- Page 1 OPERATION MANUAL TEMPERATURE. HUMIDITY MONITOR / ON-LINE LOGGER Monitor AMT208 On-line Logger AMT207...
-
Page 2: Material Supplied
INTRODUCTION Thank you for purchasing AMTAST’s Wall mount/desktop Temperature, Humidity monitor /online logger. It is used to measure air temperature and relative humidity with visible or audible alarms. FEATURES 1) Super large LCD simultaneously display of Temp., Relative humidity, Calendar (M/D) and Time (Clock) 2) Alarm threshold is selectable.(LEDs) -
Page 3: Operation
KEYPAD (MAIN FUNCTION) 1) MODE : MAX.MIN. display. 2) TRH.M. : Change value down 3) SEL./R : Change value up 4) UNIT : Select Temp. unit 5) POWER : Power on and power off OPERATION POWER ON/OFF Plug with adaptor or batteries, LCD shows current ,RH &... -
Page 4: Alarm Setting
ALARM SETTING Temp./RH alarm ON/OFF: In normal measurement, Press MODE+UNIT buttons , → bell will appear circularly from Temp. alarm on RH → → alarm on Temp. &RH alarms on Temp. & RH alarm off. Meantime, the RED LED will flash if the data exceeding or lower the setting data. -
Page 5: Taking Measurement
TEMPERATURE UNIT(°C or °F) Press UNIT button to toggle the temperature unit (°C or°F) . MAXIMUM/MINIMUM Press MODE button to appear MAX/MIN. Note: a) MAXIMUM. MINIMUM: The unit automatically records maximum reading and minimum reading after powered on. b) RESET MAX/MIN: Power off the meter to reset MAX and MIN reading. - Page 6 DATALOGGING FUNCTION (AMT207 Only) If you want record Temp.RH, plug with supplied USB cable as below to do the on-line logging function NOTE: Ensure to set up date and time first Plug mini USB cable onto logger unit, and the male USB plug onto computer, follow the instruction manual to install datalogger software.
-
Page 7: Specifications
SPECIFICATIONS Spec./ Model no. AMT208 AMT207 Visable LED alarm Online logging Logger mode Temp.range -20~50℃ -20~50℃ Accuracy ±1.0C ±1.0C RH % range 2~90%RH 2~90%RH ±5%(at 25 ℃ ) ±5%(at 25℃ ), Accuracy Memory capacity 64000 online CE CERTIFICATE The product complies with EMC directive 2004/108/EC... -
Page 8: Warranty
Amtast USA Inc 438 Skyline Dr. E Lakeland Fl. USA Distributor...
