OPERATING INSTRUCTIONS
Modelle:
in areas of specialised cultivation such as nurseries, orchards and
vineyards, ornamental plant and vegetable gardens, as well as
agricultural, forestry, communal and non-cultivated lands.
The unit has been developed for the undiluted
application of ROUNDUP
Important:
Before application, carefully read the usage instructions for the unit and the plant protective agent!
Observe safety instructions!
For questions regarding plant protective agents, consult the manufacturer!
Observe the requirements and regional regulations for the use of herbicides and, if necessary,
obtain approval from the responsible authorities (e.g. environmental conservation agency)!
Application is to be performed only by a competent user.
Remarks about usage of the unit:
Settings: This system is not suitable for the application of water.
Use herbicides for testing the spray action and calibration of the flow rate.
Usage: Position the spray hood directly above the ground –
if the spray hood is held too high, the danger of spray driftage exists.
Cleaning: Do not clean the unit with a high-pressure spray or an intense water jet spray.
Noise emission from the unit equates to less than 70 dB(A).
Manufacturer:
Mantis ULV-Sprühgeräte GmbH
Germany 21502 Geesthacht, Vierlander Str. 11 a
Telephone +49(0)4152-8459-0, FAX +49(0)4152-8459-11
Web: www.mantis-ulv.eu Email: mantis@mantis-ulv.eu
MANKAR
MANKAR-P 30-50 Flex, MANKAR-P 50
MANKAR-P 60-80, MANKAR-P 70-110
MANKAR-GP 60-80 , MANKAR-GP 70-110
ULV- Applicator for weed control
®
products (Glyphosate).
1
09.03.2009
Advertisement
Related Manuals for Mantis ULV MANKAR-P 50
Summary of Contents for Mantis ULV MANKAR-P 50
-
Page 1: Operating Instructions
OPERATING INSTRUCTIONS MANKAR Modelle: MANKAR-P 30-50 Flex, MANKAR-P 50 MANKAR-P 60-80, MANKAR-P 70-110 MANKAR-GP 60-80 , MANKAR-GP 70-110 ULV- Applicator for weed control in areas of specialised cultivation such as nurseries, orchards and vineyards, ornamental plant and vegetable gardens, as well as agricultural, forestry, communal and non-cultivated lands. - Page 2 For the undiluted application of Roundup products (Glyphosate) The instructions on this page are valid for all MANKAR applicator units. Details regarding assembly, use and replacement parts are provided on the following pages: MANKAR-P 30-50 FLEX, MANKAR-P 50: Pages 4-5 MANKAR-P 60-80, MANKAR-P 70-110:...
- Page 3 Applicator unit function: Segmental atomisers are driven by means of a rechargeable battery. Metering on all the units mentioned is path-dependent and takes place by means of a wheel driven pump. Droplets are formed by the centrifugal force of the rotating atomiser. The droplets are discharged downwards by the segmental atomiser through a continuously variable, adjustable segment.
- Page 4 MANKAR-P 30-50 FLEX MANKAR-P 50 Shut-off valve position closed Spray hood 30-50 FLEX Assembly Checking the output volume Screw the applicator unit support stand (A) together with Place an underlay (e.g. cardboard or paper) on the the stand foot (B).
- Page 5 Pump drive Item Part No. Description 102360 MANKAR-P 30-50 FLEX 101093 MANKAR-P 50 100349 Rubber hand grip for MANKAR 101272 Handle bar for MANKAR 101273 Handle bar VA extension for MANKAR-P 100459 Powerpack compl. 1 battery 6V-7 Ah, for MANKAR...
- Page 6 MANKAR-P 60-80 MANKAR-P 70-110 Shut-off valve position closed Spray hood 60-80 Assembly Adjusting the spray width a) Loosen the spray hood screws in the elongated holes Screw the applicator unit support stand (A) together with on the upper side of the sheet metal skirt and unscrew the stand foot (B).
- Page 7 Pump drive, see page 5 Part Art. No. Designation 101094 MANKAR-P 70-110 102391 MANKAR-P 60-80 100349 Rubber hand grip for MANKAR 101272 Handle bar VA for MANKAR-P VA, -110P VA 101273 Handle bar extension VA for MANKAR-P VA, -110P VA 100459 Powerpack with 1 battery, 6 V - 7 Ah, for MANKAR-P,-110P 100368...
- Page 8 MANKAR-GP 60-80 MANKAR-GP 70-110 Shut-off valve position closed Spray hood GP 60-80 Assembly Adjusting the spray width a) Loosen the spray hood screws in the elongated holes Screw the spray hood together with the height on the upper side of the sheet metal skirt and unscrew adjustment (K) and the unit support beam (C).
- Page 9 Pump drive Part Art. No. Designation 102490 MANKAR-GP 60-80 100526 MANKAR-GP 70-110 100349 Rubber hand grip for MANKAR 2 + 3 101272 Handle bar for MANKAR 100419 Handle bar extension, MANKAR GP 100990 Hexagon screw M 8 x 20 mm stainless steel 100429 Connection for handle bar extension MANKAR GP 100397...
- Page 10 PartArt. No. Designation Part Art. No. Designation 100459 Powerpack with 1 battery, 6 V - 7 Ah, for MANKAR-P models 100320 Atomiser for MANKAR 102312 Powerpack with 1 battery, 6 V - 7 Ah, for MANKAR-GP models 102417 Motor module for segmental atomiser MANKAR 100469 Powerpack housing 100478 Atomiser disc for segmental atomiser 100461 Clamping rail, round milled for MANKAR P powerpack...
-
Page 11: Troubleshooting
Troubleshooting Fault occurrence Cause Rectification Atomiser disc not rotating Atomiser contaminated Thoroughly clean atomiser, remove plant parts as necessary Battery empty Charge battery Fuse blown Replace fuse on powerpack (Replacement fuses are located in the powerpack housing) No electrical contact Check cable or connector contact Battery defective Install new battery... - Page 12 EG-Declaration of conformity Council Directive 2006/42/EG Mantis ULV-Sprühgeräte GmbH, Vierlander Straße 11 a, 21502 Geesthacht declare under our sole responsibility that the following products are in conformity with the provisions of the following Council Directive: 2006/42/EG...
