- Page 1 UHD2-140 Owner’s Manual 1 x 4 HDMI 2.0 Distribution Amplifier PureLink E-mail: info@purelinkav.com 535 East Crescent Avenue www.purelinkav.com Ramsey, NJ 07446, USA Tel: 201.488.3232 For technical support, contact: Fax: 201.621.6118 support@purelinkav.com...
-
Page 2: Table Of Contents
Table of Contents 1-1 Package Contents 1-2 General Specification 1-3 Operation and Reliability Specifications 1-4 Main Features 1-5 Video Connection 1-6 Mechanical Specification 1-7 Technical Specification p.10 1-8 Warranty Information p.11 Manual version Release date 1/16/2017... -
Page 3: Package Contents
PureLink by Dtrovision 1-1 Package Contents Please make sure all of the following items are included in the package: 1) UHD2-140 Unit 2) DC 5V 2A Power supply adapter 3) Owner’s Manual... -
Page 4: General Specification
PureLink UHD2-140 1x4 HDMI 2.0 distribution amplifier is designed to distribute a single HDMI/DVI digital signal into multiple monitor without any degradation of original signal quality or distortion of the image. In addition, a dedicated IC chipset makes UHD2-140 capable of amplifying and distributing highest quality of video signal and UHD digital contents. -
Page 5: Operation And Reliability Specifications
PureLink by Dtrovision 1-3 Operation and Reliability Specification 1. Operating Environment Temperature : 32F ~ 140F (0℃~ 60℃) Humidity : 10% ~ 80% Altitude : 3,000m Max. 2. Transit Environment Temperature : -13F ~ 140F (-25℃~ 60℃) Humidity : 5% ~ 95% Altitude : 15,000m Max. -
Page 6: Main Features
2,300 ft using our fiber optical HDMI cables. 3. HDMI (High Definition Multimedia Interface) v 2.0 UHD2-140 is consisting of HDMI input and output ports, and it is conforms to HDMI 2.0 standard. 4. HDCP 2.2 (High-bandwidth Digital Content Protection) Compliant Our HDMI distribution amplifiers are fully HDCP compliant. -
Page 7: Video Connection
Video Connection 1. Turn off the whole system before connecting. 2. Connect your video source’s HDMI output port to the UHD2-140’s HDMI input port using standard HDMI cables (not included). 3. Connect your HDMI display’s HDMI input port to UHD2-140’s HDMI output port. - Page 8 PureLink by Dtrovision UHD2-140 provides Auto EDID management system to meet today’s sophisticated digital connectivity integration environment. There is an EDID setting DIP switch on the front of the unit; EDID SETTING DIP Switch Position EDID function Dip switch 1,2,3,4 “up” position Communicate EDID with factory default at 1080p 2ch Dip switch 1 "down"...
-
Page 9: Mechanical Specification
PureLink by Dtrovision 1-6 UHD2-140 Mechanical Specification UHD2-140 Dimension: 6.6” x 3.96” x 1.58” (167 x 100.5 x 40 mm) *RS-232 Port is used to connect to PC for firmware upload... -
Page 10: Technical Specification
PureLink by Dtrovision 1-7 Technical Specification Frequency bandwidth: 18 Gbps Supporting Graphic Resolution: Supports all standard display resolutions up to UltraHD/4K 4096x2160@50/60Hz (RGB 4:4:4 YCbCr 4:4:4, 4:2:2, 4:2:0) , 480i, 576i, 720p, 1080i, 1080p@60Hz Inputs: Single HDMI Input Output: Dual HDMI Output Power supply: DC 5V, 2A Adapter included Connector Pin Assignment Part No. - Page 11 1-8 Warranty Manufacturer’s Warranty (3-Year) PureLink warrants UHD2-140 to be free from defects in workmanship and materials, under normal use and service, for a period of three (3) years from the date of purchase from PureLink or its authorized resellers.
