubing. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 258: Propulsion Engines And Transmissions

    1. Turn OFF the circuit breaker label ‘SALT WATER PUMP’ on the 24V DC Main Panel Disconnect. 2. Close the raw water intake seacock for the raw water washdown pump. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 259: Refrigerator

    The windlass needs no special de-commissioning procedure. Make sure the circuit breaker labeled ‘BOW THRUSTER WINDLASS’ on the 24V DC NAV./COM. Electronics Panel is kept in the OFF position until re-commissioning. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 261: Re-Commissioning

    1. Close all faucets (Galley, Master Head sink and shower, Guest Head sink and shower, Engine Room, Aft cockpit shower, and all three fresh water washdowns). 2. Tighten the inlet and outlet connections on the fresh water pump. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Re-Commissioning...

  • Page 262: Generators

    3. Reconnect the hose connecting the sea strainer to the raw water pump. 4. Install new impeller (if old one removed during de-commissioning). 5. Tighten the screws on the raw water intake pump. 6. Replace fuel filter element. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Re-Commissioning...

  • Page 263: Propulsion Engines

    Inverter Bypass Panel. 3. Slide the freezer control to midpoint. 4. Slide the refrigerator control to midpoint. 5. Let the refrigerator run at least 8-12 hours before adding food. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Re-Commissioning...
  • Page 264 6. Allow 24 hours for temperatures in refrigerator and freezer compartments to stabilize before resetting. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Re-Commissioning Krogen 58’ Manual, Hull 58014...

  • Page 265: Winterizing

    9. Disconnect the hoses connecting each air conditioning unit and the sea strainer at the sea strainer and drain the all water from both units into the bilge. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Winterizing...

  • Page 266: Battery System

    Digital Stabilizer will also be winterized. The following winterizing procedure should be followed: 1. Turn OFF the circuit breaker labeled ‘STABILIZERS’ on the 24V DC NAV./COM. Electronics Panel. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Winterizing...

  • Page 267: Engine Controls

    5. Turn the power to the unit ON and allow the unit to run for one hour. 6. Remove any ice cubes that may have been ejected during this period. 7. Turn OFF the power. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 268 5. Pour a quart (1 L) of nontoxic antifreeze (propylene glycol) (cheap Vodka works well here and doesn’t leave any nasty taste) into the hot water fitting of ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 269: Fuel System

    7. Disconnect the hose connecting the raw water pump to the sea trainer at the sea strainer and let the water drain into the bilge. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Winterizing...

  • Page 270: Lpg System

    9. Close globe valve to shaft seal. 10. Prepare a 5 gallon bucket of 50/50 mix of antifreeze and distilled water. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 271: Raw Water Washdown

    Inverter Bypass Panel. 4. Disconnect the refrigerator power cord from the electrical outlet. 5. Clean and dry the refrigerator and freezer thoroughly. 6. Leave the doors open to prevent odors. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Winterizing...

  • Page 272: Shower Drains

    The windlass needs no special winterizing procedure. Make sure the circuit breaker labeled ‘BOW THRUSTER WINDLASS’ on the 24V DC NAV./COM. Electronics Panel is kept in the OFF position until de-winterizing. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 273: De-Winterizing

    Engine Room, Aft cockpit shower, and all three fresh water washdowns). 2. Tighten the inlet and outlet connections on the fresh water pump. 3. Fill the fresh water tank. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. De-Winterizing...

  • Page 274: Generators

    4. Install new impeller (if old one removed during winterizing). 5. Tighten the screws on the raw water intake pump. 6. Replace fuel filter element. 7. Open the raw water intake seacock. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. De-Winterizing...

  • Page 275: Propulsion Engines

    4. Slide the refrigerator control to midpoint. 5. Let the refrigerator run at least 8-12 hours before adding food. 6. Allow 24 hours for temperatures in refrigerator and freezer compartments to stabilize before resetting. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. De-Winterizing...

  • Page 277: Spare Parts

    SPARE PARTS Spare Parts – Suggested List …………………………………………......261 Spare Parts – Inventory on Hand ……………………………………………………… 271 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 SPARE PARTS...

  • Page 279: Spare Parts - Suggested List

    Nautical Structures gpm ¹ Cable Kit, ¼” with hook ¹ N1AE0005 Nautical Structures Fittings, flow control ¹ N2BFT034 Nautical Structures ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Spare Parts – Suggested List...

  • Page 280: Electrical System

    See Note below Oil Filter Northern Lights Fuel Filter Northern Lights Air Filter ¹ Northern Lights Drive Belt Northern Lights ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Spare Parts – Suggested List Krogen 58’ Manual, Hull 58014...

  • Page 281: Generator 20Kw

    Gasket Northern Lights Raw Water Pump Northern Lights O-Ring Northern Lights Relay, SPDT 12V Northern Lights Gasket Set Northern Lights ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Spare Parts – Suggested List...

  • Page 282: Propulsion Engines

    Starter 24V DC John Deere Valve Cover Gasket John Deere Exhaust V Band Clamp John Deere Exhaust Manifold Gasket John Deere ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Spare Parts – Suggested List Krogen 58’ Manual, Hull 58014...

