Samson Electronics Inc.
3400 E. Slauson Ave.
Maywood, CA 90270
Ph: 323.585.6393
Fax: 323.585.6202
Web:
http://www.blackmoremobile.com
BBX-503 Portable Stereo System
Introduction:
The BBX-503 is a portable and amplified stereo system with integrated MP3 music
player, Bluetooth Connectivity, Dual ¼" MIC Inputs LED and accent lighting. This
model boasts USB /SD card inputs as well as RCA stereo inputs and an FM tuner.
Sound is produced by dual 3" full range drivers and a 6.5" port tuned bass driver
delivering 250W of total musical power. The BBX-500 also has a built in RECORD
function that allows you to record directly to a USB storage device or SD card.
Features:
Portable and Amplified
•
Music Player with SD Card and USB inputs
•
Bluetooth Connectivity
•
FM Radio
•
LED Accent lighting
•
Wireless remote control
•
250 watts of total musical output
•
Record to USB or SD
•
Weight: 14 lbs
•
Caution:
Please read All Operating Instructions before using this product
•
Avoid electrical shock, DO NOT OPEN THIS UNIT, THERE ARE NO REPLACEABLE PARTS
•
INSIDE. Please refer to your warranty information for service.
Do not Expose this product to Moisture, Water, Rain or Snow. Keep away from direct heat
•
sources. Damaged items will not be accepted for warranty
Do not clean this unit with solvents or chemicals
•
Insure that all volume and gain controls are set to "0" when connecting source units
•
Advertisement
Summary of Contents for BLACKMORE BBX-503
- Page 1 Samson Electronics Inc. 3400 E. Slauson Ave. Maywood, CA 90270 Ph: 323.585.6393 Fax: 323.585.6202 Web: http://www.blackmoremobile.com BBX-503 Portable Stereo System Introduction: The BBX-503 is a portable and amplified stereo system with integrated MP3 music player, Bluetooth Connectivity, Dual ¼” MIC Inputs LED and accent lighting. This model boasts USB /SD card inputs as well as RCA stereo inputs and an FM tuner. Sound is produced by dual 3” full range drivers and a 6.5” port tuned bass driver delivering 250W of total musical power. The BBX-500 also has a built in RECORD function that allows you to record directly to a USB storage device or SD card. Features: Portable and Amplified • Music Player with SD Card and USB inputs • Bluetooth Connectivity • FM Radio • LED Accent lighting • Wireless remote control • 250 watts of total musical output • Record to USB or SD • Weight: 14 lbs • Caution: Please read All Operating Instructions before using this product • Avoid electrical shock, DO NOT OPEN THIS UNIT, THERE ARE NO REPLACEABLE PARTS • INSIDE. Please refer to your warranty information for service.
- Page 2 1.MIC Volume Control 2. Menu 3. Record Button 4. SD Card Input 5. USB input 6. Mode 7. Volume Control 8. Previous track 9. Play/Pause 10. Next Track 11. Master Power Switch 12. AC Power cord 13. RCA Stereo In 14. 1/4” MIC Inputs 15. FM Antenna...
- Page 3 16. Mute 17. Master Power 18. Previous Track 19. Play/Pause 20. Next track 21. Track Repeat 22. Voice Prompt On/OFF 23. Input/Mode Selector . 24. Record Start/Stop 25. Record Playback 26.Delete Recording 27. MIC echo decrease 28. MIC Echo increase 29. MIC Priority Selector 30. Bass Level control 31. Treble level Control 32. MIC Volume Control 33. Master Volume Control 34. EQ preset selector 35. Direct channel and track access...
