aldes ALD-5404 Installation, Specification And Settings

Technical Data

Outputs
Power supply
Power consumption
Set point range
Control accuracy
Proportional band
Electrical connection
Operating temperature
Storage temperature
Relative Humidity
Degree of protection of housing

Presentation

Dimensions

B
ALD-5404/110718

Feature:

0 or 22 VDC, TPM, (Time proportional modulation) 25 mA max.
Weight
Symbols on display
or
D
A C
Room controller Thermostat
Specification & Installation manual
•
Selectable analog output
•
Selectable Fahrenheit or Celsius scale
•
Manual Night Set Back override
•
Multi level lockable access menu
•
Lockable Set point
•
Selectable internal or external temperature
sensor (10 KΩ )
•
Selectable proportional control band
ALD-5404
2 Analog Cooling outputs (0-10VDC)
2 Analog Heating outputs (0-10VDC)
22 to 26 VAC 50/60Hz
10ºC to +35ºC [50ºF to 95ºF]
Temperature: +/-0.2ºC [0.4ºF]
0.5 ºC to 4ºC [1 ºC to 8ºF] adjustable
2
0.8 mm [18 AWG] minimum
0ºC to +50ºC [32ºF to +122ºF]
-30ºC to +50ºC [-22ºF to +122ºF]
5 to 95 % non condensing
IP 30 to EN 60529
85 g. [0.2 lb]
Cooling ON
A: Automatic
Heating ON
A: Automatic
Energy saving mode ON
ºC: Celsius scale
ºF: Fahrenheit scale
Dimension
2 VA
Menu set-up Lock ON
Programming mode
Minimum/Maximum
set points
Inches
3.00
A
3.00
B
1.00
C
2.36
D
ALD-5404
Metric (mm)
78
78
24
60
1