  • Page 283: Propulsion Engines Cooling System

    Manufacturer Return Filter Assembly ABT 29408 Twist On 15 psi Bypass Heat Exchanger Zincs 3/8” NPT Pencil type West Marine ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Spare Parts – Suggested List...

  • Page 284: Steering System

    Available At Refrigerator light bulb 60-watt appliance bulb Local hardware store Freezer light bulb 40-watt appliance bulb Local hardware store ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Spare Parts – Suggested List Krogen 58’ Manual, Hull 58014...

  • Page 285: Trash Compactor

    Trash Compactor Description Model/Part Number Manufacturer Replacement trash bags WC60X5015 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Spare Parts – Suggested List...

  • Page 286: Owner Installed Equipment

    Owner Installed Equipment Qty Description Model/Part Number Manufacturer ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Spare Parts – Suggested List Krogen 58’ Manual, Hull 58014...
  • Page 287 Qty Description Model/Part Number Manufacturer ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Spare Parts – Suggested List...

  • Page 289: Spare Parts - Inventory On Hand

    ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Spare Parts – Inventory on Hand...
  • Page 290 ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Spare Parts – Inventory on Hand...
  • Page 291 ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Spare Parts – Inventory on Hand...
  • Page 292 ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ____ ____________ ___________ _______________ ___/____/_____ ________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Spare Parts – Inventory on Hand...

  • Page 293: Equipment List

    Interior......................... 292 Machinery Space..................... 292 Saloon ........................293 Pilothouse........................ 293 Appliances....................... 294 Exterior ........................295 Flybridge ......................... 296 Owner Installed Equipment ..................297 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 EQUIPMENT LIST...

  • Page 295: Equipment List

    2 Years Engine Controls, “MicroCommander” with 9000 Series ZF Mathers 3 Years MC2000-2 Control Heads P/N 92100 Emergency tiller arm Kadey-Krogen Kadey-Krogen Warranty Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 296: Systems

    Horn Solenoid Valve 24V DC 0.05 amp V–69K Kahlenberg Bros. Manufacturer’s Warranty Horn Push Buttons M-125 Kahlenberg Bros. Manufacturer’s Warranty Whistle control 24V DC M-511A Kahlenberg Bros. Manufacturer’s Warranty Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 297: Antivibration System

    Manufacturer’s Warranty 12V-40A Master Switch 2102B Guest 1 year H/O Battery Select Switches 2300A Guest 1 year H/O On/Off Switches 2303A Guest 1 year Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 298: Bilge System

    Warranty #8 & #6 Tinned wire used Kadey-Krogen Warranty Galvanic Isolators 50A GI-50 Newmar 2 years Shaft Brush Anodes 2436 Guest 1 year Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 299: Bow Thruster System

    Power Inlets 125/250VAC BX 50 amps 6373EL-B Marinco 5 years Plugs 125/250V AC 50 amps 6365CRN Marinco 5 years Covers and Plugs 50 amps 7717N Marinco 5 years Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 300: Davit System

    HZ Meter 12/24V DC 2053-3761-07 Modutec Digital Manufacturer’s Warranty AC Volt Meter 120/240V AC 2053-3729-07 Modutec Digital Manufacturer’s Warranty 200A 50MV Shunts TM-200-50 Crompton Manufacturer’s Warranty Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.
  • Page 301 Storm Lights – in Companion ways CN70704 Cantalupi Manufacturer’s Warranty Diana 85 Lights 3” CN32101 Cantalupi Manufacturer’s Warranty Diana 105 4” Overhead Dome CN12301 Cantalupi Manufacturer’s Warranty Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 302: Exhaust System

    2” Gen-Sep Inlet/Outlets, White P.N. 1020200 Centek Industries Manufacturer’s Warranty 2” O.D. 90° Mitered elbows P.N. 1200200 Centek Industries Manufacturer’s Warranty Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 303: Fire Suppression System

    5 years Lavatory Faucets – Single Lever Mixer 4050-7050 FM Mattsson 5 years Marine Showers- Single Lever Mixer 5110-7050 FM Mattsson 5 years Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 304: Fuel System

    1027 Series King’s Point Manufacturer’s Warranty Monel Float and Screen Machinery Deck Plates Marked “DIESEL” for 2” hose 66412 Attwood Manufacturer’s Warranty Stainless-Polished Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 305: Fuel Polishing System

    Trident Marine 1 year Systems Gas Control Kit 1300-7716 Trident Marine 1 year Systems Solenoid Valve 24V DC 100 amp SW866 ASCO 1 year Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 306: Oil Change System

    ¾” Intake Water Strainers, bronze Kadey-Krogen Warranty Perko 1” Intake Water strainer, bronze Kadey-Krogen Warranty Perko 1 ½” Intake Water Strainers, bronze Kadey-Krogen Warranty Perko Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 307: Sanitary System

    Kadey-Krogen Warranty siphon-break “joker” valve) 1 ½” Integrated thru-hull valve with one 1 ½” P.N. 931266 Forespar Products Kadey-Krogen Warranty full threaded/mushroom head Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 308: Shower/Sink And Deck Drain System

    Cockpit Scupper Drains, Bronze Chrome Perko 5 years Plated for 1 ½” Thru-hull connectors, 1 ¼” Pipe size, cast H.F. Co. Ltd. Kadey-Krogen Warranty bronze Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 309: Windshield Wiper System