- Page 4 Functions: 1. MIC volume control: This adjusts the gain level for attached microphones 2. Menu: This button gives you access to Sound adjustments for audio and MIC playback 3. Record : Press this button to start or stop a recording 4. SD card Input: Capable of reading cards up to 4GB. Music files must be formatted as MP3 in order to be played via SD card. 5. USB Input: This is a full size USB2.0 female input. It has a read capacity of 4GB. Music files must be formatted as MP3 in order to be played via USB 6. Mode: This button allows you to select between, USB, SD, BT, Or FM Radio for playback. 7. Master Volume Control: This controls the overall output of the speakers. This volume control supersedes all other built in volume controls. 8. Previous Track: Use this button to go back one track 9. Play /Pause/Scan(FM) : Press this button to start or pause an MP3 track played via USB or SD. In FM mode this button will scan available radio stations. Press scan again to stop at a station. 10. Next Track: Use this button to play the next track 11. Master power switch: Use this switch to power the unit on or off. 12. AC power connection only use supplied AC power cord 13. RCA Stereo line inputs: These allow input from source units using L/R stereo RCA connections 14. ¼” MIC input 15. FM Antenna 16. Mute: Mutes all Sound from all Sources 17.
-
Page 5: Operation
Operation: Setup: 1. Ensure that the unit is connected to the appropriate power source using the provided AC power plug. 2. Plug in the AC power cable and choose your input method using the MODE button on the unit or remote. 3. Ensure that the master volume is turned to the “0” position before connecting any audio source. 4. Place the speaker in a location that is away from any direct heat source, moisture, or extreme humidity. Playback: *Use the Mode select button to choose between SD Card, USB, or Bluetooth* 1. Using a USB storage device: The player can accept thumb drives and storage devices in USB 2.0 or less format. Files can be played back formatted as MP3 only. The USB connection can read devices up to 4GB. 2. Using a SD card: The player can accept thumb drives and storage devices in USB 2.0 or less format. Files can be played back formatted as MP3 only. The SD Card input can read devices up to 4GB. 3. Using Bluetooth: Ensure that your audio source has bluetooth enabled/discoverable, next turn your speaker on and select bluetooth mode. Search for available Bluetooth devices on your source unit and select BBX-500. Once connected you can play audio from your device when the BBX-500 is in Bluetooth Mode. 4. Using Line in: Ensure that your line In RCA connections is securely connected to the speaker and audio source before powering on this unit. If your music source has a volume control ensure that the volume is set to 75%. Begin playing music and adjust the master volume to your desired level. 5. Using Microphones: Ensure that the Microphone volume is set to “0”. Connect your microphone to ¼” Jacks located on inputs one and two. Ensure that your microphone is turned on. Adjust the volume control to desired volume. 6. Using FM: Press the Mode button till FM is selected. Once in FM mode press the Play/pause button on the speaker and the FM tuner will begin programming all available stations. You can also manually input the desired radio station using the keypad on the remote control unit. - Page 6 Maintenance and care: Store and use in a dry environment away from direct heat sources and • moisture. Do not clean with solvents or detergents. Only use a mildly damp cloth • to dust or clean. Use on a flat stable surface. This unit will vibrate when played at high • volume and will shift position. Please use caution when placing this on any surface Use only the correct power source. AC 110-240V 50/60 Hz • Maintain all gain controls at correct levels. Excessive gain controls • coupled with high volume can damage the speaker drivers. Collapse all antennas and disconnect all cables before moving the unit. • Troubleshooting: Music files not read: Ensure that your music files are encoded as MP3 • Audio Files. No Sound: Please ensure that all volume and gain controls are not in • the “0” position and that all source units are on and producing volume. Check volume controls at source units Bluetooth not connecting: Ensure that the Bluetooth devise you are • connecting has Bluetooth on and is discoverable. No Power: please ensure that your AC power connection is fully • engaged and connected to a non surging power source. Sound is distorted: Please ensure that your source volume and input • gains on the speaker are even and balanced. Also check that your connecting cables from source units are not damaged or broken. No sound from Microphone: Ensure that the MIC gain control is not • set to “0” ensure that the microphone is turned on and that all connecting cables are fully engaged and working properly. If you are still having technical issues with your product and could use some assistance please contact us at support@samsonelec.com...
