Iridium 9505A Satellite Phone
Simple User Guide
This is not a normal mobile phone, but it's easy!
Just follow these 3 simple steps...
1
2
3
Go Outside
Rotate & Extend
Switch On
Antenna
1) Go Outside
Before you switch on the phone ensure that you are outside, away
from buildings and trees, with a clear uninterrupted view of as much
sky as possible.
The phone requires a clear line of sight to the satellites at all times.
The more sky you can see the more reliable the connection will be.
This phone will not work reliably indoors (if at all), even by a
window.
It may be helpful to understand that there are many Iridium
satellites, and that they are continually moving across the sky,
'handing-over' your signal from one to another as they pass
overhead. Therefore, it is normal for the signal strength to vary as
the satellites cross your path. If you do not have a sufficiently
expansive clear uninterrupted view of the sky then your received
signal strength may vary dramatically, or even drop altogether, as
you await the arrival of the next satellite. The only solution to this is
to find yourself a position with more sky!
Page 1 of 8
SUG3:12APR2012
Advertisement
Table of Contents
Summary of Contents for Mobell Iridium 9505A
- Page 1 Iridium 9505A Satellite Phone Simple User Guide This is not a normal mobile phone, but it’s easy! Just follow these 3 simple steps… Go Outside Rotate & Extend Switch On Antenna 1) Go Outside Before you switch on the phone ensure that you are outside, away from buildings and trees, with a clear uninterrupted view of as much sky as possible.
- Page 2 2) Rotate and Extend Antenna Carefully rotate the antenna to a vertical position, and pull it to fully extend the end section. The antenna works best when it is pointing vertically upwards. The antenna should be rotated to the appropriate position, left or right of centre, so as to maintain this vertical position when it is held to your ear.
- Page 3 (if there is one): CountryCode AreaCode PhoneNumber For example: to call Mobell in the UK… 00 44 1543 426999 to call another Iridium phone… 00 8816 xxxx xxxx Receiving Calls The antenna must be rotated and fully extended to receive calls.
- Page 4 Sending Messages from the Iridium Phone You can send short text messages to email addresses, other Iridium phones and most mobile phones. To send a text message to a mobile phone or another Iridium phone Press MENU, scroll down to Messages and press OK Scroll up to Message Editor and press OK Type your message (using the number keys to select letters - max 160 characters)
- Page 5 Making Calls to the Iridium Phone There are two ways to a call an Iridium phone; ’Direct-Dialling’, and ‘2-Stage Dialling’. Unfortunately many phones cannot make direct-dialled calls to satellite phones; even phones that can are often charged at very high rates. Some telephone providers charge up to £10 per minute for direct-dialled calls to Iridium phones, therefore callers are first advised to contact their provider to confirm the cost! Iridium’s 2-Stage dialling system solves these problems by...
- Page 6 Sending Messages to the Iridium Phone It’s easy to send messages to the Iridium phone – see the three options below: Leave a Voicemail Message If the Iridium phone cannot be reached (because it is switched off, out of coverage, or busy on another call) then incoming calls will be forwarded to the Iridium Voicemail Service Important note: The caller may be prompted to re-enter the Iridium phone number.
- Page 7 Voicemail Leaving a Voicemail Message If your Iridium phone cannot be reached (because it is switched off, out of coverage, or busy on another call) then your incoming calls will be forwarded to the Iridium Voicemail Service. Important note: The caller may be prompted to re-enter your Iridium phone number.
- Page 8 For more information please refer to the Iridium Handset User Manual supplied. If you experience any problems that cannot be resolved by reference to these guides then please contact us as soon as possible. + 44 1543 426999 rental@mobell.com Page 8 of 8 SUG3:12APR2012...