    Description Model No. Manufacturer Warranty Anchor Windlass double horizontal chain HWVC 3500 Maxwell 3 years wheel, vertical warping capstan, 3500 lb line pull Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 310: Interior

    Groco 1 year Sound Insulation with Aluminum Sheathing Quietech Perforated Soundown Corp. Kadey-Krogen Warranty Throughout Fresh Water Hose with spray nozzle Kadey-Krogen Warranty Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 311: Saloon

    Helm Chair – High Back “Luxury” Admiral 500-XH-PX2 STIDD Manufacturer’s Warranty with choice of Ultra Leather color, 24V DC Compass, 6” Model C651A Danforth/Rule Manufacturer’s Warranty Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 312: Appliances

    Washer 240V AC 15 amp W6461 Asko 3 years full, 4/5 years limited, lifetime tank Garbage Disposal GFC525F G.E. 1 year full warranty Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 313: Exterior

    20 ft 4” I.D. Duct hose, rated @300° F 450-400G Shields Marine Manufacturer’s Warranty 10 ft 5” I.D. Duct hose, rated @300° F 450-500G Shields Marine Manufacturer’s Warranty Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 314: Flybridge

    Manufacturer’s Warranty Flybridge Helm, DLX Sewn Seats with Arms P2000 Pompanette Manufacturer’s Warranty Pedestals T1230M Pompanette Manufacturer’s Warranty Adjustable Footrests Pompanette Manufacturer’s Warranty Krogen 58’ Manual, Hull 58014 ©2008 Kadey-Krogen Yachts, Inc. Equipment List www.kadeykrogen.com Subject to change without notice.

  • Page 315: Owner Installed Equipment

    Owner Installed Equipment Description Model No. Manufacturer Warranty ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Equipment List...
  • Page 316 Description Model No. Manufacturer Warranty ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Equipment List...

  • Page 317: Component Manufacturers List

    COMPONENT MANUFACTURERS LIST Component Manufacturers List - Sorted by Manufacturer......... 301 Component Manufacturers List - Sorted by Component..........317 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 COMPONENT MANUFACTURERS LIST...

  • Page 319: Component Manufacturers List - Sorted By Manufacturer

    Washer & Dryer AM Appliance Group P.O. Box 851805, Richardson, TX 75085-1805, USA PHONE ASKO Advisory Center 800-898-1879, 972-238-0798 www.askousa.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Manufacturer...
  • Page 320 Carling Technologies, Inc Circuit Breakers Worldwide Headquarters: 60 Johnson Ave, Plainville, CT 06062-1177, USA PHONE 860-793-9281, FAX 860-793-9231 www.carlingtech.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Manufacturer Krogen 58’ Manual, Hull 58014...
  • Page 321 Division Headquarters: 5639 W. Genesee St., Camillus, NY 13031, USA PHONE 800-365-1185 / 315-487-0800, FAX 315-487-4028 www.crucibleservice.com www.aquamet.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Manufacturer...
  • Page 322 Edson Steering Wheel Edson International: 146 Duchaine Boulevard, New Bedford, MA 02745-1292, USA PHONE 508-995-9711, FAX 508-995-5021 www.edsonmarine.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Manufacturer Krogen 58’ Manual, Hull 58014...
  • Page 323 Fuel Vent Drain Plug 22322 Gilberto Rancho Santa Margarita, CA 92688 PHONE 949-858.8820 or 800-266.8820, FAX 949-858.0505 www.forespar.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Manufacturer...
  • Page 324 Guest Marine Products Battery Switches Marinco 2655 Napa Valley Corporate Drive, Napa, CA 94558-6261, USA PHONE 707-226-9600, FAX 707-226-9670 www.marinco.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Manufacturer Krogen 58’ Manual, Hull 58014...
  • Page 325 Deck Washdown Quick Connect 1485 Dale Way, P.O. Box 2158, Costa Mesa, CA 92628-2158, USA PHONE 714-545-8251, FAX 714-957-0609 www.jabsco.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Manufacturer...
  • Page 326 LHA Products/Donaldson Company Inc. Stabilizer Reservoir Filter P.O. Box 1299 Minneapolis, MN 55440-1299 PHONE 952 887-3131 www.donaldson.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Manufacturer Krogen 58’ Manual, Hull 58014...
  • Page 327 Nautical Structures Davit System 10351 72 Street North, Largo, FL 34647, USA PHONE 888-541-6664, 727-541-6664, FAX 727-541-6353 www.nautical-structures.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Manufacturer...
  • Page 328 Reya 144 Avenue de la Roubine-BP126, 06156 Cannes-la-Bocca, France PHONE 33 493 904 700, FAX 33 493 904 710 www.reya.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Manufacturer Krogen 58’ Manual, Hull 58014...
  • Page 329 A division of MetalCraft, Inc 9331-A Philadelphia Road, Baltimore, MD 21237, USA PHONE 800-445-7680, 410-667-5500, FAX 410-667-5503 www.sea-fire.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Manufacturer...
  • Page 330 Teleflex Hydraulic Division 3831 No. 6 Road Richmond, BC Canada V6V 1P6 PHONE 604 270-6899, FAX 604 270-7172 www.teleflexcanada.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Manufacturer Krogen 58’ Manual, Hull 58014...
  • Page 331 Marine Transmission and Reduction Gear Corporate Office: 1328 Racine Street, Racine, WI 53403, USA PHONE 262-638-4000, FAX 262-638-4482 Marketing, 262-638-4480 General. www.twindisc.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Manufacturer...
  • Page 332 PHONE (310) 516-9812, FAX (310) 516-9824 www.windline.com Worthington Industries LPG Cylinders 200 Old Wilson Bridge Rd. Columbus, OH 43085 PHONE 614 438-3210 www.worthingtonindustries.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Manufacturer Krogen 58’ Manual, Hull 58014...
  • Page 333 ZF Mathers, LLC Engine Controls 1415 Pacific Drive, Burlington WA 98233-3103, USA PHONE 800-546-5455, 360-757-6265, FAX 360-757-2500 www.zf-marine.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Manufacturer...

