Page 2
Selection of Installation Position for Outdoor Unit Items for Consideration Unit Installation Is the Unit Installed Correctly? Connection of Power Cable Exploded View Spare Part List Wiring Diagram Model Specification Pressure V.S. Temperature Chart Subcooling Method Troubleshooting...
Page 7
Gauges should be attached to both the service ports. Evacuate the unit down to a minimum of 200 Microns, break vacuum with Nitrogen to further leak check. Re-evacuate the system down to 200 Microns or lower. This is an R410a system, it is essential that a deep vacuum be pulled on the system to remove all traces of moisture.
Page 8
Two knockouts are provided in the side panel of unit. One knockout is for power 115V/230V wiring. One knockout is for control 24V wiring.
