GEIGER RADIO SYSTEMS
Sunshade controls
Radio remote controls
for rolling shutters and
sunshade controls
3-channel GF0040
6-channel GF0041
12-channel GF0042
Comfort handheld transmitter
with graphic display
EN
Operating instructions
LIVINGROOM
AWNING 1
AWNING 2
BLIND 1
BLIND 2
BLIND 3
LIGHT 1
EDIT
EN
Advertisement
Table of Contents
Related Manuals for GEIGER GF0040
Summary of Contents for GEIGER GF0040
- Page 1 GEIGER RADIO SYSTEMS Sunshade controls Radio remote controls for rolling shutters and sunshade controls LIVINGROOM AWNING 1 3-channel GF0040 AWNING 2 BLIND 1 BLIND 2 6-channel GF0041 BLIND 3 LIGHT 1 EDIT 12-channel GF0042 Comfort handheld transmitter with graphic display...
-
Page 2: Table Of Contents
Sleep mode ..........................4 6. Operating instructions .........................5 Multifunction keys .........................5 Navigation keys ..........................5 Turning on the display transmitters GF0040 / 41 / 42 ................6 Selection of the actuator / receiver ....................6 Send a radio command ........................6 7. Programming and coding instructions .....................7 Select the language ........................7... -
Page 3: Introduction
No labour-intensive and time-consuming laying of control lines is needed as all switching signals are transmitted via radio. The following actuators (radio receiver with integrated control) can be controlled with the GEIGER comfort handheld transmitters: • all GEIGER motors with built-in radio receivers • all external GEIGER radio receivers... -
Page 4: Comfort 12-Channel Display Handheld Transmitter Gf0042
You get the transmitter to enter the deep sleep mode when all keys are not actuated for 1 minute. The display shuts down. The OK key keeps active. To wake the transmitter back up, simply press the OK key. Gerhard Geiger GmbH & Co. | 100W0624 0311... -
Page 5: Operating Instructions
6.2 Navigation keys These keys have several functions: Exit or change the menu items Vertical change of the menu items or send the selected radio command “OK” navigation key to ACTIVATE the device to SEND (one-channel) and to CONFIRM several functions. www.geiger-antriebstechnik.de... -
Page 6: Turning On The Display Transmitters Gf0040 / 41 / 42
6.3 Turning on the display transmitters GF0040 / 41 / 42 Press “OK” key The device turns out when no keys are activated. After 10 seconds the display light turns off, after 60 seconds, the device enters the deep sleep mode. -
Page 7: Programming And Coding Instructions
7. Programming and coding instructions 7.1 Select the language Press OK key to activate the comfort handheld transmitter The GEIGER logo shows for 3 seconds Press key „EDIT“ for > 4 seconds till an arrow displays SETTINGS on the left side... - Page 8 Example: in order to select the area name „LIVING ROOM“ AREANAME proceed as follows: LIVINGROOM EDIT To take over the new area name „LIVING ROOM“ press x 2 the LIVINGROOM multifunction key „ML“ EDIT Gerhard Geiger GmbH & Co. | 100W0624 0311...
- Page 9 If handheld transmitters GJ..01 - ..06 are already programmed on actuators / receivers, the DIP switches 8 +9 should be set as follows: Key pair 1 UP: 0 0 DOWN: 0 – Key pair 2 UP: – 0 DOWN: – – Key pair 3 UP: 0 + DOWN: + 0 www.geiger-antriebstechnik.de...
- Page 10 The DIP switch settings 1-7 are saved, the DIP switches 8 and 9 are set on the next channel. If the selected actuator „Venetian blind 1“ is not controlled by a sensor, then continue straight to step Gerhard Geiger GmbH & Co. | 100W0624 0311...
- Page 11 BLIND 1 the set codings are saved and you leave the programming level. You are now back in service menu. EDIT Should another actuator be added, press the navigation key DOWN LIVINGROOM BLIND 1 and start again at point EDIT www.geiger-antriebstechnik.de...
-
Page 12: Transfer Set Codings On Actuators / Receivers
In order to transfer the set codings on the various actuators / receivers, please refer to the operating instructions of the respective devices and to the instruction manuals of the GEIGER motors with integrated and external radio receivers. 7.4 Selection of various actuators / receivers... -
Page 13: Delete Or Modify Areas, Actuators And Codings
NAME CODE DELETE Now delete with multifunction key „OK“ LIVINGROOM AWNING 1 EDIT AWNING 2 and return to operating mode with multifunction key left „ML“ BLIND 1 BLIND 2 LIGHT 1 The actuator (receiver) „Blind 2“ is deleted.. EDIT www.geiger-antriebstechnik.de... -
Page 14: Reset To Factory Setting
CLEAR ALL? RESET IF YOU NOW PRESS THE MULTI-FUNCTION KEY ALL DELETE SETTINGS ARE DELETED! CHANGES ? With the multi-function key „left arrow“ you exit this point CANCEL without making any changes DELETE Gerhard Geiger GmbH & Co. | 100W0624 0311... -
Page 15: Care And Maintenance
8. Care and Maintenance Like any electronic device, the comfort display handheld transmitters GF0040, 41 and 42 should be treated with care. The suggestions below will help you fulfil guarantee obligations and enjoy this product for many years to come. If operated normally, the life of the battery inserted in the device comes to approx. 2 years. -
Page 16: Gerhard Geiger Gmbh & Co. | 100W0624 En