  • Page 335: Component Manufacturers List - Sorted By Component

    Canada Metal (Pacific) Ltd. Anodes: 634 Derwent Way, Delta British Columbia, Canada V3M 5P8 PHONE 604 525-0471, FAX 604 540-3650 www.canmet.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Component...
  • Page 336 PHONE 856-825-4900, FAX: 856-825-4409 Southern Office: 3101 SW Second Ave., Ft. Lauderdale, FL 33315, USA PHONE 954-525-0378, FAX 954-764-4370 www.raritaneng.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Component Krogen 58’ Manual, Hull 58014...
  • Page 337 Guest Marine Products Battery Switches: Marinco 2655 Napa Valley Corporate Drive, Napa, CA 94558-6261, USA PHONE 707-226-9600, FAX 707-226-9670 www.marinco.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Component...
  • Page 338 Morse Industrial Products Division Cables: 730 Great Southwest Parkway, P. O. Box 43509, Atlanta, GA 30336, USA www.teleflexmorse.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Component Krogen 58’ Manual, Hull 58014...
  • Page 339 1419 Illinois Ave., Sheboygan, WI 53082, USA PHONE 920-457-4891 www.thomaspumps.com Corian Countertops: PHONE 800-426-7426 Check website for local dealer www.corian.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Component...
  • Page 340 Freeman Marine Equipment, Inc Doors: 28336 Hunter Creek Road, Gold Beach, OR 97444, USA PHONE 541-247-7078, FAX 541-247-2114 www.freemanmarine.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Component Krogen 58’ Manual, Hull 58014...
  • Page 341 A Division of Tyco Electronics UK Ltd. Freebournes Road, Witham, Essex CM8 3AH, UK PHONE 44-1376-509-509, FAX 44-1376-509-511 www.crompton-instruments.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Component...
  • Page 342 A division of MetalCraft, Inc 9331-A Philadelphia Road, Baltimore, MD 21237, USA PHONE 800-445-7680, 410-667-5500, FAX 410-667-5503 www.sea-fire.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Component Krogen 58’ Manual, Hull 58014...
  • Page 343 Fresh Water Pump Strainer: Groco 7240 Standard Drive, Hanover, MD 21076, USA PHONE 410-712-4242, FAX 410-712-0160 www.groco.net ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Component...
  • Page 344 CCP – Cook Composites and Polymers Gel coat: PO Box 419389, Kansas City, MO 64141-6389 PHONE 816-391-6088 – Customer Service 800-821-3590 www.ccponline.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Component Krogen 58’ Manual, Hull 58014...
  • Page 345 PHONE 954-525-6367 www.pompanette.com STIDD Systems, Inc. 220 Carpenter St., Greenport, NY 11944, USA PHONE 631-477-2400 x 120 www.stidd.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Component...
  • Page 346 Sorensen Lighted Controls, Inc. 75 Locust St. Hartford, CT 06114 PHONE 800 275-7089 860 527-3092 FAX 860 527-6047 www.solico.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Component Krogen 58’ Manual, Hull 58014...
  • Page 347 Twin Disc, Incorporated Corporate Office: 1328 Racine Street, Racine, WI 53403, USA PHONE 262-638-4000, FAX 262-638-4482 Marketing, 262-638- 4480 www.twindisc.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Component...
  • Page 348 USA Distributor IMTRA Corporation, 30 Samuel Barnet Blvd. New Bedford, MA 02745, USA PHONE 508-995-7000, FAX 508-998-5359 www.cantalupi.it ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Component Krogen 58’ Manual, Hull 58014...
  • Page 349 Division Headquarters: 5639 W. Genesee St., Camillus, NY 13031, USA PHONE 800-365-1185 / 315-487-0800, FAX 315-487-4028 www.crucibleservice.com www.aquamet.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Component...
  • Page 350 PHONE U.S. and CANADA 800-668-1100 www.jennair.com BALMAR® Regulator: 19009 61 Ave. NE, Arlington, WA 98223, USA PHONE 360-435-6100, FAX 360-435-3210 www.balmar.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Component Krogen 58’ Manual, Hull 58014...
  • Page 351 36 Hogan Road, Lewiston, ME 04240, USA PHONE 207-782-1885 www.fmmattsson.com Scandvik, Inc P.O. Box 68, Vero Beach, FL 32961-0068, USA PHONE 800-535-6009 www.scandvik.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Component...
  • Page 352 Edson Steering Wheel: Edson International 146 Duchaine Boulevard, New Bedford, MA 02745-1292, USA PHONE 508-995-9711, FAX 508-995-5021 www.edsonmarine.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Component Krogen 58’ Manual, Hull 58014...
  • Page 353 New Found Metals Washdown Valve: 240 Airport Road Port Townsend, WA 98368 PHONE 360-385-3315 888-437-5512 FAX 360-385-6097 www.newfoundmetals.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Component Manufacturers List – Sorted by Component...
  • Page 354 Imtra/Exalto 30 Samuel Barnet Blvd. New Bedford, MA 02745 PHONE 800 989-2580 508 995-7000 FAX 508 998-5359 www.imtra.com ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Component Manufacturers List – Sorted by Component Krogen 58’ Manual, Hull 58014...

