OUTLAW PB – BATTERY DRY VACUUM
WARNING: Failure to observe these instructions can cause
WARNING: Shock or electrocution hazard.
ALWAYS disconnect batteries before
performing any maintenance or service.
WARNING: Shock or electrocution hazard.
NEVER connect this machine to any
batteries other than genuine NSS batteries.
WARNING: Burn/Fire hazard.
ALWAYS handle batteries with care.
WARNING: This product contains a chemical known to the state of California to cause
cancer and birth defects or other reproductive harm.
INTENDED USE
NSS vacuum cleaners are intended for commercial
use, vacuuming floors, furniture, and draperies in an
indoor environment. This machine is intended for
Dry pickup only. NSS does not recommend using
these machines for any other purpose.
FOR SAFETY
• ALWAYS read and understand all instructions before
operating or servicing machine.
• ALWAYS use this machine ONLY as described in this
manual.
• ALWAYS remove all jewelry when handling the
batteries.
• NEVER attempt to operate this machine unless you
have been trained in its operation.
• NEVER allow an untrained person to operate this
machine.
• NEVER attempt to operate this machine if it is not
working properly or has been damaged in any manner.
• NEVER disconnect or modify any switches or safety
devices.
• NEVER drop or insert any object into any machine
opening.
• NEVER operate this machine with any air opening
blocked. Keep all air openings free of dust, lint, hair,
etc.
• NEVER pull or carry the charger by its electrical
supply cord(s), use the cord(s) as a handle, close a
door on the cord(s), pull the cord(s) around sharp
edges or corners, expose to heated surfaces, run
machines over cord(s), or set heavy or sharp objects
on the cord(s).
ALL REPAIR SERVICE MUST BE PERFORMED BY AN NSS AUTHORIZED DISTRIBUTOR /
SERVICE STATION USING ONLY NSS ORIGINAL EQUIPMENT PARTS.
SAVE THESE INSTRUCTIONS
OPERATION MANUAL
personal injury to machine, operator, or bystanders.
WARNING: Fire or explosion hazard.
NEVER use to pick up flammable or
combustible liquids, or any thing that is
burning or smoking, such as cigarettes,
matches or hot ashes.
NEVER operate this machine in an
explosive atmosphere (grain dust,
flammable liquids or fumes, etc.)
• NEVER allow this machine to be used as a toy. Close
attention is necessary when used near children.
• ALWAYS keep face, fingers, hair or any other body part
or loose clothing away from any machine opening or
moving part.
• NEVER use this machine on wet surfaces or for wet
pickup.
• ALWAYS use extreme care when cleaning on stairs or
when machine is placed on stairs.
• NEVER operate machine without all filters in place.
• NEVER use any attachments other than the
manufacturers recommended attachments.
• NEVER spray this machine with water or any liquids.
• NEVER operate the machine outdoors.
• NEVER expose the machine to rain, snow, or extreme
temperatures.
• ALWAYS store this machine indoors in a dry, cool area.
BATTERY CHARGING
• NEVER charge batteries with any charger other than the
approved NSS charger for the Outlaw PB.
• NEVER use the NSS charger to charge batteries other
than genuine NSS batteries for the Outlaw PB.
• NEVER block the ventilation fan on the charger.
• ALWAYS keep flammable materials away from the
charger.
• NEVER disassemble or modify the charger in any way.
• NEVER touch the un-insulated portion of the output
connector or un-insulated battery terminal.
• NEVER operate charger if the AC supply cord is damaged
or if the charger has received a sharp blow, been
dropped, or otherwise damaged in any way.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB and is the answer not in the manual?

Questions and answers

Summary of Contents for Outlaw PB

  • Page 1: Important Safety Instructions

    • NEVER use the NSS charger to charge batteries other • NEVER drop or insert any object into any machine than genuine NSS batteries for the Outlaw PB. opening. • NEVER block the ventilation fan on the charger. • NEVER operate this machine with any air opening •...
  • Page 2: Grounding Instructions

    IMPORTANT SAFETY INSTRUCTIONS GROUNDING OF ELECTRICAL EQUIPMENT-BATTERY CHARGER WARNING: Improper connection of the equipment–grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service person if you are in doubt as to whether the outlet is properly grounded.
  • Page 3: General Information

    DROPPING BATTERIES MAY CAUSE AN UNSAFE CONDITION. ASSEMBLY • The Outlaw PB requires minimal assembly. The hose must be plugged into the canister inlet - right hand or left hand (photo 1). Be sure to insert the provided plug into the unused inlet.
  • Page 4: Machine Components

    OR OTHER FLUIDS. Trigger Charging the Batteries The Outlaw PB is equipped with a “hold to run” trigger The battery charger provides proper charging and to turn the vacuum on squeeze the lever against the charge maintenance of the special batteries used by handle (photo 6).
  • Page 5 The LED light next to that cord will display the status of that battery. • RED = charging • GREEN = charge complete. • ORANGE = charge pending. • BLINKING YELLOW = Charge failed, unplug the Photo 10 battery then plug back in. If still blinks yellow, call for repair.
  • Page 6 Battery Installation Attachments Two battery packs are required to operate the vacuum. The Outlaw PB comes equipped with a 1 1/4” There is a battery - carrying pouch located on each telescoping wand, a combination carpet / hard floor side of the harness (photo 14). The pouches can be tool, a crevice tool, and a round brush.
  • Page 7 Other • Replace batteries after approximately 500 cycles. Batteries need replaced when runtime is significantly diminished. Optional Equipment 6793111 HEPA filter Brute Mounted Outlaw PB parts (photo 22) 6990781 Hanger Brackets 6990791 Accessory Skirt Photo 19 6990801 10 ft Hose...
  • Page 8: Troubleshooting

    NSS ® Enterprises, Inc. European Distribution Centre Unit II, Pinfold Trading Estate * 55 Nottingham Road STAPLEFORD, NOTTINGHAM NG9 8AD ENGLAND U.K. PHONE: (44) 0115 939 1568 * FAX: (44) 0115 949 0615 Outlaw PB Dry Vacuum Operation Manual Rev H 05-12 6991051...
