Summary of Contents for YUNEEC CGO2-GB
-
Page 2: Table Of Contents
5 ......What is included in the CGO2-GB 6 ...... -
Page 3: Technical Speci Cations
Yuneec for small UAVs. The compact and light-weight CGO2-GB is suitable for high quality rst person view (FPV) for an array of ying platforms. CGO2-GB includes long range and low-latency digital Wi-Fi video link, providing users with a high de nition, portable real-time video solution. -
Page 4: Overview
OVERVIEW Illustration A: LED indicator： -Red LED solid: Power On -Green LED solid: Get Ready -Green and Blue LEDs ash alternatively: Video/Photo taking -Yellow LED ashes: T card error -Red LED ashes: Wi error Camera 5.8 Ghz Wi-Fi Antenna Illustration B: Yaw axis Roll axis arm Weight balancing part... - Page 5 NOTE：T Card Storage should be more than 4GB or CGO2GB will failed in recording. T card slot 5pin MICRO USB Illustration D: CGO2-GB Control cable slot (3 pin cable from QX1 ) PWM slot Camera power cable slot (Cable from CGO2-GB) UART...
- Page 6 Illustration E: gyro cable slot SR12S cable slot CGO2-GB power cable slot (2 pin cable from QX1 ) potentiometer cable slot Yaw motor control cable slot Roll motor control cable slot Pitch motor control cable slot...
-
Page 7: What Is Included In The Cgo2-Gb
What is included in the CGO2-GB Illustration F：The entire CGO2-GB includes a camera, a gimbal and internal 5.8Ghz wi antenna. Gimbal Camera Internal 5.8Ghz Wi Antenna Mounting on QX1 Mounting CGO2-GB to QX1 Step.1 Mounting CGO2-GB transfer board to the QX1 with 3 socket head cap screws (ST2.5*10). - Page 8 Illustration H：Transfer board mounted to QX1 Step.2 Slide the CGO2-GB onto the transfer board as shown until it locks. Illustration I:...
-
Page 9: Powering The Cgo2-Gb
CGO2-GB power cable slot (Illustration E) and the “CGO2-GB control cable” to the CGO2-GB control cable slot (Illustration D) . Note: The CGO2-GB does not contain any battery pack. It is directly powered from the QX1. Illustration J：... - Page 10 Turn on the power button to “ON” To Power ON: Turn on the power button on QX1 to “ON”, Red LED indicates CGO2GB has been successfully powed on, 30-40s later, when the Red LED turns into Green LED, it indicates that wi for CGO2GB is ready. To Power OFF: Turn o the power button on QX1 to “OFF”.
-
Page 11: Cgo2-Gb App Interfaces
VIEW PHOTO/VIDEO TAKE PHOTO, START/STOP RECORDING START/STOP RECORDING TROUBLESHOOTING GUIDE WHAT SOLUTION The CGO2-GB keeps CGO2-GB may not be Make sure the CGO2-GB vibrating after mounted securely to is slided onto the transfer initializing. the transfer board. board until it locks . - Page 12 QX1, be sure to connect connected into the the power cable from correct port. QX1 to the slot on CGO2-GB. CGO2-GB may not have Check CGO2-GB yaw axle CGO2-GB failed in positive connection control cable, if necessary turning back to the via yaw axle cable.
-
Page 13: Cgo2Gb Smartphone Fpv App
5. Copy your precious les to the computer. Using Micro card: 1. Turn o the power switch on QX1. 2. Take the T card out of CGO2-GB and insert it in the T card slot of your computer. 3. Double click ‘My Computer’, locate and double click ‘Removable Disk’. -
Page 14: Safety Warnings
2. Power on CGO2-GB (turn on the “ON/OFF” button on QX1). 3. Open your device’s Wi-Fi settings and connect to the CGO2-GB_****** network. 4. Enter the password ‘key’ located on the CGO2-GB. 5. Open the CGO2-GB App on your smartphone or tablet. - Page 15 (1) This device may not cause harmful interference (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 16 (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Keep CGO2-GB out of the reach of any liquid. Age Recommendation: Not for children under 14 years. This not a toy.
-
Page 17: Warranty
Yuneec disclaims all other expressed or implied warranties or conditions. To the extent not prohibit- ed by law, in no event will Yuneec be liable for any loss of data, revenue or pro t, or for any special, indirect, consequen-... -
Page 18: About The Quickstart Manual
Yuneec has been advised of the possibility of such damages. In no event will Yuneec’s liability exceed the amount paid by you for the product. Some jurisdictions do... - Page 19 Copyright 2014 Yuneec...