  • Page 355: Appendices

    Appendix L - Float Plan ………………………………………………………………. 397 Appendix M - Law Enforcement …………………………………………………….. 401 Appendix N - VHF Channel Usage …………………………………………………… 407 Appendix O - Notes ……………………………………………........411 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...

  • Page 357: Appendix A - Inspection Check List

    Turn ON VHF radio. Perform radio check and listen to Weather Channel. Ensure navigation and anchor lights are operational. Ensure horn and windshield wipers are operational. Check Pilothouse and other interior lights are operational. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix A – Inspection Check List...

  • Page 358: Fire Suppression System

    Inspect pressure at stabilizer manifold. See page 66. Listen for normal actuator sounds. Generators Check for raw water exhaust. Monitor gauges. See page 132. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix A – Inspection Check List Krogen 58’ Manual, Hull 58014...

  • Page 359: Shut Down

    Move Engine Control switch to ‘STOP’ until engine stops. Close raw water intake seacocks. If Generators will not be used for several days, close fuel supply valves. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix A – Inspection Check List...

  • Page 360: Weekly

    Inspect actuators and cylinders for oil leaks. Inspect cylinder hoses for chafing. Fuel System Check fuel filters for water and other contaminants. See page 119. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix A – Inspection Check List...

  • Page 361: Monthly

    Check hydraulic fluid level. See page 185. Check system air pressure. See page 185. Bi-Monthly Grease Windlass main bearing. See page 195. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix A – Inspection Check List Krogen 58’ Manual, Hull 58014...

  • Page 362: Quarterly

    Have a qualified marine mechanic inspect the entire system. Transmissions Change oil each 1000 hours or every six months. Windlass Check oil level in gear box. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix A – Inspection Check List Krogen 58’ Manual, Hull 58014...

  • Page 363: Annually

    Clean the heat exchanger core. Refer to “Northern Lights Operator’s Manual”, page 18, SP15. Refrigerator Clean and defrost. Sanitation System Replace holding tank vent filter. See page 174. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix A – Inspection Check List Krogen 58’ Manual, Hull 58014...

  • Page 364: Steering System

    Inspect the Bow Thruster – clean and repair as necessary. It is recommended that tunnel and thruster propeller be painted with bottom paint. Inspect the Stabilizers – clean and repair as necessary. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 365: Appendix B - Engine Maintenance Log

    Mfr: Twin Disc Model: MG5075A Oil Type: ______ Oil Capacity: _____ Ratio: 2.88:1 BOM Number: Port: _______________ Stbd: ________________ Notes:__________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix B – Engine Maintenance Log...
  • Page 366 Oil Filter: NL 24-03100 Drive Belt: NL 40-02003 Zincs for Heat Exchanger: NL 21-12010 Notes:__________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix B – Engine Maintenance Log Krogen 58’ Manual, Hull 58014...

  • Page 367: Starboard Engine Maintenance Log

    Starboard Engine Maintenance Log Date Eng. STARBOARD ENGINE Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix B – Engine Maintenance Log...
  • Page 368 Date Eng. STARBOARD ENGINE Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix B – Engine Maintenance Log Krogen 58’ Manual, Hull 58014...

  • Page 369: Port Engine Maintenance Log

    Port Engine Maintenance Log Date Eng. PORT ENGINE Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix B – Engine Maintenance Log...
  • Page 370 Date Eng. PORT ENGINE Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix B – Engine Maintenance Log Krogen 58’ Manual, Hull 58014...

  • Page 371: Starboard Transmission Maintenance Log

    Starboard Transmission Maintenance Log Date Eng. STARBOARD TRANSMISSION Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix B – Engine Maintenance Log...
  • Page 372 Date Eng. STARBOARD TRANSMISSION Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix B – Engine Maintenance Log Krogen 58’ Manual, Hull 58014...

  • Page 373: Port Transmission Maintenance Log

    Port Transmission Maintenance Log Date Eng. PORT TRANSMISSION Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix B – Engine Maintenance Log...
  • Page 374 Date Eng. PORT TRANSMISSION Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix B – Engine Maintenance Log Krogen 58’ Manual, Hull 58014...

