PS1503SB - - DC-REGULATED POWER SUPPLY
1. Introduction
Thank you for buying the PS1503SB. Read this manual carefully before bringing the device into service.
2. Technical Specifications
Input Voltage
Output Voltage
Output Current
Ripple & Noise
Supply Regulation
Load Regulation
Accuracy Voltage
Accuracy Current
Protection
Operating Temperature
Operating Humidity
Operating Atmospheric Pressure
Autonomy
Dimensions (L x W x H)
Weight
3. Block diagram
PS1503SB
: AC 220V ±10% ; 50Hz ±2Hz
: 0-15V continuously adjustable
: 0-3A continuously adjustable
: CV≤1.0mVrms
CC≤3mArms
: CV≤1x10
+0.5mV
-4
CC≤2x10
+6mV
-3
: CV≤1x10
+2mV
-4
CC≤2x10
+6mV
-3
: ±1% + 2 digits
: ±2% + 2 digits
: current-limiting
: 0 - 40°C
: <RH80%
: 86kPa ~ 104kPa
: 8hrs of continuous operation
: 225 x 95 x 160mm
: 2.5kg
1
VELLEMAN
Advertisement
Table of Contents
Related Manuals for HQ Power PS1503SB
Summary of Contents for HQ Power PS1503SB
-
Page 1: Technical Specifications
PS1503SB - - DC-REGULATED POWER SUPPLY 1. Introduction Thank you for buying the PS1503SB. Read this manual carefully before bringing the device into service. 2. Technical Specifications : AC 220V ±10% ; 50Hz ±2Hz Input Voltage Output Voltage : 0-15V continuously adjustable... -
Page 2: Front Panel
- The unit can get very hot when you are using a high power output. - If the unit is defective, the output may rise over the maximum rated voltage. Always keep an eye on the load to prevent damage. - This unit should be earthed properly. 6. Accessories 1 instruction manual. PS1503SB VELLEMAN... -
Page 3: Technische Specificaties
PS1503SB - - REGELBARE DC LABORATORIUMVOEDING 1. Inleiding Dank u voor uw aankoop! Lees deze handleiding aandachtig voor u uw PS1503SB in gebruik neemt. 2. Technische Specificaties : AC 220V ±10% ; 50Hz ±2Hz Ingangsspanning Uitgangsspanning : 0-15V regelbaar Uitgangsstroom : 0-3A regelbaar Rimpel &... -
Page 4: Spécifications Techniques
1 gebruikershandleiding. PS1503SB - - ALIMENTATION CC REGLABLE 1. Introduction Nous vous remercions de votre achat ! Lisez le manuel attentivement avant de prendre votre PS1503SB en service. 2. Spécifications Techniques : AC 220V ±10% ; 50Hz ±2Hz Tension d’entrée Tension de sortie : 0-15V réglable... - Page 5 - Quand l’appareil est défectif, la tension de sortie peut dépasser le maximum programmé. Gardez toujours un œil sur la charge pour éviter des dommages. - Cet appareil doit bien être mis à la masse. 6. Accessoires 1 manuel d’utilisation. PS1503SB VELLEMAN...
