Front Panel Controls - TELEREADER CWR-880 Operating Instructions Manual

1) POWER: Power switch
2) MONI: Volume adjustment of audio monitor
3) TONE: Frequency adjustment of input audio signal
CW:
RTTY: 1275 Hz – 2125 Hz, continuously changeable
4) CW/RTTY: CW (telegraph) / RTTY (radio teletype) selector pushbutton switch
5) MODE: Operation mode selector pushbutton
6) SPEED: Baudot
TOR
ASCII
7) USOS
In RTTY operation: Unshift-on-space function pushbutton
AUTO
8) NOR
Input polarity selector pushbutton in RTTY operation: Normal
REV
9) LTR
Letter case changeover pushbutton in RTTY operation: LTR
FIG
10) GEN: CW operation: Starts random code generation. ON
11) UP: Scroll up the screen
12) DWN: Scroll down the screen
(UP and DWN switches effects continuous scrolling when kept being pressed.)
4 – FRONT PANEL CONTROLS
750 Hz – 850 Hz, continuously changeable
In CW operation: Alphabetical letters
In RTTY operation: Baudot
45 50 57
Synchronized reset
110 300
TOR ASCII
75
75
5
reverse
FIG
OFF
