NOTE:

Please read all

instructions carefully

before using this product

Table of Contents

Safety Notice

Hardware Pack

Assembly Instruction

Parts List

Warranty

Ordering Parts

Model

NS-654

Retain This

Manual for

Reference

160718

OWNER'S

MANUAL

FOLDABLE BIKE

NS-654

IMPEX

2801 S. Towne Ave, Pomona, CA 91766

Tel: (800) 999-8899

www.impex-fitness.com

support@impex-fitness.com

INC.

Table of Contents

Need help?

Do you have a question about the NS-654 and is the answer not in the manual?

Questions and answers

Summary of Contents for Impex NS-654

Page 1 NOTE: Please read all instructions carefully before using this product FOLDABLE BIKE Table of Contents NS-654 Safety Notice Hardware Pack Assembly Instruction Parts List Warranty Ordering Parts Model NS-654 Retain This Manual for Reference 160718 OWNER'S ® IMPEX INC. MANUAL 2801 S.
Page 2: Table Of Contents
BEFORE YOU BEGIN ® ® Thank you for selecting the MARCY NS-654 by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction. If you have any questions, or find there are missing or damaged parts, we guarantee you complete satisfaction through direct assistance from our factory.
Page 3: Important Safety Notices
OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. SAVE THESE INSTRUCTIONS.
Page 4: Warning Label Placement
WARNING LABEL REPLACEMENT The Warning Label shown here has been placed on the rear Stabilizer. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown.
Page 5: Pre-Assembly Check List, Hardware Pack
PRE-ASSEMBLY CHECK LIST...
Page 6 HARDWARE PACK Ensure all hardware components are included in the hardware pack prior to assembly.
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTION NOTE: It is strongly recommended that two or more people assemble this bike to avoid possible injury. Tools required for assembling this bike: Allen Wrench and Crossing Wrench packed in Hardware Pack. STEP 1 (See Diagram1) A). Pull out the Lock Pin (#11). B.) Unfold and extend the Main Frame (#1) and Rear Support (#2).
Page 8 STEP 2 (See Diagram 2) A.) Attach the Front Stabilizer (#5) to the bracket on bottom of Main Frame (#1). Secure it with two M8 x 2 ⅜” Carriage Bolt (#21), two Ø ⅜” x Ø ⅞” Curved Washers (#9), and two Domed Nuts (#10).
Page 9 STEP 3 (See Diagram 3) A.) Firmly thread the Left Pedal (#8L) counter clockwise onto left crank. B.) Firmly thread the Right Pedal (#8R) clockwise onto right crank. DIAGRAM 3...
Page 10 STEP 4 (See Diagram 4) A.) Remove the three M8 Nylon Nuts (#13) and three Ø ⅜” x Ø ¾” Flat Washers (#14) under the Seat Pad (#7). B.) Insert the bolts under the Seat Pad to the Seat Post (#4). Secure it with the three M8 Nylon Nuts (#13) and three Ø...
Page 11 STEP 5 (See Diagram 5) A.) Insert the Handlebar into the opening on top of Rear Support (#2). B.) Secure it with four M6 x ½” Allen Bolts (#15), four Ø ½” Lock Washers (#16), two Ø ½” Washers (#17), and two Ø ½” Curved Washers (18). C.) Connect the Computer Wire (#20) to Computer.
Page 12: Folding The Bike
FOLDING THE BIKE A.) Pull out Lock Pin (#11). Fold down the Main Frame (#1). B.) Insert the Lock Pin (#11) to lower hole to safely folded the Bike.
Page 13: Exploded Diagram
EXPLODED DIAGRAM...
Page 14: Parts List
NS-654 PARTS LIST PART DESCRIPTION SPEC. QUANTITY Main Frame Rear Support Handlebar Seat Post Front Stabilizer Rear Stabilizer Seat Pad Left Pedal Right Pedal Ø ⅜” x Ø ⅞” Curved Washer Domed Nut Lock Pin 2 ¾” Lock Knob Nylon Nut Ø...
Page 15: Computer
COMPUTER AUTO START / STOP When exercise starts, the monitor will automatically turn on and display the progress. When exercise stops, the monitor will automatically turn off after 5 minutes to save energy. Press “MODE” key, will automatically scan Time, Speed, Distance, Calories, and ODO for every 4 seconds.
Page 16: Care And Maintenance, Operating Notes
Review all warning notices before using the bike. Electronic warning notices may be obtained by contacting customer support (support@impex-fitness.com). Allow minimum 20” of clear spaces in all directions to operate the bike. Before mounting or dismounting move the pedal on the mounting or dismounting side to its lowest position and bring the bike to a complete stop.
Page 17: Exercise Instructions
EXERCISE INSTRUCTIONS Using your FOLDABLE BIKE will provide you with several benefits, it will improve your physical fitness, tone muscle and in conjunction with calorie controlled diet help you lose weight. 1. The Warm Up Phase This stage helps get the blood flowing around the body and the muscles working properly.
Page 18 This stage should last for a minimum of 12 minutes though most people start at about 15-20 minutes 3. The Cool Down Phase This stage is to let your Cardio-vascular System and muscles wind down. This is a repeat of the warm up exercise e.g. reduce your tempo, continue for approximately 5 minutes.
Page 19: Warranty
IMPEX authorized service center or for products used for commercial or rental purposes. No other warranty beyond that specifically set forth above is authorized by IMPEX.