  • Page 375: 20Kw Generator Maintenance Log

    20Kw Generator Maintenance Log Date Gen. 20Kw GENERATOR Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix B – Engine Maintenance Log...
  • Page 376 Date Gen. 20Kw GENERATOR Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix B – Engine Maintenance Log Krogen 58’ Manual, Hull 58014...

  • Page 377: 12Kw Generator Maintenance Log

    12Kw Generator Maintenance Log Date Gen. 12Kw GENERATOR Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix B – Engine Maintenance Log...
  • Page 378 Date Gen. 12Kw GENERATOR Hours NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix B – Engine Maintenance Log Krogen 58’ Manual, Hull 58014...

  • Page 379: Maintenance Notes

    Maintenance Notes Date NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix B – Engine Maintenance Log...
  • Page 380 Date NOTES ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix B – Engine Maintenance Log Krogen 58’ Manual, Hull 58014...

  • Page 381: Appendix C - Daily Engine & Generator Logs

    Daily Engine Log Date: ____________ Port: Engine Hours on Meter: _____________ Oil Added: _________ Stbd: Engine Hours on Meter: _____________ Oil Added: _________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix C – Daily Engine & Generator Log...
  • Page 382 Stbd: Idle rpm Oil Pressure Coolant Temperature Voltage 1200 50 psi 180º-202º 13-14 _______ ________ _______ __________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix C – Daily Engine & Generator Log Krogen 58’ Manual, Hull 58014...
  • Page 383 Port: Engine Hours on Meter: _____________ Oil Added: _________ Stbd: Engine Hours on Meter: _____________ Oil Added: _________ Check box if readings are in Normal range. Otherwise record Actual reading. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix C – Daily Engine & Generator Log...

  • Page 384: Daily Generator Log

    11-15 V DC ________ _______ __________ 12Kw: Oil Pressure Coolant Temperature Voltage >15 psi <200º F 11-15 V DC ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix C – Daily Engine & Generator Log Krogen 58’ Manual, Hull 58014...
  • Page 385 ________ _______ __________ Observations: All Normal ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix C – Daily Engine & Generator Log Krogen 58’ Manual, Hull 58014...
  • Page 386 Coolant Temperature Voltage <200º F >15 psi 11-15 V DC ________ _______ __________ Observations: All Normal ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix C – Daily Engine & Generator Log Krogen 58’ Manual, Hull 58014...
  • Page 387 Voltage <200º F >15 psi 11-15 V DC ________ _______ __________ Observations: All Normal ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix C – Daily Engine & Generator Log Krogen 58’ Manual, Hull 58014...
  • Page 388 Voltage <200º F >15 psi 11-15 V DC ________ _______ __________ Observations: All Normal ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix C – Daily Engine & Generator Log Krogen 58’ Manual, Hull 58014...

  • Page 389: Appendix D - Fuel Log

    (*) Normally calculated by dividing Total Gallons by Total Eng Hours and adding 1.70 GPH (6.5 LPH) for each hour of 20Kw Generator usage and 1.2 GPH (4.5 LPH) for each hour of 12Kw Generator usage. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 390 (*) Normally calculated by dividing Total Gallons by Total Eng Hours and adding 1.70 GPH (6.5 LPH) for each hour of 20Kw Generator usage and 1.2 GPH (4.5 LPH) for each hour of 12Kw Generator usage. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 391 (*) Normally calculated by dividing Total Gallons by Total Eng Hours and adding 1.70 GPH (6.5 LPH) for each hour of 20Kw Generator usage and 1.2 GPH (4.5 LPH) for each hour of 12Kw Generator usage. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.
  • Page 392 (*) Normally calculated by dividing Total Gallons by Total Eng Hours and adding 1.70 GPH (6.5 LPH) for each hour of 20Kw Generator usage and 1.2 GPH (4.5 LPH) for each hour of 12Kw Generator usage. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 393: Appendix E - Tools And Equipment Needed

    • Paper towels • Plastic scouring pad • Protective clothing • Protective eyewear • Scotch-Brite® or similar pad ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix E – Tools and Equipment Needed...

  • Page 394: Supplies

    • Warm water • Water proof grease and grease gun • Wax for gel coat • Windex (or equivalent) ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix E – Tools and Equipment Needed Krogen 58’ Manual, Hull 58014...

  • Page 395: Appendix F - Fluids Table

    Hydraulic Fluid meeting Mil-H-5606 Steering Reservoir specifications. See ‘Steering System’ section for other acceptable fluids. See lubrication data plate on transmission. Transmission Oil ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix F – Fluids Table...

  • Page 397: Appendix G - Equipment Serial Numbers

    24 months prior to 2000 hrs Transmission MG-5075A Twin Disc 12 months Gear Ratio: 2.88:1 BOM Number: _________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix G - Equipment Serial Numbers...

  • Page 398: Generators

    PRX-3C Cruisair 2 yrs Parts & Labor Condensing Unit 24,000 BTU FX 24C3-P Cruisair 2 yrs Parts & Labor ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix G - Equipment Serial Numbers...

  • Page 399: Bow Thruster

    Engine Room Bow Thruster Description Model Number Manufacturer Warranty Serial Number Hydraulic Bow Thruster TRAC American Bow Thruster 1 year ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix G - Equipment Serial Numbers...

