Summary of Contents for RevJams StudioLite REV100-BLK

  • Page 1 REV100-BLK StudioLite Bluetooth Headphones U S E R S M A N U A L...
  • Page 2 Thank you for choosing the RevJams Studio Lite Bluetooth Headphones ! Please take the time to read this manual carefully, even if you are already familiar with a similar product.
  • Page 3: Package Contents

    PACKAGE CONTENTS • RevJams Studio Lite Bluetooth Headphones • Micro USB charging cable • AUX audio cable • Users guide...
  • Page 4 BLUETOOTH HEADPHONE CONTROLS 1. Volume – / Previous track 2. Volume + / Next track 3. Multi-Function Button - Power/Play/Pause/Pair 4. Micro USB charging port 5. Microphone 6. LED indicator 7. AUX audio port...
  • Page 5: Led Indicator Guide

    LED INDICATOR GUIDE INDICATOR STATUS Blue light Power On Turn red to power o Power O Red light Charging Red and blue light Bluetooth Pairing Mode ash alternately Connected to Bluetooth Blue LED flashing slowly...
  • Page 6: Getting Started

    GETTING STARTED To use your RevJams Studio Lite Bluetooth Headphones, please follow the steps below: 1. Ensure your Bluetooth headphones are fully charged. 2. Pair your Bluetooth headphones to a Bluetooth- enabled device prior to use. (See Pairing your Headset instructions)
  • Page 7: Pairing Your Headset

    PAIRING YOUR HEADSET In order to use your RevJams Studio Lite Bluetooth Headphones with a Bluetooth-enabled device, you will rst need to pair the two. 1. Begin with the headset being powered o and fully charged. 2. Place the headset and the mobile phone where they are easily viewable and no more than 3ft apart.
  • Page 8 POWERING ON THE HEADSET Press and hold down the Multi-Function button for 3-4 seconds until a BLUE light appears. PRESS & HOLD POWERING OFF THE HEADSET Once powered on, Press and hold down the Multi-Function button until a RED light appears to turn o .
  • Page 9: Wearing Your Headset

    CONNECTION WITH THE LAST PAIRED DEVICE When powered on, the headset will automatically connect with the last successfully paired device. WEARING YOUR HEADSET The Left / Right indicator is located on the inside of the headphones band. Be sure to adjust the headband so that the ear cups rest comfortably on your ear, only with the right fit will you enjoy a snug fit &...
  • Page 10: Call Mode

    CALL MODE Answering a Call Short Press the Multi-Function button once to accept the call, or answer the call normally via your mobile phone. Rejecting a Call Press and hold the Multi-Function button for 2 seconds to reject the incoming call. Ending a Call Short Press the Multi-Function button to end the call or end the call directly...
  • Page 11: Music Mode

    MUSIC MODE Adjusting the Press and hold the Volume + to Volume increase volume or Volume – to decrease volume. You can also adjust the volume on your handset or device Play/Pause Once connected, Press the Music Multi-Function button once to play music.
  • Page 12: Troubleshooting

    TROUBLESHOOTING If you are unable to connect your headset and mobile phone, please try the following: Ensure that your headset is fully charged and powered on. Ensure that the headset is paired with your mobile phone. Ensure that your mobile phone's Bluetooth feature is activated.
  • Page 13 in your pants pocket below waist level may produce varied results as your body can get between the music device & headphones. CARE AND MAINTENANCE OF YOUR HEADSET i. Consider turning your headset off before placing it in your pocket or bag. If the Power button is accidentally activated, your mobile phone may place an unintended call.
  • Page 14: Warranty

    WARRANTY At RevJams, we are dedicated to making the best quality product. To back this up, your RevJams Studio Lite Bluetooth Headphones are covered by a One (1) Year Limited Manufacturer’s Warranty. Details of the warranty are as follows: for a period of...
  • Page 15: Safety Information

    SAFETY INFORMATION Check local laws regarding the use of mobile phones and headsets while driving. If you use the headset while driving, ensure that your attention and focus remains on the road and you drive in a responsible and safe manner. Never allow children to play with the headset, as the small parts may be a choking hazard.
  • Page 16: Product Specifications

    PRODUCT SPECIFICATIONS Bluetooth version: 4.1 Frequency 2.402-2.480GHz Bluetooth mode: HSP HFP A2DP AVRCP Working range: 33 ft. Talk/Music time: Up to 20 hours Standby time: 250 hours Charging time: About 3 hours Battery: 400mAh 3.7V Polymer Li-ion Battery Speaker size: 40mm 110±3dB 20Hz~20KHz Microphone: 4015 -42+/-3dB 30-16KHZ Actual performance may vary due to the user's habits, different modes of operation, and mobile...
  • Page 17: Warning And Precautions

    If you suspect your battery may be dead after several attempts to charge, please visit www.revjams.com for support. Never disassemble the unit or attempt to remove the battery as that could cause leakage of an electrolyte...
  • Page 18: Fcc Warnings

    FCC WARNINGS Warning: Changes or modi cations to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