  • Page 400: Electrical System

    Model Number Manufacturer Warranty Serial Number Holding Tank Discharge Pump T-Series 24 SeaLand 1 year with Macerator 270 GPH ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix G - Equipment Serial Numbers...

  • Page 401: Stabilizer System

    Refrigerator/Freezer, French JFC2089HEP Jenn-Air Expressions 1st year full Door, bottom Freezer, SS face 2-5th years 120V AC limited, major components ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix G - Equipment Serial Numbers...
  • Page 402 Panel Kit #24-M117 120V AC warranty Washer 240V AC 15 amp W6761 Asko 3 years full, 4/5th years limited, lifetime tank ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix G - Equipment Serial Numbers...

  • Page 403: Owner Installed Equipment

    Owner Installed Equipment Description Model Number Manufacturer Warranty Serial Number ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix G - Equipment Serial Numbers...
  • Page 404 Description Model Number Manufacturer Warranty Serial Number ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix G - Equipment Serial Numbers...

  • Page 405: Appendix H - Approved Service Centers

    Fax: (206) 547-3789 Osprey Marine Composites 389 Deale Rd. Tracy’s Landing, MD 20779 www.ospreycomposites.com Tel: (410) 867-3022 Fax: (301) 261-5370 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix H - Approved Service Centers...
  • Page 406 Tel: (800) 397-3442 (804) 725-3440 Fax: (804) 725-7904 For other Service Center locations, contact Kadey-Krogen at (800) 247-1230. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix H - Approved Service Centers Krogen 58’ Manual, Hull 58014...

  • Page 407: Appendix I - Warranties

    Warranty Administration John Deere Power Systems P. O. Box 5100 Waterloo, IA 50704-5100 Or call them at: 319-292-5871 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix I - Warranties...

  • Page 409: Appendix J - Dinghy Information

    Size: _________ Weight: ___________ Serial Number: _________________ Registration Number: ___________________________ Dinghy Engine Make: _______________________________________ HP: _______ Weight: __________ Serial Number: _________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix J - Dinghy Information...

  • Page 411: Appendix K - Health Information Form

    ALLERGIES OR REACTIONS TO MEDICINES: ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ MOST RECENT IMMUNIZATIONS: Tetanus (Td)__________ Others_____________________________________________ OTHER PERTINENT MEDICAL INFORMATION: ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix K - Health Information Form...
  • Page 412 ALLERGIES OR REACTIONS TO MEDICINES: ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ MOST RECENT IMMUNIZATIONS: Tetanus (Td)__________ Others_____________________________________________ OTHER PERTINENT MEDICAL INFORMATION: ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix K - Health Information Form Krogen 58’ Manual, Hull 58014...
  • Page 413 ALLERGIES OR REACTIONS TO MEDICINES: ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ MOST RECENT IMMUNIZATIONS: Tetanus (Td)__________ Others_____________________________________________ OTHER PERTINENT MEDICAL INFORMATION: ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix K - Health Information Form...
  • Page 414 ALLERGIES OR REACTIONS TO MEDICINES: ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ MOST RECENT IMMUNIZATIONS: Tetanus (Td)__________ Others_____________________________________________ OTHER PERTINENT MEDICAL INFORMATION: ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix K - Health Information Form Krogen 58’ Manual, Hull 58014...

  • Page 415: Appendix L - Float Plan

    4. Survival Equipment (Check as Appropriate) #____PFDs Flares Mirror Smoke Signals Flashlight Food Raft or Dinghy Water EPIRB Others________________________________________________________________ ________________________________________________________________________ 5. Marine Radio ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix L - Float Plan...
  • Page 416 ______________________________ ______ __________________ Yes____ No____ ______________________________ ______ __________________ Yes____ No____ ______________________________ ______ __________________ Yes____ No____ 9. Additional Information ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix L - Float Plan Krogen 58’ Manual, Hull 58014...
  • Page 417 Mirror Smoke Signals Flashlight Food Raft or Dinghy Water EPIRB Others________________________________________________________________ _______________________________________________________________________ 5. Marine Radio Type________________________________________Freqs.______________________ Digital Selective Calling (DSC) ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix L - Float Plan...
  • Page 418 ______________________________ ______ __________________ Yes____ No____ ______________________________ ______ __________________ Yes____ No____ ______________________________ ______ __________________ Yes____ No____ 9. Additional Information ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix L - Float Plan Krogen 58’ Manual, Hull 58014...

  • Page 419: Appendix M - Law Enforcement

    In any event, those procedures are written on the reverse of the form. If you have any questions ask the CG boarding officer, or call the U.S. Coast Guard Infoline at 800-368-5647. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 420: Boating Under The Influence (Bui)

    Coast Guard boarding officer, as well as for the specific violations which were the basis for the termination order. Violators may be fined not more than $1,000 or imprisoned not more than one year or both. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 421: Reporting Boating Accidents

    The master or person in charge of a vessel is obligated by law to provide assistance that can be safely provided to any individual in danger at sea. The master or person in charge is subject to a fine and/or imprisonment for failure to do ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 422: Requesting Towing Assistance (Non-Distress Call)

    • Number of people on board 6. Release transmit button 7. Wait for 10 second - if no response Repeat "MAYDAY" Call. ***HAVE ALL PERSONS PUT ON LIFE JACKETS*** ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix M - Law Enforcement...

  • Page 423: False Distress Alerts

    Channel 16 is a calling and distress channel. It is not to be used for conversation or radio checks. Such traffic should be conducted on an authorized working channel. (See Appendix N - VHF Channel Usage) ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice.

  • Page 425: Appendix N - Vhf Channel Usage

    16. 157.150 157.150 U.S. Coast Guard only 157.200 161.800 Public Correspondence (Marine Operator) 157.250 161.850 Public Correspondence (Marine Operator) ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix N - VHF Channel Usage...
  • Page 426 Public Correspondence (Marine Operator) 157.275 161.875 Public Correspondence (Marine Operator) 157.325 161.925 Public Correspondence (Marine Operator) 157.425 157.425 Commercial, Intership only. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix N - VHF Channel Usage Krogen 58’ Manual, Hull 58014...

  • Page 427: Noaa Weather Radio Frequencies

    P - PAPA X - X-RAY H - HOTEL Q - QUEBEC Y - YANKEE I - INDIA Z - ZULU ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 Appendix N - VHF Channel Usage...

  • Page 429: Appendix O - Notes

    _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix O - Notes Krogen 58’ Manual, Hull 58014...
  • Page 430 _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix O - Notes Krogen 58’ Manual, Hull 58014...
  • Page 431 _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix O - Notes Krogen 58’ Manual, Hull 58014...
  • Page 432 _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Appendix O - Notes Krogen 58’ Manual, Hull 58014...

  • Page 433: Glossary

    Barcol Hardness Tester - Also called Barcol Impressor. The instrument used to measure Barcol Hardness. The instrument gives a direct reading on a 0-100 scale ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 434 The positive terminal from one battery is connected to the negative terminal of the next battery in the series, until all batteries are connected. Batteries in Series ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. GLOSSARY...
  • Page 435 An electric circuit is the path of an electric current. A closed circuit has a complete path. An open circuit has a broken or disconnected path. Coaming - Raised edge around hatches to keep water out. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 436 - A small rail on tables and counters used to keep objects from sliding off when the vessel rolls and pitches. Flybridge - An elevated steering position located on top of the cabin of a powerboat. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. GLOSSARY...
  • Page 437 - U.S. gallons per hour Gross Tonnage – Gross tonnage is a unitless measure of a boats internal volume. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 438 - A small hole or slot in a frame or web for the purpose of preventing water or oil from collecting; a drain hole. . – Length Over All – Length On Deck ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. GLOSSARY...
  • Page 439 - A screw type device that drives or pushes a boat through the water. Raw Water – The body of water in which the vessel is currently located. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014...
  • Page 440 Wet Cell Battery – Also called ‘lead-acid’ is any type of battery that uses liquid as an electrolyte. AGM is one type of wet cell battery. ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. GLOSSARY...

  • Page 441: Index

    ... 41 remote operation ......56 equalization ........42 Capacity Battery Chargers ......... 73 bilge pumps GPH......43 Battery Equalizer black water holding tank....172 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 INDEX...

  • Page 442: Krogen 58' Manual, Hull

    ......... 62 Emergency Shut Off pinning of fins ......... 65 generator ........135 reservoir location ......66 Emergency Tiller Dinghy where fitted ........184 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. INDEX Krogen 58’ Manual, Hull 58014...
  • Page 443 Fan Speed Adjustment ......30 when to replace ......120 Fastening Fuel Filter Element bolts and machine screws....17 manufacturer and model ....116 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 INDEX...
  • Page 444 ..71 GFI Receptacles ........67 dispose of coolant ....131, 152 Girders..........16 drain oil from engines or generators Glossary ..........415 ........... 141 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. INDEX Krogen 58’ Manual, Hull 58014...
  • Page 445 105 Icemaker fuel filters ........116 maintenance ........208 fuel tank sight gauge ..... 115 operation ........207 fuel tanks........115 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 INDEX...
  • Page 446 130 engine controls ......162 propulsion engines ......141 exhaust system ......100 transmissions......... 141 fire suppression system ....103 Oil Change System ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. INDEX Krogen 58’ Manual, Hull 58014...
  • Page 447 ........215 Stainless Steel Regulator how to maintain......226 LPG ..........137 Stateroom/Den ........22 Remote Fan Operation ......29 Steering Remote Operation ....... 56 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 INDEX...
  • Page 448 ........219 Cooling........163 serial number Raw Water Washdown ....167 location........219 Sanitary ......... 169 WASTE Deck Discharge Shower Drain/Sink Drain....179 location.......... 171 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. INDEX Krogen 58’ Manual, Hull 58014...
  • Page 449 Water separator ....See Fuel Filter sacrificial, purpose ......49 Water Tanks sacrificial, rate of corrosion .... 50 capacity ......... 105 stabilizer heat exchanger....66 ©2008 Kadey-Krogen Yachts, Inc. www.kadeykrogen.com Subject to change without notice. Krogen 58’ Manual, Hull 58014 INDEX...

Table of Contents

Save PDF
